SEAUTO CRAB Manual

STRUCTURE

SPECIFICATIONS

LED STATUS

LED Color	State	LED Display
Blue	Initialisation phase	Flashes once per second
	Standby	Flashes once per 3 seconds
	Working	Solid
Yellow	Device Malfunction	Flashes once per second
Red	Low battery	Flashes once per second
	Charging	Solid
Green	Fully charged	Solid
Purple	Failure to get out of trouble	Solid

CLEANING MODES & APP

Search "Unlock SEAUTO" on either Google play or the App store.
Turn on Bluetooth on your phone, then power on the cleaner. Ensure your phone is close to the cleaner for optimal connection.
Once connected to the app, you can easily switch between the 3 Clean Modes using the app or by simply pressing the on/off button on the cleaner.

Note:

1. You can cycle through the cleaning modes by pressing the power button.
2. The device will announce the current mode selected.
3. The default mode upon turning on the cleaner is All-Cover mode.

USING THE POOL CLEANER

CHARGING

1. Plug the power supply into the robot to begin charging. The LED indicator will turn solid red to indicate charging.

2. The LED indicator will turn solid green when the device is fully charged and will automatically turn off after 10 minutes.


Please charge the device indoors to protect the charger from water damage and sunlight exposure.

PLACING INTO THE POOL

ALL-COVER MODE
Note: Once turned on, the cleaner will automatically start cleaning the entire pool, walls and waterline first, then the floor.

1. When the cleaner is first turned on, you'll hear a voice prompt saying, "Welcome to the Seauto pool cleaning robot. I'm ready to work," and the LED light will flash blue.

2. Place the device in the pool, ensuring the water level is above the top of the cleaner for optimal performance. The LED light will turn solid blue, indicating that the cleaning process has begun.


RETRIEVING FROM THE POOL

Note: Please attach the included retrieval hook to a compatible telescopic pool pole (not included).

1. Hook the cleaner's handle with the retrieval hook and pull it out of the water.

2. Before cleaning the filter, press and hold the power button to turn off the cleaner.


CLEANING

Note: Clean the filter basket before debris dries out. Ensure the cleaner is turned off.

1. Unbuckle both sides of the filter basket to open the lid.

2. Remove the filter basket.

3. Unlatch the cap of the basket.

4. Clean the filter basket.

5. Reassemble once everything is dry.


REPLACING THE BATTERY

Note: Before replacing the battery, leave the cleaner idle for 2 days to ensure complete moisture evaporation. This will help maintain optimal battery performance.
Follow the steps below to replace the battery and restore your pool cleaner to optimal performance:

1. Remove all six Phillips-head screws securing the battery, then take out the old battery.

2. Insert the new battery, aligning the contact points with the battery cavity. The battery should sit flush with the body when correctly installed.
   Note: Before installing a new battery, ensure the contact points are clean and free of water droplets, sand, or other debris.

3. Secure the battery by fastening all six Phillips-head screws.


OFF-SEASON STORAGE

If you won't be using your pool cleaner for an extended period of time, please follow these steps for storage

1. Make sure that no water is left in the pool cleaner.
2. Thoroughly clean the filter basket and securely reinstall it.
3. Store the pool cleaner in a sheltered area away from direct sunlight, rain, or frost, at a temperature between 5°Cand 45°C.
4. Charge the pool cleaner once a month to maintain peak battery health.

TROUBLE-SHOOTING & FAQ

If the following solutions do not resolve your issue, please contact us for further assistance.

Q: Applicable swimming pool size?
A: Up to 150m2.

Q: Why doesn't the cleaner respond after pressing the power button?
A: The battery might be depleted due to extended storage. Please recharge the device. The indicator light will display solid red while charging.

Q: Why can't it climb the walls?
A:

1. It may be set to Floor-Only Mode. Please select the correct mode for wall climbing.
2. The filter basket may be clogged with debris. Please remove and clean the basket to ensure optimal performance.

Q: Why is the cleaner sitting at the bottom of the pool and not moving, or moving slowly?
A:

1. The cleaner may be caught in the drain outlet at the bottom of the pool. It will attempt to float and free itself. If it remains stuck for several minutes, please use your pool pole to assist in freeing it.
2. If placed in a dirty pool, the cleaner may collect a large amount of debris quickly. In this case, check and clean the filters as needed.

Q: Why does the front of the robot float up while the rear remains on the floor?
A: This is an intelligent feature of the pool cleaner, designed to help it break free if it gets stuck.

Q: Why does the cleaner automatically turn off after a few hours of charging?
A: It is designed to automatically shut off 10 minutes after reaching a full charge to protect the battery and extend its lifespan. You can feel confident leaving it unattended, knowing that charging safety is ensured.

Q: What does it mean when the cleaner's LED indicator displays yellow?
A: The yellow light indicates the cleaner has encountered an issue, such as an overcurrent due to being stuck or a failure to start. Simply remove the cleaner, restart it, and it should be ready to work.

Q: How can I purchase replacement parts and accessories?
A: Please contact the retailer where you made your purchase. Alternatively, you can visit our website or call us directly, and we'll be happy to assist you.

Q: How can I purchase a telescopic pool pole, and what size should I choose?
A: The retrieval hook included in the box is designed to connect to a universal telescopic pool pole. The hook fits poles with a standard 1-1/4" (25-32 mm) diameter connector end. These poles are commonly available at your local pool shop or from online retailers.

Q: Why are there some water droplets inside a newly purchased cleaner?
A: As every cleaner is rigorously tested before leaving the factory, including underwater tests, thus there may be a little water left inside, feel free to use it normally.

Q: What does it mean when the cleaner's LED indicator displays purple?
A: If the LED displays purple, it means the cleaner is stuck on an obstacle. Use a pole to remove it, restart the cleaner, and then place it back in the pool to continue cleaning.

Q: Why can't I turn off the cleaner after removing it from the pool?
A: The cleaner may still think it's underwater due to water on the detection probe. Simply wipe it dry and you should be able to turn off the cleaner.

Please read this manual carefully and use the device accordingly. We are not liable for any loss or injury caused by the improper use of the device.

1. Make sure to fully charge the device before using it for the first time.
2. To ensure optimal cleaning performance, make sure the water depth of the pool is at least 50 cm from the top of the device.
3. The device contains a lithium battery. Do not attempt to disassemble the sealed battery compartment. Keep the device away from direct sunlight and impacts.
4. For safety reasons, please keep people and animals out of the pool while the device is in use. Children should always be supervised around the pool.
5. Please turn off the device before cleaning the filters.
6. To maintain peak battery health during the off-season, please charge the device once a month.
7. Please use the Pool Cleaner only in the following water conditions:

   Chlorine	Max 4 PPM
   pH	7.0 - 7.8 PPM
   Temperature	5 - 35°C
   NaCl	Maximum = 5000 PPM
