Summary of Contents for imilab EC5
- Page 1 IMILAB EC5 Floodlight Camera User Manual Scan the QR code for the tutorial on how to use the camera. Please read this manual carefully before using the device and retain it for future reference.
-
Page 2: Product Introduction
Product Introduction Package List IMILAB EC5 Floodlight Camera Power adapter Wall mounting pack Mounting sticker Waterproof kit User manual Product Appearance Floodlight Lens Speaker Ethernet Indicator port Reset light Power port MicroSD card slot... -
Page 3: Connect To Power Source
Connect to Power Source Power On Insert the power supply cable into the camera's power supply port. Note: Do not twist the camera’s dome to force it to rotate after it is turned on. If the lens positioning is inaccurate, calibrate it with the app. Indicator Light Solid green: Successful connection/normal status Flashing green: Waiting for connection/network exception... -
Page 4: Installing The Device
Smart home room home Sh Smart home room home Sh Scan 28° 28° Manual controls room room Open Open IMILAB C30 Dual Home Security Camera IMILAB C30 Dual Home Security Camera Automation Mi Home Smart Products Store Profile Mi Home Smart... - Page 5 Note: 1.The MicroSD card needs to be purchased separately. The camera can be used without a MicroSD card. 2.When inserting or removing the MicroSD card, please disconnect the camera from the power supply. Use a MicroSD card from a reputable manufacturer (up to 256GB).
- Page 6 • Ceiling mounting 1. Attach the ceiling mounting positioning sticker on the desired installa- tion location on the ceiling. Drill two holes at the positions indicated on the sticker. The drilling diameter should be around 6.0 mm with a depth of around 30 mm.
-
Page 7: Basic Parameters
Please follow the instructions. Using a waterproofing sleeve on the LAN port Basic Parameters Product name: IMILAB EC5 Floodlight Camera Dimension: 139 x 128 x 135 mm Model: CMSXJ55A Net weight: 680 g Power input: 12V Video code: H.265... -
Page 8: Fcc Statement
• Please ensure that the device is within Wi-Fi signal coverage. Place it at a location with good Wi-Fi signal strength. • Try to avoid placing the device near a metallic object, a microwave oven or other objects that may cause signal interference. •... -
Page 9: Weee Information
The full Declaration of Conformity can be found at https://www.imilabglobal.com/pages/psti-declaration. For any issues, please contact us at help@imilab.com or submit the Issue Feedback Form via the link above. - Page 10 California to cause cancer. For more information, go www.P65Warnings. ca. gov. Manufacturer: Shanghai Imilab Technology Co., Ltd. Address: Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang District, Shanghai, China For further information, please go to www.imilabglobal.com.
