Summary of Contents for LG LMX21986ST/03

  • Page 1 OWNER’S MANUAL FRENCH DOOR REFRIGERATOR Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. LMX21986 P.No.:MFL63264265 www.lg.com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS PRODUCT FEATURES HOW TO USE Before Use Control Panel IMPORTANT SAFETY INSTRUCTIONS - Control Panel Features In-Door Ice Bin COMPONENTS - Detaching the In-Door Ice Bin - Assembling the In-Door Ice Bin Refrigerator Exterior Automatic Icemaker Refrigerator Interior - Turning the Automatic Icemaker On or Off...
  • Page 3: Product Features

    PRODUCT FEATURES PRODUCT FEATURES * Depending on the model, some of the following functions may not be available. FILTERED WATER AND ICE DISPENSER The water dispenser dispenses fresh, chilled water. The ice dispenser dispenses cubed and crushed ice. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigera- tor door or freezer drawer remains open.
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETy INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product.
  • Page 5 IMPORTANT SAFETy INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. Do not use this product for special purposes (storage of medicine or test materials or for ships, etc). Unplug the power plug before cleaning or repairing the refrigerator.
  • Page 6 IMPORTANT SAFETy INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. CAUTION Installation The refrigerator must be properly installed in accordance with the Installer Instructions that were taped to the front of the refrigerator.
  • Page 7: Components

    COMPONENTS COMPONENTS Use this page to become more familiar with the parts and features of your refrigerator. Page references are included for your convenience. *The appearance and specifications of the actual product may differ depending on the model. Refrigerator Exterior LED Display Displays the refrigerator and freezer temperature, the water filter condi-...
  • Page 8: Refrigerator Interior

    COMPONENTS Refrigerator Interior Key Parts and Components LED Interior Lamps The interior lamps light up the inside of the refrigerator. Adjustable Refrigerator Shelf The shelves in your re- frigerator are adjustable to meet your individual storage needs. Fixed Door Bins Gallon Storage Bins Interchangeable bins that can be arranged...
  • Page 9: Special Features

    COMPONENTS Special Features Smart Diagnosis Speaker Hold your phone to this speaker when activating Smart Diagnosis. Refer to the Smart Diagnosis section for more details. SpacePlus Ice System Ice cubes are automatically produced. Crispers Controls humidity and helps vege- tables and fruit to Mullion stay crisp.
  • Page 10: Installation

    INSTALLATION INSTALLATION Specifications The appearance and specifications listed in this manual may vary due to constant product improvements. Bottom-freezer refrigerator model LMX21986 Description French door refrigerator Electrical requirements 115 VAC @ 60 Hz Min. / Max. Water pressure 20 and 120 psi (140 and 830 kPa) Dimensions 35 3/4"...
  • Page 11: Unpacking Your Refrigerator

    INSTALLATION Unpacking Your Refrigerator WARNING To reduce the risk of electric shock, do not install the refrigerator in a wet or damp area. WARNING Use two or more people to move and install the Flooring refrigerator. Failure to do so can result in back or other injury.
  • Page 12: Removing/Assembling The Refrigerator Door Handles

    INSTALLATION Removing/Assembling the Removing/Assembling the Refrigerator Door Handles Freezer Drawer Handle NOTE Removing the Handles Removing the doors is always recommended when it is necessary to move the refrigerator through a nar- Loosen the set screws located on the lower side of the row opening.
  • Page 13: Removing/Assembling The Doors And Drawers

    INSTALLATION Removing/Assembling the Doors and Drawers Removing the doors is always recommended when it is nec- essary to move the refrigerator through a narrow opening. WARNING If your entrance door is too narrow for the refrigera- tor to pass through, remove the refrigerator doors and move the refrigerator sideways through the doorway.
  • Page 14: Removing The Right Refrigerator Door

    INSTALLATION Removing the Right Refrigerator Door Assembling the Right Refrigerator Door Install the right-side door first. 1 Lower the door onto the middle hinge pin. Make sure that the plastic sleeve is inserted into 1 Open the door. Remove the top hinge the bottom of the door.
  • Page 15: Assembling The Left Refrigerator Door

    INSTALLATION Assembling the Left Refrigerator Door Install the left refrigerator door after the right door is installed. Insert the water supply tube at least 5/8 in. (15 mm) into the connector. Lower the door onto the middle hinge pin. Hook the tab on the door switch side of the cover under the edge of the wire opening in the cabinet top.
  • Page 16: Removing The Freezer Drawers

