PRODUCT MANUAL
v2022.09.29
MODEL:TMG-GSB34
34" SELF-PROPELLED
GAS-POWERED SNOW BLOWER
375CC LECTRIC START
Please read and understand the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TMG-GSB34 and is the answer not in the manual?

Questions and answers

Related Manuals for TMG TMG-GSB34

Summary of Contents for TMG TMG-GSB34

  • Page 1 PRODUCT MANUAL v2022.09.29 MODEL:TMG-GSB34 34” SELF-PROPELLED GAS-POWERED SNOW BLOWER 375CC LECTRIC START Please read and understand the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Do not return the product to dealer.

  • Page 2: Table Of Contents

    Table of Contents Important Safety Information..................................3 Products Specifications ....................................5 Products Parts Identification..................................5 Unpacking and Setup..............................6 Assembly................................6 Filling with Gasoline and Oil....................................8 Operation Precautions....................................9 Operation Controls.......................................10 Operation......................................11 Maintenance.....................................13 Engine Troubleshooting....................................21 Snow Blower Troubleshooting..................................22 Storage..................................24 Part Diagrams and Parts List..................................25 www.tmgindustrial.com 02/35 Toll Free:1-877-761-2819...

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION WARNING: Read and thoroughly understand all instructions and safety information before operating this Snow blower. Failure to do so may cause serious injury or death. Do not allow anyone to operate this Snow blower who has not read this manual. As with all power equipment, a snow blower can be dangerous if used improperly;...
  • Page 4 Safety labels on the snow blower are to remind you of important information while you are operating the unit. Make sure all safety warning decals are attached and in readable condition. Replace missing or defaced decals. Contact TMG Industrial at 1-877-761-2819 for replacement decals. www.tmgindustrial.com 04/35...

  • Page 5: Products Specifications

    PRODUCTS SPECIFICATIONS Model No. TMG-GSB34 Operating width 34 inch Intake height 21 inch Throwing distance 50 feet Transmission 6 forward speeds and 2 reverse speeds Auger diameter 15” Chute rotation 190° turning radius on console Power and type 375CC single cylinder, air cooled, 4-sroke, OHV...

  • Page 6: Unpacking And Setup

    UNPACKING AND SETUP Your snow blower requires some assembly; Save the packing materials and box for future use as a storage container. COMPLETELY READ AND UNDERSTAND THE OPERATORS MANUAL BEFORE ATTEMPTING TO OPERATE THE SNOW BLOWER. Assembly Handlebar and Shift Control Assembly Fig 1 Nylon Lock Nut Carriage...
  • Page 7 6. Attach the wire harness for heated handle control to the Chute harness coming off of the engine. Direction Control Handle Control Cable Fig 6 Attaching the Shift Lever Handles 1. Thread the shift lever handles on to the shift lever rods, one for the speed shift and one for the discharge height control.

  • Page 8: Filling With Gasoline And Oil

    Filling with Gasoline and Oil WARNING: FUEL IS HIGHLY FLAMMABLE AND POISONOUS ALWAYS FILL THE TANK WITH ENGINE OFF AND COOL. ALWAYS CHECK THE FUEL LEVEL BEFORE OPERATING. Allow the engine to cool for at least two minutes before removing the fuel cap. 1.

  • Page 9: Operation Precautions

    Operation Precautions DANGER: COMPLETELY READ AND UNDERSTAND THIS MANUAL BEFORE ATTEMPTING TO OPERATE THE SNOW BLOWER 1. Keep all safety guards in place and in proper working order at all times. 2. NEVER place fingers, hands, or body near the snow blower when it is running. Do not lean or reach over the snow blower when the machine is running.

  • Page 10: Operation Controls

    Operation Control Fig 10 Auger Shift Lever Drive Control Lever Control Lever Chute Height Control Chute Direction Control Shift Lever The shift lever controls the direction of travel and ground speed. There are six forward speeds. Position one (1) is the slowest and position six (6) is the fastest.

