airRoxy aRid Manual Manual

EN
Manual guide
Dear Customer!
Thank you for choosing our product. We are sure that it will fulfil all your expectations. We wish
you satisfaction from your choice of the fan and its usage.
Attention
Cut off the power supply in the electrical installation before the connection.
Hammer Driller
Content of the box
aRid / pRim / pRemium / pRestige
Fan set of screws and dowels
Content of the box
Fan
Option TS/HS/MS
AC L
T
230
N
L
Phase wire
N
Neutral wire
T
Control wire
Grill disassembly
Grill disassembly
pRim / pRemium / pRestige
KLIK
Useful tools
Pencil Drill screwdriver
Guarantee
aRc
Mounting plate Guarantee
aRid HS / aRid TS
Przygotowanie otworu
aRid / pRim / pRemium / pRestige
aRid / pRim / pRemium / pRestige
It is possible to set the fan operating time on potentiometer by using a screwdriver in fans with
electrical control system (TS, HS and MS version).
TS
Timer Sensor (The fan operates from 3 to 23 minutes after switching off the light)
HS
Higro Sensor (The fan dries the room depending on chosen humidity level from
40% to 80% with precision+-20%)
MS Movement Sensor (The fan turns on depending on chosen sensitivity degree. The
sensor has the reach of 5m from the device)
Insert the wire and fasten it using the holder
Electrical connection of S
aRc / aRid / pRim / pRemium / pRestige
Electrical connection of TS, HS and MS version
pRim / pRemium / pRestige
TS\HS
L T
AC
230
N
Lid disassembly
aRid S / aRc S
Ø100/ Ø120/ Ø150
Fan installation
aRid S / aRc S
AC
230
L
N
MS
Motor
motor