    INSTALLATION Removing the Freezer Drawers Grasp the drawer on each side and pull it up to separate it from the rails. The top, middle and bottom drawers are all removed in the same way. In the following figures, the Pullout Drawer located above the freezer drawer is not shown for clarity.
  • Page 17: Bottom Freezer Drawer

    INSTALLATION Bottom Freezer Drawer Grasp the drawer on each side and pull it up to separate it from the rails. Pull the drawer open to full extension. Remove the bas- ket by lifting the basket from the rail system. Remove the screws on both the left and right rails. With both hands, flex the center bar enough to allow the gears on both ends to release from the track.
  • Page 18: Assembling The Freezer Drawers

    INSTALLATION Assembling the Freezer Drawers Bottom Freezer Drawer To reinstall the freezer drawer, hold the center bar with both hands and pull it out until both rails are fully Top Freezer Drawer extended. To reinstall the freezer drawer, hold the center bar with both hands and pull it out until both rails are fully extended.
  • Page 19: Connecting The Water Line

    INSTALLATION Connecting the Water Line Allow the storage tank on the reverse osmosis system to refill after heavy usage. Before You Begin If the issue concerning water pressure from reverse osmosis remains, call a licensed, qualified plumber. This water line installation is not covered by the refrigerator All installations must be in accordance with local plumb- warranty.
  • Page 20: Water Line Installation Instructions

    INSTALLATION Water Line Installation Instructions NOTE WARNING Commonwealth of Massachusetts Plumbing Codes 248CMR shall be adhered to. Saddle valves are illegal When using any electrical device (such as a power and use is not permitted in Massachusetts. Consult drill) during installation, be sure the device is bat- with your licensed plumber.
  • Page 21: Turning On The Power

    INSTALLATION FLUSH OUT THE TUBING TURN THE WATER ON AT THE SHUTOFF VALVE Turn the main water supply on and Tighten any connections that leak. flush out the tubing until the water is clear. Shut the water off at the water valve after about one quart of water has been flushed through the tubing.
  • Page 22: Leveling And Door Alignment

    INSTALLATION Door Alignment Leveling and Door Alignment Leveling Both the left and right refrigerator doors have an adjustable nut, located on the bottom hinge, to raise and lower them to After installing, plug the refrigerator’s power cord into a align properly. If the space between your doors is uneven, 3-prong grounded outlet and push the refrigerator into the follow the instructions below to align the doors evenly: final position.
  • Page 23: How To Use

    HOW TO USE HOW TO USE Before Use Clean the refrigerator. Clean your refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flam- mable liquid or an abrasive when removing any tape or adhesive from the refrigerator,.
  • Page 24: Control Panel

    HOW TO USE Control Panel * Depending on the model, some of the following functions may not be available. Control Panel Features The LED Display shows the temperature settings, dispenser options, water filter, door alarm, andl ocking status mes- sages. Ice Type Press the ICE TYPE button to select either Crushed or Cubed Ice.
  • Page 25: Change Filter

    HOW TO USE Control Panel Features (continued) CAUTION Display Mode (For Store Use Only) Light The Display Mode disables all cooling in the refrigera- tor and freezer sections to conserve energy while on display in a retail store. When activated, OFF will Press the LIGHT button, to turn on the dispenser light.
  • Page 26: In-Door Ice Bin

    HOW TO USE In-Door Ice Bin Assembling the In-Door Ice Bin Carefully insert the in-door ice bin while slightly slanting it * Depending on the model, some of the following functions to avoid contact with the icemaker. may not be available. CAUTION Keep hands and tools out of the ice compartment door and dispenser chute.
  • Page 27: Automatic Icemaker

    HOW TO USE Automatic Icemaker Icemaker * Depending on the model, some of the following functions may not be available. Ice is made in the automatic icemaker and sent to the dis- penser. The icemaker will produce 70~210 cubes in a 24- hour period, depending on freezer compartment tempera- ture, room temperature, number of door openings and other operating conditions.
  • Page 28: When You Should Turn The Icemaker Off

    HOW TO USE When You Should Turn the Icemaker Off When You Should Turn the Icemaker Off Automatic Icemaker (continued) When the water supply will be shut off for several CAUTION hours. When the ice bin is removed for more than one or two The first ice and water dispensed may include particles minutes.
  • Page 29: Ice And Water Dispenser

    HOW TO USE Ice and Water Dispenser Incorrect Way Correct Way * Depending on the model, some of the following functions may not be available. Water CAUTION Keep children away from the dispenser. Children may play with or damage the controls. Dispenser Water Switch CAUTION...
  • Page 30: Storing Food