  • Page 11: Operation

    OPERATION CAUTION: FILL WITH OIL BEFORE STARTING Make sure the auger control and drive control are in the disengaged (released) position. Recoil Starter 1. To start a cold engine, move the choke to the Ignition Primer Fuel Throttle Choke Button Valve CHOKE position (to the left).
  • Page 12 Engaging the Drive and Auger Controls 1. With the throttle control in the fast position, move shift lever into one of the six forward (F) or two reverse (R) positions. Select a speed appropriate for the snow conditions and a pace you’re comfortable with.

  • Page 13: Maintenance

    MAINTENANCE WARNING: BEFORE PERFORMING ANY MAINTENANCE PROCEDURE STOP THE ENGINE, WAIT FIVE (5) MINUTES TO ALLOW ALL PARTS TO COOL. Disconnect the spark plug wire, keeping it away from the spark plug. Regular maintenance is the way to ensure the best performance and long life of your machine. Please refer to this manual and the engine manufacturer’s owner’s manual for maintenance procedures.
  • Page 14 WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL STARTING TURN THE POWER SWITCH OF THE ENGINE TO ITS“OFF”POSITION. Wait for the engine to cool, and remove the spark plug wire before performing any inspection, maintenance, or cleaning procedures. Changing /Cleaning the Air Filter Fig 15 Air Cleaner Cover 1.
  • Page 15 WARNING: OIL IS VERY HOT DURING OPERATION AND CAN CAUSE BURNS. WAIT FOR ENGINE TO COOL BEFORE CHANGING OIL. Wait for the engine to cool, and remove the spark plug wire before performing any inspection, maintenance, or cleaning procedures. Changing the engine oil 1.
  • Page 16 LUBRICATION Gear Shaft The gear (hex) shaft should be lubricated at least once a season or after every 20 hours of operation. Fig 17 1. Remove the lower frame cover by removing the two screws which secure it (see Figure 17). 2.
  • Page 17 Shear Pin Replacement The auger is attached to the spiral shaft with shear pins Fig 20 Shear Pin secured with cotter pins. If the auger should strike a foreign object or ice jam, the snow blower is designed to shear off those pins (see Figure 20). If the auger will not rotate, check if the pins have been sheared.
  • Page 18 Auger Belt Replacement 1. ）Loose the two screws fixing the belt cover. Remove the belt cover. 2. Pull the belt out from the drive pulley. 3. Screw out the six nuts on two sides connecting the housing and transmission box. Separate the housing and the transmission box, then the belt will go out itself.
  • Page 19 Drive Belt Replacement 1. Separate the housing and transmission box as Step 1 in Auger belt replacement 2. Disassemble the belt pulley support from the transmission box (both strut should be screwed out on two sides together. Then the belt will go off itself. While install new belt, put the belt on belt pulley first, then guide it into the groove.
  • Page 20 Control Wire Adjustment When the auger or drive belts are adjusted or replaced, Fig 29 Control or after a long time of use, the control wires may need Lever to be adjusted. The control wires for the drive control and the auger control are attached to the auger lever and the drive lever on the handlebar.

  • Page 21: Engine Troubleshooting

    ENGINE TROUBLESHOOTING WARNING: BEFORE PERFORMING ANY MAINTENANCE PROCEDURE STOP THE ENGINE, WAIT FIVE (5) MINUTES TO ALLOW ALL PARTS TO COOL. Disconnect the spark plug wire, keeping it away from the spark plug. Problem Solution The engine will not start. •...

  • Page 22: Snow Blower Troubleshooting

    SNOW BLOWER TROUBLESHOOTING Problem Solution No snow through blower’s discharge chute. • Discharge chute and/or auger is clogged • Disengage the auger and drive controls, stop the engine, wait ten seconds for the auger to stop rotating, then using the clean-out tool provided, remove the snow clogging the chute.
  • Page 23 Auger does not engage. • Auger control wire is too loose. • If there is too much slack in the auger control wire, the augers will not be engaged properly. Turn off the engine. Adjust the tension of the auger control wire (see page 20). •...

