- Page 1 ÆtherBox IP65 1 universe CRMX transceiver, DMX and Ethernet protocols, Wi-Fi, Bluetooth and battery ready USER MANUAL English version Rev.01 - Preliminary...
- Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.
- Page 3 11 - ACCESSORIES INSTALLATION RACK ADAPTER (CODE AEBRACKADP) ................ 15 BATTERY HOLDER (CODE AEBBATADP) ............... 16 12 - TEST OF IP65 RATING 13 - MAINTENANCE MAINTENANCE THE PRODUCT ..................18 VISUAL CHECK OF PRODUCT HOUSING ..............18 TROUBLESHOOTING ..................... 18 PROLIGHTS - ÆtherBox...
-
Page 4: Safety Information
• Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center. - Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
- Page 6 2. This device must accept any interference received, including interference that may cause undesired operation. Other approvals • The product meets the safety requirements of the certification procedures of the market in which it is placed and sold. PROLIGHTS - ÆtherBox...
-
Page 7: Package Content
1 - PACKAGING PACKAGE CONTENT • 1 x AETHERBOX; • 1 x AEB2DBA90D; • 1 x 1,5 meters 3G1,5mmq power cable (BARE END - SEETRONIC POWERCON TRUE1 IP65 power connector); • User Manual OPTIONAL ACCESSORIES Check the updated accessories list, description and informations of the product at the following link: https://www.prolights.it/product/AETHERBOX#accessories... -
Page 8: Installation
Warning! When clamping the fixture to a truss or other structure at any angle, use clamps of half-cou- pler type. Do not use any type of clamp that does not completely encircle the structure when fastened. C6002 clamp OS27 PLUS Steel security cable Fig.02 PROLIGHTS - ÆtherBox... -
Page 9: Connection To The Mains Supply
• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz). • The product is then ready for its operations and can be controlled through the available input sig- nals on board. • To disconnect power from the product, disconnect the Mains from the socket. PROLIGHTS - ÆtherBox... -
Page 10: Product Overview
1. USER INTERFACE with button and status LEDs for access to the functions; 2. PUSHABLE ENCODER to access and select the menu function; 3. POWER BUTTON to power on the AETHERBOX; 4. AEB2DBA90D 2dBi antenna; 5. SAFETY HOLE: to attach the safety cable;... -
Page 11: Control Panel Overview
• DMX from ethernet enabled. If this LED is on, DMX LED must be OFF • If this LED is on, the bluetooth is enabled • DMX In enabled. If this LED is on, NET LED must be OFF • If this LED is on, the RDM is enabled Fig. 05 PROLIGHTS - ÆtherBox... -
Page 12: Menu Structure
D (Only in CRMX2) F (Only in CRMX2) H (Only in CRMX2) <- BACK RX Mode: received from TX; UNIVERSE UNIVERSE NAME TX CRMX Mode: default first 16 characters METADATA of Model Name: (DEVICELABEL-Last 4 digit of RDM UID) PROLIGHTS - ÆtherBox... - Page 13 Set IP Address for ArtNet usage. SETTINGS 0-127 Set Net used for ArtNet, value from 0 to 127 0-15 Set SubNet used for ArtNet, value from 0 SUBNET to 15 SUBNET MASK Set SubNet Mask for ArtNet usage. PROLIGHTS - ÆtherBox...
-
Page 14: Menu Settings
Show CRMX firmware version of the fixture. WIFI Firmware 2.00.00 Show WIFI firmware version of the fixture. Working hours <999h> Show working hours of the fixture. RDM UID xxxx Show RDM UID of the fixture. <- BACK PROLIGHTS - ÆtherBox... - Page 15 Soft reset, factory reset keeping working hours power-on ENCODER 3 sec (keep Triggers on display settings for fast change. QUICK SETTINGS pushed) Enabled on home screen only. Keep pushed ENCODER LOCK/UNLOCK and then push LINK (1 Works only with KEYLOCK ON sec) (KEYLOCK) PROLIGHTS - ÆtherBox...
-
Page 16: Rdm Functions
1: 16 TX RF OUTPUT POWER 0x8318 2: 11 3: 5 dBm 0: Off BLUETOOTH 0x8319 1: On 0: No identify IDENTIFY 0x8317 1: Identify active 0: Off RDM DOWNSTREAM 0x8316 1: On LINK QUALITY 0x831A 0-255 PROLIGHTS - ÆtherBox... -
Page 17: Accessories Installation
11 - ACCESSORIES INSTALLATION RACK ADAPTER (CODE AEBRACKADP) Place the two metal plates as shown in figure (1), then fix them with the provided screws. Fig. 06 PROLIGHTS - ÆtherBox... - Page 18 BATTERY HOLDER (CODE AEBBATADP) Place the battery holder as shown in figure (1). Fig. 07 Lock the accessory by the provided pin as shown in figure (2). PROLIGHTS - ÆtherBox...
- Page 19 Remove the gore valve from the connections panel.Insert the threaded end into the threaded valve hole socket. Connect the air hose to the IPTESTBOX by inserting the quick-connect fitting into the coupler. For the operating procedure using the instrument, refer to the IPTESTBOX user manual. Fig. 08 PROLIGHTS - ÆtherBox...
-
Page 20: Maintenance The Product
IP grade of the fixture. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel. - Page 21 Note...
- Page 22 Note...
- Page 24 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