    HOW TO USE Storing Food Food Preservation Location Each compartment inside the refrigerator is designed to store different types of food. Store your food in the optimal space to enjoy the freshest taste. Dairy Product Bin Vegetable Storage (Crisper) Preserves vegetables and fruit. Adjustable Refrigerator Shelf Adjustable shelves to meet your individual Ice Storage Bin...
  • Page 31: Food Storage Tips

    HOW TO USE Storing Frozen Food Food Storage Tips * The following tips may not be applicable depending on NOTE the model. Check a freezer guide or a reliable cookbook for fur- ther information about preparing food for freezing or Wrap or store food in the refrigerator in airtight and moisture- food storage times.
  • Page 32: Humidity Controlled Crisper And Glide'n'serve

    HOW TO USE Humidity Controlled Crisper Glide’N’Serve and Glide’N’Serve The Glide’N’Serve provides storage space with a variable temperature control that can keep the compartment at a Humidity Controlled Crisper slightly different temperature than the refrigerator section. This drawer can be used for large party trays, deli items and * Depending on the model, some of the following functions beverages.
  • Page 33: Detaching And Assembling The Storage Bins

    HOW TO USE Detaching and Assembling the To Remove the Glass (Pantry drawer not shown for clarity) Storage Bins Lift up the glass under the crisper cover, and pull up and out. Glide’N’Serve and Humidity Controlled Crisper To remove the Humidity Controlled Crisper and the Glide’N’Server, pull out the Crisper and Glide’N’Server...
  • Page 34: Adjusting The Refrigerator Shelves

    HOW TO USE Adjusting the Refrigerator Shelves Using the Folding Shelf You can store taller items, such as a gallon container or bot- The shelves in your refrigerator are adjustable to meet your tles, by simply pushing the front half of the shelf underneath individual storage needs.
  • Page 35: Maintenance

    MAINTENANCE MAINTENANCE Cleaning Both the refrigerator and freezer sections defrost automatically; however, clean both sections about once a month to pre- vent odors. Wipe up spills immediately. Always unplug the refrigeration before cleaning. General Cleaning Tips Inside Walls (allow freezer to warm up so the cloth will not stick) Unplug refrigerator or disconnect power.
  • Page 36 MAINTENANCE 2.5 gallons (9 litters) 2.5 gallons (9 litters)
  • Page 37: Care And Cleaning

    MAINTENANCE Care and cleaning Performance Data Sheet Model: LG ADQ36006101-S Use Replacement Cartridge: ADQ36006101 The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system as specified in NSF/ANSI Standard 42 and Standard 53.
  • Page 38 • Read and follow. Use Instructions before installation and (24 hours per day/7 days per week) use of this system. or visit our website at www.lg.com • Installation and use MUST comply with all state and local plumbing codes. 3M is a trademark of 3M Company.
  • Page 39 MAINTENANCE State of California Department of Public Health Water Treatment Device Certificate Number 09 - 2018 Date Issued: December 15, 2009 Trademark/Model Designation Replacement Elements ADQ36006101-S ADQ36006101 Manufacturer: Cuno Inc. The water treatment device(s) listed on this certificate have met the testing requirements pursuant to Section 116830 of the Health and Safety Code for the following health related contaminants: Microbiological Contaminants and Turbidity Inorganic/Radiological Contaminants...
  • Page 40: Smart Diagnosis

    1-800-243-0000. Only use the Smart Diagnosis feature when Keep the phone in place until the tone transmission has instructed to do so by the LG call center agent. The transmis- finished. This takes about 15 seconds, and the display will sion sounds that you will hear are normal and sound similar count down the time.
  • Page 41: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING Review the Troubleshooting section before calling for service; doing so will save you both time and money. Problem Possible Causes Solutions Refrigerator and Freezer The refrigerator control is set to OFF (some Turn the control ON. Refer to the Setting the section are not cooling.
  • Page 42 TROUBLESHOOTING Problem Possible Causes Solutions Refrigerator or Freezer Refrigerator was recently installed. It may take up to 24 hours for each compartment to section is too warm. reach the desired temperature. Air vents are blocked. Rearrange items to allow air to flow throughout the compartment.
  • Page 43 TROUBLESHOOTING Problem Possible Causes Solutions Food is freezing Food with high water content was placed Rearrange items with high water content away from in the refrigerator near an air vent. air vents. compartment. Refrigerator temperature control is set If the temperature is too cold, adjust the control one incorrectly.
  • Page 44 TROUBLESHOOTING Problem Possible Causes Solutions Icemaker is not making Doors are opened often or for long periods If the doors of the unit are opened often, ambient enough ice (continued). of time. air will warm the refrigerator which will prevent the unit from maintaining the set temperature.
  • Page 45 TROUBLESHOOTING Problem Possible Causes Solutions Icemaker is not making Refrigerator was recently installed or It may take up to 24 hours for each compartment to ice. icemaker recently connected. reach the desired temperature and for the icemaker to begin making ice. Icemaker not turned on.
  • Page 46 TROUBLESHOOTING Problem Possible Causes Solutions Ice has bad taste or odor. Water supply contains minerals such as A water filter may need to be installed to eliminate sulfur. taste and odor problems. NOTE: In some cases, a filter may not help. It may not be possible to remove all minerals / odor / taste in all water supplies.
  • Page 47 TROUBLESHOOTING Problem Possible Causes Solutions Clicking The defrost control will click when the Normal Operation automatic defrost cycle begins and ends. The thermostat control (or refrigerator control on some models) will also click when cycling on and off. Normal Operation Rattling Rattling noises may come from the flow of refrigerant, the water line on the back of the...
  • Page 48 TROUBLESHOOTING Problem Possible Causes Solutions Doors will not close Food packages are blocking the door open. Rearrange food containers to clear the door and door correctly or pop open. shelves. Ice bin, crisper cover, pans, shelves, door Push bins all the way in and put crisper cover, pans, bins, or baskets are out of position.
  • Page 49: Warranty

