Item #1012 130 632
Model #KIO-02
USE AND CARE GUIDE
2-PIECE GFCI TESTER AND
DUAL-LASER INFRARED THERMOMETER KIT
Questions, problems, missing parts? Before returning to the store,
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
1-877-527-0313
HOMEDEPOT.COM
HOMEDEPOT.COM
Retain this manual for future use.
THANK YOU
We appreciate the trust and confidence you have placed in Commercial Electric through the purchase
of this home tester kit. We strive to continually create quality products designed to enhance your
home. Visit us online to see our full line of products available for your home improvement needs.
Document #: IM052524
Thank you for choosing Commercial Electric!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KIO-02 and is the answer not in the manual?

Questions and answers

Summary of Contents for Commercial Electric KIO-02

  • Page 1 Retain this manual for future use. THANK YOU We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this home tester kit. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
  • Page 2: Table Of Contents

    HOMEDEPOT.COM THANK YOU We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this infrared thermometer. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
  • Page 3: Safety Information

    Safety Information Safety Information (continued) PRECAUTIONS Please read this manual carefully and pay attention to related safe working standards before using this infrared thermometer. Protection provided by the instrument will be impaired if CAUTION: Use of controls of WARNING: Eye damage or personal used in a manner not specified by the manufacturer.
  • Page 4: Warning Label

    Safety Information (continued) Safety Information (continued) FCC COMPLIANCE STATEMENT WARNING LABEL This thermometer is designed for determining the surface temperature by measuring WARNING: This device complies with Part 15 of the FCC Rules. the amount of infrared energy radiated by the target’s surface with laser targeting. While Operation is subject to the following two conditions: this meter causes no foreseeable dangers beyond its targeting laser, the objects being (1) This device may not cause harmful interference, and...
  • Page 5: Pre-Operation

    Pre-Operation Pre-Operation (continued) PRODUCT DESCRIPTION LCD DISPLAY DEFINITIONS Part Symbol Description Hold the trigger to enter scan mode which constantly updates the temperature reading in the displaywhen aim at different objects. Buzzer-off indicator Active laser indicator Battery level indicator Data hold icon Part Name Description Temperature value indicator...
  • Page 6: Product Specifications

    Pre-Operation (continued) Pre-Operation (continued) PRODUCT SPECIFICATIONS POWER-ON MODE SELECTION □ When measuring temperature, the meter □ Install with fresh 9-volt battery, note the Component Specification continuously samples the object being correct polarity. Tighthen the battery Display LCD with display backlight measured.
  • Page 7: Mode Function Settings

    Pre-Operation (continued) Operation MODE FUNCTION SETTINGS TEMPERATURE MEASUREMENT User adjustable settings may be defined up/laser button (D) to enable or disable □ Pull and hold the trigger (B) to turn on the meter, and aim the meter to the object to by using the MODE button (C).
  • Page 8: Maintenance

    Operation (continued) Maintenance Emissivity BATTERY REPLACEMENT Emissivity is a term used to describe the energy-emitting characteristics of materials. □ In order to avoid incorrect reading, Most (90% of typical applications) organic materials and painted or oxidized surfaces have battery must change when the low an emissivity of 0.95 (pre-set in the unit).
  • Page 9 HOMEDEPOT.COM THANK YOU We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this outlet tester. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
  • Page 10 Safety Information (continued) Safety Information (continued) FCC COMPLIANCE STATEMENT PRECAUTIONS WARNING: This device complies with Part 15 of the FCC Rules. WARNING: BE EXTREMELY WARNING: Do not measure Operation is subject to the following two conditions: CAREFUL IN THE USE OF TH DEVICE. voltages exceeding the rated voltage (1) This device may not cause harmful interference, and Improper use of this device can...
  • Page 11: Product Description

    Pre-Operation Pre-Operation (continued) PRODUCT DESCRIPTION PRODUCT SPECIFICATIONS Component Specification AC voltage range 110V to 125V AC, 50/60 Hz Operating power Operating altitude < 6560 ft. (2000 m) 32°F to 104°F (0°C to 40°C), < 80% relative humidity, indoor Operating environment use only Storage environment 14°F to 122°F (-10°C to 50°C), <...
  • Page 12: Operation

    Operation (continued) Operation (continued) GFCI Receptacles INDICATOR PANEL DEFINITIONS Testing CAUTION: When testing in 2-wire (non-grounded) systems, the tester may indicate WARNING: For use on 120V outlets only. a faulty result. Do not connect to higher voltage electrical Neutral Hot supplies.
