- Page 1 Smart Metered pH Neutralizing Filter Installation / Operation Manual Model #: WS-PHN kindwater.com KIND WATER Have questions? Call us: 888-614-5559 EDUCATION WS-PHN-REV-C-FE25...
- Page 2 Items Included Tank Bypass Valve Hose Clamp 90-degree 1” Low Voltage Low Voltage Power NPT Fittings Power Cord Cord Extention Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •...
- Page 3 Please comply with all applicable plumbing codes Protect from FREEZING TEMPERATURES Please read the entire Installation/Operating Manual and Instruction before installation. This Installation/Operating Manual must stay with the unit. Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •...
-
Page 4: Installation Requirements
What Is a Smart Metered pH Neutralizing Filter and What Does It Do? The Kind Water Smart Metered pH Neutralizing Filter is essential to water treatment systems that neutralize acidic water and balance pH levels. Utilizing calcite media, composed of naturally occurring calcium carbonate, this media slowly dissolves in acidic water, raising its pH to a more neutral or slightly alkaline range. - Page 5 HOT WATER COLD WATER CITY WATER INLET WATER METER PRESSURE RELIEF VALVE (To drain) WS-PHN WATER PRESSURE HEATER TANK RELIEF VALVE MUST BE INSTALLED PUMP WELL INLET Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •...
- Page 6 Bypass Assembly Description Bypass (included with all units) 1” NPT Elbow Set (included with all units) Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •...
-
Page 7: Installation Procedure
Install inlet and outlet piping in direction of arrows. It is recommended that a vacuum breaker be installed on the inlet plumbing. KIND WATER EDUCATION Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •... -
Page 8: Electrical Connection
Check for leaks! If water is observed leaking from bypass, o-rings on valve body may not be seated properly. Exercise bypass valve. After air is evacuated from plumbing lines, turn off faucet. Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •... -
Page 9: System Start Up Procedure
• Make sure the power supply is connected to an uninterrupted 120-volt outlet. • Check that the time of day is set • Double check regeneration schedule. • Make final check for leaks! Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •... - Page 10 Bluetooth Control Utilizing Bluetooth Control For simplified set up and control, please install the Kind Water app on a compatible Bluetooth 4.0+ enabled smart phone or tablet. Download and install the Kind Water app from the Google Play Store, Apple App Store Open the Kind Water app •...
-
Page 11: Set Up Utilizing Bluetooth App
Consult Kind Water’s Technical Support Team at 888-614-5559 before NOTE making any changes. We do not recommend changing Advanced Settings unless you have a good understanding of the system operation.battery Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •... - Page 12 Set time of day. Set a.m. or p.m. Set regeneration day override if other than (3) days is desired. Set regeneration time, if other than 12:00 a.m. is desired. Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •...
- Page 13 3. Default setting is 6 days for filters. To Exit Main Menu, press the Menu/Enter button. If no buttons are pressed for 60 seconds, the Main Menu will be exited automatically. NOTE Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •...
-
Page 14: Normal Operation
No other system will be affected. Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •... -
Page 15: General Care And Cleaning
• Use only mild soap and warm water to clean exterior of the unit. Never use harsh, abrasive cleaners. • Protect the water filter and drain line from freezing. • Reset time for daylight saving time periods. • Replace 9-volt battery once a year. Kind Water Systems - Smart Metered pH Neutralizing Filter, Installation and Operation •...