    Should your LG Refrigerator (“Product”) fail due to a defect in materials or workmanship under normal home use, during the warranty period set forth below, LG will at its option repair or replace the product. This limited warranty is valid only to the original retail purchaser of the product and applies only when purchased and used within the United States including U.S.
  • Page 50: Warranty (Canada)

    WARRANTY: Should your LG Refrigerator (“Product”) fail due to a defect in material or workmanship under normal home use during the warranty period set forth below, LG Canada will at its option repair or replace the Product upon receipt of proof of original retail purchase. This warranty is valid only to the original retail purchaser of the product and applies only to a Product distributed in Canada by LG Canada or an authorized Cana- dian distributor thereof.
  • Page 53: Manual Del Propietario

    MANUAL DEL PROPIETARIO REFRIGERADOR DE PUERTA FRANCES Lea este manual de usuario detenidamente antes de la utilización y guárdelo a mano para futuras consultas. LMX21986 ** www.lg.com P/NO : MFL63264265...
  • Page 54 ÍNDICE ÍNDICE CARACTERÍSTICAS DEL PRODUCTO INSTRUCCIONES DE USO Antes de usar Panel de control INSTRUCCIONES IMPORTANTES SO- - Funciones del panel de control BRE SEGURIDAD Uso del depósito de hielo del interior de la puerta - Desmontaje del depósito de hielo del interior de COMPONENTES la puerta - Montaje del depósito de hielo del interior de la...
  • Page 55: Características Del Producto

    CARACTERÍSTICAS DEL PRODUCTO CARACTERÍSTICAS DEL PRODUCTO * Dependiendo del modelo, algunas de las siguientes funciones podrán no estar disponibles. AgUA FILTRADA y DISPENSADOR DE hIELO El dispensador de agua dispensa agua fresca y helada. El dispensador de hielo dispensa hielo picado y en cubos.
  • Page 56: Instrucciones Importantes Sobre Seguridad

    INSTRUCCIONES IMPORTANTES SOBRE SEgURIDAD INSTRUCCIONES IMPORTANTES SOBRE SEGURIDAD LEA TODAS LAS INSTRUCCIONES ANTES DE USAR ESTE ELECTRODOMÉSTICO. Este manual contiene muchos mensajes de seguridad importantes. Lea y cumpla siempre todos los mensajes de seguridad. Éste es el símbolo de alerta de seguridad. Le avisa de mensajes de seguridad que le informan de peligros de muerte o lesiones para usted o los demás, o que puedan dañar el producto.
  • Page 57 INSTRUCCIONES IMPORTANTES SOBRE SEgURIDAD LEA TODAS LAS INSTRUCCIONES ANTES DE USAR ESTE ELECTRODOMÉSTICO. Para reducir el riesgo de incendio, descarga eléctrica o lesiones personales al utilizar el producto, se deben respetar una serie de precauciones de seguridad básicas, entre las que se incluyen las siguientes: No utilice este producto para fines especiales (almacenamiento de medicamentos o materiales de prueba o de transporte, etc.).
  • Page 58 INSTRUCCIONES IMPORTANTES SOBRE SEgURIDAD LEA TODAS LAS INSTRUCCIONES ANTES DE USAR ESTE ELECTRODOMÉSTICO. Para reducir el riesgo de incendio, descarga eléctrica o lesiones personales al utilizar el producto, se deben respetar una serie de precauciones de seguridad básicas, entre las que se incluyen las siguientes: PRECAUCIóN Instalación El refrigerador se debe instalar correctamente de acuerdo con las instrucciones para el instalador incluidas en la hoja adhe-...
  • Page 59: Exterior Del Refrigerador

