Soundcast OutCast Jr. User Manual page 7

Power on the unit by pressing the power button located on the top keypad.
A green light will first illuminate and then will change to blue. Light is located on top right side of
keypad under an antenna icon.
Power on icon
If the light does not change to blue, then the unit is not linked with the transmitter. Reset channel
switch until light changes to blue. If the channels are the same and the unit still does not link, then
try a different channel on the transmitter and reset the Outcast Junior to match new switch setting
on the transmitter. If the blue link light still does not light up, try moving the unit closer to the
transmitter until light turns blue.
Once the channel switch is selected make sure to reseat rubber cover properly into recessed
area. Not reseating the cover properly can result in water entering the switch and cause possible
unit failures.
If the source audio device is playing during time of power up, after a short delay, the audio will
automatically come on at a factory set volume level.
Keypad functions when using Outcast Junior with Soundcast transmitter.
** Play / pause and track functions will work with iPod when used with iCast transmitter. They will
also work with many PC media players when used with USB connection on UAT transmitter. Play
/ pause and track commands will not work with a MAC computer but audio will play.
Track back **
Track forward **
After either selecting the channel or using
the auxiliary input, make sure to properly
reseat the rubber cover so that it fits snug
and is flush with the outer enclosure face.
Play / Pause **
7
Antenna icon
Volume up
Volume down
Power on / off
