- Page 1 User Manual UMAX141520 Version 1B Firmware 1.00 Automotive Ethernet to Ethernet Converter USER MANUAL P/N: AX141520...
-
Page 2: Table Of Contents
TABLE OF CONTENT GENERAL INFORMATION ..........................3 Introduction ............................... 3 Functional Block Diagram of the Converter ...................... 3 CONNECTORS ............................... 4 M12 8-pin ................................4 M12 12-pin ................................ 4 CONFIGURATION USING RS-232 ........................5 Show Configuration Parameter ......................... 8 Change Configuration Parameters ........................9 Set Default Configuration Parameters ...................... -
Page 3: General Information
If the proper power supply level is connected to the converter, the Power LED will be ON; indicating the converter is ON. The AX141520 is continuously monitoring the status of Link and Activity by reading the registers of Ethernet PHYs and will show the real-time update of Ethernet and Automotive Ethernet Link and Activity on Link and Activity LEDs, respectively. -
Page 4: Connectors
2. CONNECTORS The converter has two connectors. 2.1 M12 8-pin The M12 8-pin connector is used for the Ethernet 1000BASE-T connection. The mating harness P/N is: AX070535. Figure 2 M12 8-pin Ethernet Connector with RJ45 2.2 M12 12-pin The M12 12-pin connector is used for power supply, RS-232, CAN, and Automotive Ethernet. 1 Phoenix Contact M12 12-pin connector (A-coded). -
Page 5: Configuration Using Rs-232
Default configuration menu includes Project details like Project Name, Version number, Release Date, Part Number, and Serial Number. The menu has 8 options as attached in the picture below. To access any of the 8 options the one-time password is “AX141520”. UMAX141520 Version 1B... - Page 6 Figure 4 Default Tera Term Menu UMAX141520 Version 1B 6-19...
- Page 7 To view or change the configuration, please enter the password: “AX141520”. Figure 5 One-time password to access the Menu UMAX141520 Version 1B 7-19...
-
Page 8: Show Configuration Parameter
3.1 Show Configuration Parameter Press ‘1’ to see the Configuration parameters. This option will show Serial Number, Converter Mode, Converter Speed, and Log Timing. If the converter Mode is “Master”, it shows that Automotive Ethernet PHY is configured to work as Master. If the converter Mode is “Slave”, it shows that Automotive Ethernet PHY is configured to work as Slave. -
Page 9: Change Configuration Parameters
3.2 Change Configuration Parameters Press ‘2’ to change the configuration parameters. This option gives the choice to change Serial Number, Mode, Speed, and Log Timing. Enter the name of the parameter that needs to be changed other than Serial Number. The option to change the Serial Number is not available for field updates. Enter the name from the list given on the Tera term window. -
Page 10: Set Default Configuration Parameters
3.3 Set Default Configuration Parameters Press ‘3’ to set the default configuration parameters. This option will set the Mode and Speed to Slave and 1000Mbps respectively, as the default mode is Slave mode and default speed is 1000 Mbps. The log timing will be also changed to the default value, which is 1 Second. The configuration settings will be saved. -
Page 11: Start/Stop Logs
3.6 Start/Stop Logs Press ‘s’ to start or stop the debug logs. Starting the debug logs will print the supplied voltage to the Unit and Ethernet and Automotive Ethernet Link status on Tera Term, as per the Log Timing configuration. i.e., If Log Timing is 1 Second, the converter will print the debug logs every second. -
Page 12: Load New Application Firmware
3.8.1 Load New Application Firmware Press ‘1’ to upload new Firmware. The firmware will be erased. Type ‘Yes’ only if a valid firmware file is received from Axiomatic Technologies to reflash. Bootloader flags will be erased. Which shows that firmware is erased. - Page 13 Figure 11 Step 1: File->Send File Figure 12 Select "Binary" and Select the Firmware File UMAX141520 Version 1B 13-19...
-
Page 14: Technical Specifications
4. TECHNICAL SPECIFICATIONS 4.1 Power Supply Input Table 2 Power Supply Input 12V, 24Vdc nominal (9…36VDC power supply range) Power Supply Input - Nominal Protections Surge protection is provided. Reverse polarity protection up to -50V is provided. Input overvoltage (45V) and input undervoltage (6V) protection are provided. -
Page 15: Interfaces
Configurability Used to configure the unit as Slave (default) or Master functionality 4.5 General Specifications Table 6 General Specifications Functionality Model AX141520 can be configured to acts as a master or a slave. Microprocessor STM32F413CGU6 Compliance CE marking pending Vibration Random Vibration: Z-axis tracked vehicle profile (5 hr/axis in all 3 axes) Sinusoidal Component: 8.9 G Sine sweep, 2.5 hr/axis in all 3 axes... -
Page 16: Housing
4.6 Housing Figure 13 Dimensional Drawing UMAX141520 Version 1B 16-19... -
Page 17: Electrical Connectors
Mating connectors should meet the following standard for M12 Connectors, IEC 61076-2-101:2012. They should be A-coded. Mating Wire Harnesses The following part numbers are available from Axiomatic. AX070535: Ethernet Cable 2 m (6.5 ft.), 8-pin M12 A-coded, Ethernet Jack Note: Cable supplier is Phoenix Contact Network cable NBC-M12MR/2,0- 94B/R4AC US –... - Page 18 Figure 14 AX070535 Mating Cable Figure 15 AX07533 Mating Cable UMAX141520 Version 1B 18-19...
-
Page 19: Version History
5. VERSION HISTORY Version Date Author Modifications April 8 , 2021 Meera Patel Initial Draft February 4 , 2022 Meera Patel Completed the User Manual February 4 , 2022 Meera Patel Updated the Firmware Reflashing interface September 7, 2022 Amanda Wilkins, Updated PHY spec and user interface details in Peter Yin Specifications section... - Page 20 Any inquiries should be sent to sales@axiomatic.com. Fan Drive Controllers SAFE USE Gateways, CAN/Modbus Protocols All products should be serviced by Axiomatic. Do not open the product and perform the service yourself. Gyroscope Inclinometers This product can expose you to chemicals which are known in the Hydraulic Valve Controllers State of California, USA to cause cancer and reproductive harm.