    COMPONENTES COMPONENTES Use esta página para familiarizarse con los componentes y características del refrigerador. Para su comodidad, se incluyen refe- rencias a las páginas. *La apariencia y especificaciones del producto real pueden cambiar dependiendo del modelo. Exterior del refrigerador Visor LED Muestra la temperatura del re- frigerador y del congelador, las condiciones del filtro de agua y...
  • Page 60: Interior Del Refrigerador

    COMPONENTES Interior del refrigerador Piezas y componentes clave Lámparas interiores LED Las lámparas interiores iluminan el interior del refrigerador. Estante ajustable del refrigerador Los estantes del refri- gerador son ajustables para satisfacer sus Bandejas necesidades personales de almacenamiento. puerta fijas Depósitos de ga- lones Las bandejas inter-...
  • Page 61: Características Especiales

    COMPONENTES Características especiales Altavoz de diagnóstico inteli- gente Mantenga su teléfono hacia el al- tavoz mientras activa el Diagnóstico Inteligente. Consulte la sección "Di- agnóstico Inteligente" para obtener mayores detalles. Sistema SpacePlus Los cubos de hielo se producen automáticamente. Cajones para verduras Controla la hume- dad y ayuda a man-...
  • Page 62: Especificaciones

    INSTALACIóN INSTALACIóN Especificaciones La apariencia y especificaciones contenidas en ete manual puden variar debido a las contantes mejoras realizadas en el producto Refrigerador con congelador inferior modelo LMX21986 Descripción Refrigerador con puerta francesa Requisitos eléctricos 115 VAC @ 60 Hz Presión de agua mínima/ máxima 20 y 120 psi (140 y 830 kPa) Dimensiones...
  • Page 63: Desembalaje Del Refrigerador

    INSTALACIóN Desembalaje del refrigerador ADVERTENCIA ADVERTENCIA Para reducir el riesgo de descarga eléctrica, no instale el refrigerador en un área húmeda ni mojada. El desplazamiento e instalación del refrigerador deben realizarse entre dos o más personas. Si no Tipo de piso se respeta esta advertencia, se podrán producir lesiones en la espalda o de otro tipo.
  • Page 64: Montaje Y Desmontaje De Las Manijas De La Puerta Del Refrigerador

    INSTALACIÓN Montaje y desmontaje de las manijas Montaje y desmontaje de la manija de la puerta del refrigerador del cajón del congelador NOTA Siempre se recomienda desmontar las puertas cuando Desmontaje de las manijas sea necesario desplazar el refrigerador a través de un espacio estrecho.
  • Page 65: Desmontaje De La Puerta Izquierda Del Refrigerador

    INSTALACIóN Montaje y desmontaje de las puertas y cajones Siempre se recomienda desmontar las puertas cuando sea necesario desplazar el refrigerador a través de un espacio estrecho. ADVERTENCIA Si supuerta de entrada es demasiado estrecha para que pase el refrigerador, retire las puertas del refrigera- dor y páselo de costado a través de la puerta.
  • Page 66: Desmontaje De La Puerta Derecha Del Refrigerador

    INSTALACIóN Desmontaje de la puerta derecha del re- Montaje de la puerta derecha del refrigera- frigerador Instale primero la puerta del lado derecho. Abra la puerta. Retire el tornillo de la tapa de la bisagra superior (1). Levante la tapa (2). Retire la tapa.
  • Page 67: Montaje De La Puerta Izquierda Del Refrigerador

    INSTALACIóN Montaje de la puerta izquierda del refrig- erador Instale la puerta izquierda del refrigerador luego de instalar la puerta derecha. Inserte el tubo de suministro de agua al menos 15 mm. ( 5/8 pulg.) en el conector. 0 Enganche la pestaña situada en el lado del interruptor de la puerta de la tapa debajo del borde de la apertura para Baje la puerta hacia el pasador de la bisagra central.
  • Page 68 INSTALACIóN Cómo extraer los cajones del conge- Sujete el cajón de cada lado y tire de él hacia arriba para lador separarlo de los rieles. Todos los cajones superior, medio e inferior se retiran del mismo modo. En las figuras siguientes, no se muestra el cajón extraíble situado por encima del cajón del congelador para que la imagen sea más clara.
  • Page 69 INSTALACIóN Cajón inferior del congelador Sujete el cajón de cada lado y tire de él hacia arriba para separarlo de los rieles. Saque el cajón hacia afuera todo lo posible. Retire la cesta levantándola del sistema de rieles. Con las dos manos, flexione el centro de la barra lo Quite los tornillos de ambos lados, derecho e izquierdo, suficiente para permitir que los mecanismos de ambos de los rieles.
  • Page 70 INSTALACIóN Cómo ensamblar los cajones del Cajón inferior del congelador congelador Para volver a instalar el cajón del freezer, sostenga la barra central con ambas manos y tire hacia afuera hasta que los Cajón superior del congelador dos rieles estén extendidos por completo. Para volver a instalar el cajón del freezer, sostenga la barra central con ambas manos y tire hacia afuera hasta que los dos rieles estén extendidos por completo.
  • Page 71: Presión Del Agua

