CIAT CONNECT TOUCH Control Service Manual page 201

ECG-SG-20-004
SERVICE GUIDE
Point Name
alarm_2c
alarm_3c
alarm_4c
alarm_5c
mstslv
W_P_OUT
W_P_IN
WP_OFFST
WAT_FLOW
PUMP_1
PUMP_2
VPMP_CMD
7.30.4 Alarm collect
The table below includes all alarms that are collected by the black box.
Alarm code Alarm description
15001 Cooler Entering Fluid Thermistor
15002 Cooler Leaving Fluid Thermistor
15003 Circuit A Defrost Thermistor
15004 Circuit B Defrost Thermistor
15010 OAT Thermistor Failure
15011 MASTER/Slave Common Fluid Thermistor
15012 Circuit A Suction Gas Thermistor
15013 Circuit B Suction Gas Thermistor
15015 Circuit A Discharge Gas Thermistor Failure
15044 Coil Suction Gas Thermistor Sensor 1 Failure
15045 Coil Suction Gas Thermistor Sensor 2 Failure
15053 Water Tank Output Thermistor Failure
12001 Circuit A Discharge Transducer
12002 Circuit B Discharge Transducer
10014 Flow Switch & Customer Interlock failure
10028 Main Power supply fault
10031 Emergency Stop
09001 Master chiller configuration error Number #1 to nn
Version I
Connect Touch AQUACIAT LD / ILD:
03/2024
Description
Current Alarm 2
Current Alarm 3
Current Alarm 4
Current Alarm 5
Unit is Master or Slave
Outlet Water Pressure
Inlet Water Pressure
Water Pressure Offset
Water Flow
Pump #1 Command
Pump #2 Command
Pump Drive Output
Go to – Table of Contents
CONTROL OPERATIONS
Unit configuration
Master/Slave in effect
Hydronic Kit
Hydronic Kit
Hydronic Kit
Hydronic Kit
Hydronic Kit
Hydronic Kit
Hydronic Kit
Page
201/230
-
-
-
-
