- Page 1 User Manual UMAX141550 Version 1.0.7 Firmware 1.00 Gigabit Ethernet / Gigabit Automotive Ethernet Converter USER MANUAL P/N: AX141550...
-
Page 2: Table Of Contents
TABLE OF CONTENT GENERAL INFORMATION ..........................3 Introduction ..............................3 Functional Block Diagram of the Converter ..................... 3 CONNECTORS ............................... 4 M12 8-pin (P/N: 1441817) ..........................4 M12 8-pin (P/N: 1441804) ..........................5 CONFIGURATION USING RS-232 ........................6 Show Configuration Parameter........................8 Change Configuration Parameters ........................ -
Page 3: General Information
If the proper power supply level is connected to the converter, the Power LED will be ON; indicating the converter is ON. The AX141550 is continuously monitoring the status of Link and Activity by reading the registers of Ethernet PHYs and will show the real-time update of Ethernet and Automotive Ethernet Link and Activity on Link and Activity LEDs, respectively. -
Page 4: Connectors
2. CONNECTORS The converter has two connectors. 2.1 M12 8-pin (P/N: 1441817) The M12 8-pin connector is used for the Ethernet 1000BASE-T connection. The mating harness P/N is: AX070535. Table 1 M12 8-pin connector (P/N:141817) PIN# Description BI_DC_P BI_DD_P BI_DD_N BI_DA_N BI_DB_P BI_DA_P... -
Page 5: M12 8-Pin (P/N: 1441804)
2.2 M12 8-pin (P/N: 1441804) The M12 8-pin connector is used for power supply, RS-232, CAN, and Automotive Ethernet. 1 Phoenix Contact M12 8-pin connector (A-coded). The mating harness PN is: AX070537 Table 2 M12 8-pin connector (P/N:1441804) PIN# Description BATT- BATT+ TRD_P... -
Page 6: Configuration Using Rs-232
Default configuration menu includes Project details like Project Name, Version number, Release Date, Part Number, and Serial Number. The menu has 8 options as attached in the picture below. To access any of the 8 options the one-time password is “AX141550”. Figure 5 Default Tera Term Menu... - Page 7 To view or change the configuration, please enter the password: “AX141550”. Figure 6 One-time password to access the Menu UMAX141550 7-19...
-
Page 8: Show Configuration Parameter
3.1 Show Configuration Parameter Press ‘1’ to see the Configuration parameters. This option will show Serial Number, Converter Mode, Converter Speed, and Log Timing. If the converter Mode is “Master”, it shows that Automotive Ethernet PHY is configured to work as Master. If the converter Mode is “Slave”, it shows that Automotive Ethernet PHY is configured to work as Slave. -
Page 9: Change Configuration Parameters
3.2 Change Configuration Parameters Press ‘2’ to change the configuration parameters. This option gives the choice to change Serial Number, Mode, Speed, and Log Timing. Enter the name of the parameter that needs to be changed other than Serial Number. The option to change the Serial Number is not available for field updates. Enter the name from the list given on the Tera term window. -
Page 10: Set Default Configuration Parameters
3.3 Set Default Configuration Parameters Press ‘3’ to set the default configuration parameters. This option will set the Mode and Speed to Slave and 1000Mbps respectively, as the default mode is Slave mode and default speed is 1000 Mbps. The log timing will be also changed to the default value, which is 1 Second. The configuration settings will be saved. -
Page 11: Start/Stop Logs
3.6 Start/Stop Logs Press ‘s’ to start or stop the debug logs. Starting the debug logs will print the supplied voltage to the Unit and Ethernet and Automotive Ethernet Link status on Tera Term, as per the Log Timing configuration. i.e., If Log Timing is 1 Second, the converter will print the debug logs every second. -
Page 12: Activate Bootloader
3.8.1 Load New Application Firmware Press ‘1’ to upload new Firmware. The firmware will be erased. Type ‘Yes’ only if a valid firmware file is received from Axiomatic Technologies to reflash. Bootloader flags will be erased. Which shows that firmware is erased. - Page 13 Figure 12 Step 1: File->Send File Figure 13 Select "Binary" and Select the Firmware File (Screenshot shown is illustrative only. The firmware loaded will be AF-22018-xx.yy for the AX141550.) UMAX141550 13-19...
-
Page 14: Technical Specifications
All our products carry a limited warranty against defects in material and workmanship. Please refer to our Warranty, Application Limitations & Return Materials Process as described on https://www.axiomatic.com/service/. 4.1 Input Power Supply... -
Page 15: General Specifications
4.5 General Specifications Functionality Can be configured to acts as a master or a slave Microcontroller STM32F413CGU6 3 Green LEDs BLINK Power Power On Power Off or Overvoltage/ LEDs Undervoltage Condition Link Ethernet Link Up Ethernet Activity Ethernet Link Down Activity Automotive Ethernet Link Up Automotive Ethernet Activity... -
Page 16: Electrical Connectors
A-coded. Mating Wire Harnesses The following part numbers are available from Axiomatic. AX070535: Ethernet Cable 2 m (6.5 ft.), 8-pin M12 A-coded, Ethernet Jack Note: The M12 connector on the harness assembly is rated for -20°C to 85°C and the RJ45 ethernet jack is rated as -20°C to 60°C. -
Page 17: Version History
5. VERSION HISTORY Version Date Author Modifications 1.0.0 October 16, 2023 Weixin Kong Initial Draft 1.0.1 October 23, 2023 Amanda Wilkins Added CE marking, ISO 13766-1:2018 1.0.2 October 24, 2023 Weixin Kong Revise the Technical Data 1.0.3 October 24, 2023 Amanda Wilkins Added mating cable p/n AX070537 1.0.4... -
Page 18: Our Products
Any inquiries should be sent to sales@axiomatic.com. Fan Drive Controllers SAFE USE Gateways, CAN/Modbus, RS-232 All products should be serviced by Axiomatic. Do not open the product and perform the service yourself. Gyroscopes, Inclinometers This product can expose you to chemicals which are known in the Hydraulic Valve Controllers State of California, USA to cause cancer and reproductive harm.