    INSTALACIóN Conexión de las tuberías de agua Después de un uso intensivo, dele tiempo al depósito de almacenamiento del sistema de ósmosis inversa para que Antes de empezar se llene. Si el problema relacionado con la presión de agua proce- dente de la ósmosis inversa persiste, llame a un fontanero Esta instalación de la tubería de agua no está...
  • Page 72: Instrucciones Para La Instalación De La Tubería De Agua

    INSTALACIóN NOTA Instrucciones para la instalación de la tubería de agua Se deben cumplir con los Códigos de Fontanería 248CMR del Estado de Massachusetts. Las válvulas ADVERTENCIA de montura son ilegales y no se permite su uso en Massachusetts. Consulte a su fontanero autorizado. Si usa un dispositivo eléctrico (como un taladro) durante la instalación, asegúrese de que esté...
  • Page 73 INSTALACIóN DEJE CORRER AGUA POR LA TUBERÍA. ABRA EL PASO DE AGUA EN LA VÁLVULA DE CORTE. Ajuste las conexiones que goteen. Active el suministro de agua prin- cipal y deje correr el agua por la tubería hasta que salga agua limpia. Corte la válvula de agua después de que haya pasado aproximadamente un litro de agua a través de la tu-...
  • Page 74: Alineación De Las Puertas

    INSTALACIóN Alineación de las puertas Nivelación y alineación de las puertas Ambas puertas del refrigerador tienen una tuerca ajustable, Nivelación ubicada en la bisagra inferior, que pueden levantarse y ba- jarse para alinearlas correctamente. Si el espacio entre las puertas no es parejo, siga estas instrucciones para alinear las Tras la instalación, enchufe el cable de alimentación del re- puertas de manera uniforme: frigerador en una toma de corriente de 3 patas con conexión...
  • Page 75: Instrucciones De Uso

    INSTRUCCIONES DE USO INSTRUCCIONES DE USO Antes de usar Limpie el refrigerador. Limpie el refrigerador a fondo y quite todo el polvo acumulado durante el transporte. PRECAUCIóN No raye el refrigerador con ningún objeto filoso, tampoco utilice detergentes que contengan alcohol, líquidos inflamables, ni abrasivos para sacar cualquier cinta o adhesivo del refrigerador.
  • Page 76: Funciones Del Panel De Control

    INSTRUCCIONES DE USO Panel de control * Dependiendo del modelo, algunas de las siguientes funciones podrán no estar disponibles. Funciones del panel de control La pantalla LED muestra los ajustes de temperatura, op- ciones del dispensador, filtro de agua, alarma de la puerta, y mensajes del estado de bloqueo.
  • Page 77: Cambio De Filtro

    INSTRUCCIONES DE USO Funciones del panel de control PRECAUCIóN (continuación) Modo exposición (sólo para uso en tienda) El Display Mode (modo exposición) desactiva toda la refrigeración en las secciones refrigerador y congela- dor para ahorrar energía mientras el electrodoméstico está en exposición en una tienda. Cuando se activa, Presione el botón LIGHT para encender la luz del dispensa- OFF (apagado) aparece en el panel de control.
  • Page 78: Montaje Del Depósito De Hielo Del Interior De La Puerta

    INSTRUCCIONES DE USO Uso del depósito de hielo del inte- rior de la puerta Para extraer el depósito de hielo del interior de la puerta, agarre la manija delantera, levante ligeramente la parte * Dependiendo del modelo, algunas de las siguientes fun- inferior y despacio saque el depósito tal como se muestra ciones podrán no estar disponibles.
  • Page 79: Encendido Y Apagado De La Máquina De Hielo Automática

    INSTRUCCIONES DE USO Máquina de hielo automática Máquina de hielo * Dependiendo del modelo, algunas de las siguientes fun- ciones podrán no estar disponibles. El dispensador de hielo producirá 70~210 cubitos en un periodo de tiempo de 24 horas, en función de la temperatura del congelador, de la temperatura ambiente, del número de puerta abiertas y otras condiciones de funcionamiento.
  • Page 80: Sonidos Normales Que Se Pueden Escuchar

