- Page 1 STS 6000 SX-F Operation & Maintenance Manual ENCLOSED FUEL MAINTENANCE SYSTEM Approved v1.0 5400 Division Dr. | Fort Myers, FL 33905 239 690-9589 | Toll Free 877-425-4239 | FAX 239 690-1195 www.AXI-International.com...
- Page 2 Approved v1.0.2 STS 6000 SX-F MANUAL V1.0.DOCX published by CC at 07/17/2024 10:41:00...
-
Page 3: Table Of Contents
Internal Pressure Relief Adjustment ..........................17 Tightening the Bypass Spring ............................17 Troubleshooting ................................. 18 Diagnostic Table ................................18 AXI International Limited Warranty ........................... 20 Warranty Claim Procedure ..............................21 Technical Assistance and Ordering ..........................22 Contact Information ................................22 Replacement Filter Chart .............................. -
Page 4: General Overview
General Overview STS 6000 SX-F Specifications Nominal Flow Rate .............. 2.5 GPM/150 GPH (9.5 LPM/567.8 LPH) 1,200 gallons (4,540 liters) per 8-hour shift 3,600 gallons (13,627 liters) per 24-hour shift Primary Filter ............... 30μ Hydrophobic particulate cartridge filter with water separation and containment Secondary Filter .............. -
Page 5: Getting Started
Familiarize the installation team with the requirements of the complete installation to prevent system damage. Thoroughly review this manual to ensure the system is installed as required. If any components are missing or damaged, contact AXI International with the provided contact information. -
Page 6: Primary Filter/Water Separator
Inline Magnetic Fuel Conditioner This component is user-serviceable and will need to be periodically inspected for contamination to ensure optimal system operation. There is a service kit that will need to be ordered to complete the Servicing the Fuel Conditioner section. -
Page 7: Fuel Pump
Adjustable Vacuum Switch Device Vaccum is the removal of pressure created by the atmosphere. This means that, in a perfect system, the absolute maximum vacuum level attainable with any device or combination of devices cannot exceed the atmospheric pressure where the system is installed. At sea level, the max level is 14.7 PSI or 29.92 in-Hg full vacuum. To protect the pump from damage, the vacuum switch is factory calibrated to a safe operating level. -
Page 8: Secondary Filter
Adjustable Pressure Switch Device To protect the pump and secondary filter from damage, the pressure switch is factory calibrated to a safe operating level. This setpoint can be recalibrated to accommodate installation configurations by following the Switch Adjustments. Adjustable Factory Setpoint: 22 PSI. •... -
Page 9: Enclosure Heater - If Applicable
An Auto/On fan switch allows for periodic or continuous fan operation. 125W Enclosure Heater AXI Offers enclosure heaters at various heating capacities as well as operating power ranges. Below is a table including all available options. Part No. -
Page 10: Installation
Installation It is recommended that only qualified, experienced personnel, familiar with this type of equipment, who have read and understood all the instructions in this manual should install, operate, and maintain the system. Plumbing installation must be in accordance with all applicable federal, state, and local rules, laws, standards, and regulations. Installation Diagram Key: Priming-T Check Valve... -
Page 11: Electrical
Flexible plumbing is strongly recommended for system inlet and outlet connections to the external plumbing in order to avoid issues with thermal expansion, prevent putting any stress on the internal fittings of the system, and enable ease of maintenance/installation. The pick-up line(s) should originate from the lowest point of the tank to ensure all water is removed and should be kept as short as possible. -
Page 12: Commissioning/Initial Start-Up
If the motor is running in the wrong direction and is built using 3-phase power, simply switch any 2 of the 3 hot wires provided from a 3-phase delta source. If this is not the case or switching the wires (3-phase only) does not resolve the problem, contact AXI International immediately. -
Page 13: Priming Procedure
Priming Procedure The head of the pump on the system is shipped from the factory oiled to facilitate initial lubrication. This will not eliminate the obligation to completely prime the system. The primary filter along with the suction line(s) must be completely filled with fuel (no trapped air) before initial system start-up. - Page 14 Reset the system alarm to resume operation. Slowly close the system inlet isolation ball valve while observing the system vacuum gauge reading. When the system vacuum reaches the switch calibrated setpoint, the controller will alert the condition is active. The pump will turn off after the vacuum debounce period has elapsed and the system controller will indicate high vacuum preventing the pump from operating further.
-
Page 15: Maintenance
Maintenance Disposal of fuel, associated waste, and filters must be in accordance with all applicable federal, state, and local rules, laws, standards, and regulations. Warning! Some fuels may have been treated with biocides. Biocides are extremely toxic and may enter the body through the skin. -
Page 16: Servicing The Primary Filter/Water Separator
Servicing the Primary Filter/Water Separator Manually Draining the Separator 1. Turn the system OFF. 2. Close the inlet and outlet ball valves. 3. Open the bleed screw at the top of the primary filter. 4. Connect a flexible line to the ½” hose barb fitting on the manual drain port of the water separator and direct it into a waste container. -
Page 17: Servicing The Secondary Filter
4. Open the inlet and outlet ball valves. 5. Check for leaks when re-starting and re-pressurizing the system. Switch Adjustments Please contact AXI International before adjusting either the vacuum or the pressure switch to avoid voiding the system’s warranty. Vacuum and Pressure Switches When the value exceeds the set point of the switches’... -
Page 18: Internal Pressure Relief Adjustment
8. Replace the rubber plug. Internal Pressure Relief Adjustment Please consult AXI International before performing any internal pressure relief adjustments to avoid warranty issues and potential damage to the system. The pump used on the STS systems comes from the factory with a pre-set internal pressure relief bypass. If the pressure on the discharge of the pump rises past this setpoint, the internal bypass will open and recirculate the fuel in the head of the pump to protect itself and any downstream components. -
Page 19: Troubleshooting
Troubleshooting Diagnostic Table To effectively identify and resolve problems associated with either the system or any of its upgrades, please consult the diagnostic table below: Impact Identified Problem Possible Root Cause(s) • Primary filter needs to be serviced Maintenance • Magnetic fuel conditioner requires service •... - Page 20 Impact Identified Problem Possible Root Cause(s) Leak Detection Alarm (cont.) Secondary Filter Leak • Damaged or incorrectly installed filter gasket • Leaking pump seal • Worn pump shaft seal Pump Leak • Pump pressure relief valve failure • Worn pump mechanical seals or O-rings •...
-
Page 21: Axi International Limited Warranty
Failures due to abuse or application of the product(s) for uses other than for which it/they are designed or intended by AXI International, including but not limited to, improper installation or location in a harsh, corrosive or saltwater environment. -
Page 22: Warranty Claim Procedure
THE EXPRESS WARRANTY PROVIDED FOR HEREIN. AXI International reserves the right at any time to make changes in the design, material, function and specifications of its products. Any such changes shall not obligate AXI International to make similar changes in such products that were previously manufactured. -
Page 23: Technical Assistance And Ordering
Technical Assistance and Ordering Contact Information For technical assistance and ordering please have your serial number ready and call, email, or inquire at: Email: info@axi-international.com Phone: +1-239-690-9589 Website: https://axi-international.com/contact-us/ AXI International 5400 Division Dr. Fort Myers, FL 33905 Please provide the following information: Serial Number of your system along with detailed descriptions of the issue for our support team to diagnose the concern.