  • Page 24: Storage

    STORAGE WARNING: DO NOT STORE SNOW BLOWER WITH FUEL IN TANK INDOORS Do not store in poorly ventilated areas, or near furnace,water heater, clothes dryer or gas appliance. 1. For short term storage wait for the engine to cool, then clean the engine with a clean cloth. 2.

  • Page 25: Part Diagrams And Parts List

    DIAGRAM--ENSEMBLE PARTS LIST -- ENSEMBLE PART NO. DESCRIPTION PART NO. DESCRIPTION Jam nut M8 Mandrel Right gimbal Lower connection tube Nut M8x1 Elastic cylindrical pin 3*18 Gear connector bar Rotating frame cover Nut M8 Screw M6X16 Concave gasket Ø8*22*2 Rotating frame Armrest aluminum pad Bolt M8X16 Bolts M8X55...
  • Page 26 DIAGRAM (A) --OPERATION ASSEMBLY www.tmgindustrial.com 26/35 Toll Free:1-877-761-2819...
  • Page 27 PARTS LIST (A) -- OPERATION ASSEMBLY PART NO. DESCRIPTION PART NO. DESCRIPTION Upper handle (right) Rivet 4x10 Panel Heated handle Nut M8 Left control lever Right pulley set Jam nut M6 Bolt M8x40 Short bushing Bolt M6x20 Input wire Small shaft sleeve Switch Pulley Deflector cable...
  • Page 28 DIAGRAM (B) --POWER ASSEMBLY www.tmgindustrial.com 28/35 Toll Free:1-877-761-2819...
  • Page 29 PARTS LIST (B) -- POWER ASSEMBLY PART NO. DESCRIPTION PART NO. DESCRIPTION Handlebar Rubber wheel Handle connecting plate Sleeve 18x23x18 Bolt M10x45 B pinchcock Bolt M6x16 Hexagon shaft Strut Transit shaft Cover 2 Chain wheel Bolt M6x20 Small chain wheel Pulley seat Sleeve 12x15x8 Small shaft sleeve...
  • Page 30 PART NO. DESCRIPTION PART NO. DESCRIPTION Delta bearing seat Rivet 4×12 Ball bearing 6002 Brake block Spring Bottom plate for transmission box Support for friction disc Position part Sleeve 13x20x20 B pin Ø1.5x25 Bolt M8x16 Reset spring Jam nut M12 Strut Brake spring PARTS LIST (C) -- WALKING ASSEMBLY...
  • Page 31 DIAGRAM (C) --WALKING ASSEMBLY www.tmgindustrial.com 31/35 Toll Free:1-877-761-2819...
  • Page 32 DIAGRAM (D) --AUGER ASSEMBLY www.tmgindustrial.com 32/35 Toll Free:1-877-761-2819...
  • Page 33 PARTS LIST (D) -- AUGER ASSEMBLY PART NO. DESCRIPTION PART NO. DESCRIPTION Housing assemble Left auger Housing bar (optional) Washer Ø8 Plastic nut (optional) Bolt M8x20 Skid shoe Bolt M8x20 (optional) Washer Ø8 BoltM8x25 Nut M8 Screw ST4.2x9.5-F Skid shoe Shovel support Nut M8 Bearing seat...
  • Page 34 DIAGRAM (E) --WORM GEAR BOX ASSEMBLY PARTS LIST (E) -- WORM GEAR BOX ASSEMBLY PART NO. DESCRIPTION PART NO. DESCRIPTION Worm case right Key A8*25 Bolt M10x15 Worm case left Seal ring 25x40x7 Bolt M6x25 Bearing 6205 Worm shaft Auger shaft 30 Sleeve Bearing 6202 Bearing 51104...
  • Page 35 DIAGRAM (F) --CHUTE ASSEMBLY PARTS LIST (F) -- CHUTE ASSEMBLY PART NO. DESCRIPTION PART NO. DESCRIPTION Chute welded Hinge axle Spring Rivet 4x10 Washer Ø8 Upper hinge Deflector spring Deflector Deflector cable Washer for barrier Barrier Strut Plastic washer Sealing pad Pin 2*16 Lower hinge Sealing pad...