    INSTRUCCIONES DE USO Cuándo Debería Ajustar La Máquina De Máquina De Hielo Automática Hielo Interruptor De Alimentación En (continuación) Posición Off (apagado) PRECAUCIÓN Cuando el suministro de agua vaya a ser interrumpido durante varias horas. La primera tanda de hielo y agua dispensada podría in- cluir partículas y olor procedente de la tubería de sumi- Cuando se retire el depósito de hielo durante más de nistro de agua o del depósito de agua.
  • Page 81: Dispensador De Hielo Y Agua

    INSTRUCCIONES DE USO Dispensador de hielo y agua Manera incorrecta Manera correcta * Dependiendo del modelo, algunas de las siguientes fun- ciones podrían no estar disponibles. Agua PRECAUCIóN No permita que los niños utilicen el dispensador. Los niños podrían jugar con los controles y romperlos. Estructura del dispensador Hielo Interruptor de agua...
  • Page 82: Almacenamiento De Alimentos

    INSTRUCCIONES DE USO ALMACENAMIENTO DE ALIMENTOS Lugar de conservación de los alimentos Cada compartimento en el interior del refrigerador está diseñado para almacenar diferentes tipos de alimentos. Almacene sus alimentos en un espacio óptimo para disfrutar la máxima frescura del sabor. Depósito para productos diarios Almacenamiento de verduras (Cajón para verduras)
  • Page 83: Almacenamiento De Alimentos Congelados

    INSTRUCCIONES DE USO Sugerencias para el almacenamiento de Almacenamiento De Alimentos alimentos Congelados NOTA * Dependiendo del modelo, las siguientes sugerencias podrían no ser aplicables. Consulte una guía de congelación o un libro de cocina Envuelva o almacene los alimentos en el refrigerador dentro fiable para obtener más información sobre la forma de de materiales herméticos y antihumedad, a menos que se preparar los alimentos para su congelación o sobre los...
  • Page 84: Cajón Para Verduras Con Control De Humedad

    INSTRUCCIONES DE USO Cajón para verduras con control de Glide‘N’Serve humedad y Glide'N'Serve El compartimiento Glide'N'Serve proporciona un espacio de Cajón para verduras con control de hume- almacenamiento con control de temperatura variable que puede mantener el compartimiento a una temperatura leve- mente diferente de la temperatura de la sección del refrig- erador.
  • Page 85 INSTRUCCIONES DE USO Montaje y desmontaje de las bande- Para retirar el vidrio (Para mayor claridad, no se muestra el cajón) jas de almacenamiento Levante el vidrio debajo del cajón para verduras y tire hacia Glide'N'Serve y Cajón para verduras con arriba y hacia afuera.
  • Page 86: Ajuste De Los Estantes Del Refrigerador

    INSTRUCCIONES DE USO Ajuste de los estantes del refrigera- Uso del estante plegable Para almacenar artículos más altos, como botellas o garrafas, empuje la mitad delantera del estante para que se deslice de- Los estantes del refrigerador son ajustables para satisfacer bajo de la mitad posterior del estante.
  • Page 87: Mantenimiento

    MANTENIMIENTO MANTENIMIENTO Limpieza Tanto las secciones refrigerador como congelador se descongelan de forma automática; sin embargo, se recomienda limpiar ambas secciones una vez al mes para evitar la aparición de olores. Seque los derrames inmediatamente. Desenchufe siempre el refrigerador antes de limpiar. Paredes interiores (deje que el congelador pierda Sugerencias generales de limpieza el frío para que el trapo no se quede pegado)
  • Page 88 MANTENIMIENTO 2.5 litros (9 litters) 2.5 litros (9 litters)
  • Page 89: Hoja De Datos De Rendimiento

    MANTENIMIENTO Hoja de datos de rendimiento Modelo: LG ADQ36006101-S Utilice un recambio de cartucho: ADQ36006101 La concentración de las sustancias indicadas en el agua que entra en el sistema se redujo a una concentración menor o igual al límite permisible para el agua de salida según las especificaciones de los estándares NSF/ANSI 42 y 53.
  • Page 90 (24 horas al día/7 días por semana) kPa). Si la presión del agua excede las 80 psi (552 kPa) o visite nuestro sitio web en www.lg.com debe usted instalar una válvula limitadora de presión. Contrate a un plomero profesional si no tiene la seguridad 3M es una marca comercial de 3M Company.
  • Page 91 MANTENIMIENTO State of California Department of Public Health Water Treatment Device Certificate Number 09 - 2018 Date Issued: December 15, 2009 Trademark/Model Designation Replacement Elements ADQ36006101-S ADQ36006101 Manufacturer: Cuno Inc. The water treatment device(s) listed on this certificate have met the testing requirements pursuant to Section 116830 of the Health and Safety Code for the following health related contaminants: Microbiological Contaminants and Turbidity Inorganic/Radiological Contaminants...
  • Page 92 En caso de experimentar algún problema con su refrigera- dor, podrá transmitir datos a través de su teléfono al centro de servicios de LG. Éste le otorgará la posibilidad de hablar directamente con nuestros técnicos especialistas. El técnico graba los datos transmitidos desde su máquina y los utiliza para analizar el problema, ofreciendo un diagnóstico rápido y...
  • Page 93: Solución De Problemas

    SOLUCIóN DE PROBLEMAS SOLUCIóN DE PROBLEMAS Consulte la sección de "Solución de problemas" antes de llamar al servicio técnico. Esto le ahorrará tiempo y dinero. Problema Causas posibles Soluciones Las secciones del El control del refrigerador está en la posición Encienda el control.
  • Page 94 SOLUCIóN DE PROBLEMAS Problema Causas posibles Soluciones La sección del El refrigerador se instaló recientemente. Puede tomar hasta 24 horas para que cada REFRIGERADOR o del compartimiento alcance la temperatura deseada. CONGELADOR está Los conductos de ventilación del aire están Reorganice los artículos dentro del electrodoméstico demasiado caliente.
  • Page 95 SOLUCIÓN DE PROBLEMAS Problema Causas posibles Soluciones Los alimentos se congelan Alimentos con alto contenido de agua fueron Reubique los alimentos con alto contenido de agua lejos en el compartimiento del colocados cerca de la ventilación de aire. de las ventilaciones de aire. refrigerador.
  • Page 96 SOLUCIóN DE PROBLEMAS Problema Causas posibles Soluciones La máquina de hielo no Las puertas se abren seguido o por largos Si las puertas de la unidad se abren a menudo, el aire hace suficiente hielo períodos de tiempo. ambiental calentará el refrigerador e impedirá que la (continuación).
  • Page 97 SOLUCIóN DE PROBLEMAS Problema Causas posibles Soluciones La máquina de hielo no El refrigerador se instaló recientemente o la Puede tomar hasta 24 horas para que cada hace hielo. máquina de hielo se conectó recientemente. compartimiento alcance la temperatura deseada y para que la máquina de hielo comience a fabricar hielo.
  • Page 98 SOLUCIóN DE PROBLEMAS Problema Causas posibles Soluciones El hielo huele o sabe mal. El suministro de agua contiene minerales Es posible que deba reemplazar el filtro de agua para tales como el azufre. eliminar los problemas de olor y sabor. NOTA: En algunos casos, un filtro podría no ser de ayuda.
  • Page 99 SOLUCIóN DE PROBLEMAS Problema Causas posibles Soluciones Clics El control de descongelación emitirá un Funcionamiento normal. “clic” al comenzar y al finalizar el ciclo de descongelación. El control del termostato (o control del refrigerador en algunos modelos) también emitirá un “clic” al iniciar o finalizar un ciclo.
  • Page 100 SOLUCIóN DE PROBLEMAS Problema Causas posibles Soluciones Las puertas no se cierran Hay paquetes de alimentos bloqueando la Reorganice los envases de alimentos para liberar la completamente o quedan puerta que impiden que se cierre. puerta y los estantes de la puerta. abiertas.
  • Page 101: Garantía (Ee.uu.)

    En caso de que su refrigerador LG (el “Producto”) presente alguna falla por defectos de materiales o de fabricación bajo uso personal normal durante el período de garantía establecido más abajo, el mismo será reparado o reemplazado por LG, a su opción. Esta garantía limitada es válida únicamente para el comprador consumidor final original del producto, y únicamente aplica para el Producto comprado y utilizado dentro de los...
  • Page 102: Garantía (Canadá)

    GARANTÍA (CANADá) En caso de que su refrigerador LG (el “Producto”) presente alguna falla por defectos de materiales o de fabricación bajo uso personal normal durante el período de garantía establecido más abajo, el mismo será reparado o reemplazado por LG, a su opción, previa presentación del recibo o factura original de compra.
  • Page 104: Register Your Product Online

    LG Customer Information Center For inquires or comments, visit www.lg.com or call; 1-800-243-0000 USA, Consumer User 1-888-865-3026 USA, Commercial User 1-888-542-2623 CANADA Register your product Online! www.lg.com...
