SIP Startmaster DSC200B Manual

Digital starter chargers

Advertisement

Quick Links

SIP Industrial Products Limited
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
United Kingdom
For help or advice please contact your
distributor, or sip directly on:
Tel.: 01509 500400
Email:
sales@sip-group.com
or
customerservice@sip-group.com
www.sip-group.com
SIP Startmaster Digital Starter Chargers
DSC200B DSC250B DSC350B DSC600B
SIP Code 03584 03585 03586 03587
Please read and fully understand the instructions in this manual before
operation. Keep this manual safe for future reference.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Startmaster DSC200B and is the answer not in the manual?

Questions and answers

Summary of Contents for SIP Startmaster DSC200B

  • Page 1 United Kingdom For help or advice please contact your distributor, or sip directly on: Tel.: 01509 500400 Email: SIP Code 03584 03585 03586 03587 sales@sip-group.com customerservice@sip-group.com www.sip-group.com Please read and fully understand the instructions in this manual before operation. Keep this manual safe for future reference.
  • Page 3: Table Of Contents

    CONTENTS Page No Description 4- 7 Safety Information Guarantee 8 - 10 Electrical Connection Technical Specification 12 - 13 Getting To Know Your Starter Charger 14 - 15 Assembly Instructions 16 - 21 Operating Instructions Troubleshooting Exploded Drawing 03584 Parts List 03584 Exploded Drawing 03585 03508 03587 Parts List 03585 03586 03587 UK Declaration of Conformity...
  • Page 4: Safety Instructions

    Read all these instructions before operating the charger and save this user manual for future reference. SIP recommends that the starter / charger should not be modified or used for any ap- plication other than that for which it was designed. If you are unsure of its relative applica- tions do not hesitate to contact us and we will be more than happy to advise you.
  • Page 5 SAFETY INSTRUCTIONS Cont... spill. The liquid inside batteries is highly corrosive therefore ensure that it is not allowed to make contact with the skin (especially eyes). In the event of contact, flush the area with clean water and immediately consult a doctor. Lead-acid batteries store a large amount of energy.
  • Page 6 SAFETY INSTRUCTIONS Cont... USE RECOMMENDED PARTS ONLY - Unapproved parts may be dangerous and will in- validate the warranty. WARNING! Only operate on a level and stable surface. WARNING! Do not allow untrained persons to operate the starter /charger and do not oper- ate the machine without all covers etc.
  • Page 7 SAFETY INSTRUCTIONS Cont... Use only a three-prong, grounded mains supply socket. ALWAYS unplug the starter / charger when not in use. Safety Symbols Used Throughout This Manual. Note: Supplementary information. Danger / Caution: Indicates risk of personal injury and/or the possibility of damage.
  • Page 8: Guarantee

    GUARANTEE Guarantee: These SIP starter / chargers are covered by a 24 month parts and labour warranty covering failure due to manufacturers defects. This does not cover failure due to misuse or oper- ating the charger outside the scope of this manual - any claims deemed to be outside the scope of the warranty may be subject to charges Including, but not limited to parts, labour and carriage costs.
  • Page 9 Connecting to the power supply: The SIP starter / charger 03584 DSC200B is fitted with a standard 230v ~ 13 amp type plug; the rest come without a plug fitted as they all need a supply above 13 amps to work correctly (see individual specifications).
  • Page 10 ELECTRICAL CONNECTION Cont... Warning: Never connect live or neutral wires to the earth terminal of the plug. Only fit an approved plug with the correct rated fuse. If in doubt consult a qualified electrician. Note: Always make sure the mains supply is of the correct voltage and amperage and the correct fuse protection is used.
  • Page 11: Technical Specification

    TECHNICAL SPECIFICATION Model 03584 03585 03586 03587 Supply 230v 50Hz 230V 50Hz 230V 50Hz 230V 50Hz Battery Voltage 6, 12 & 24v 12 & 24v 12 & 24v 12 & 24v Functions 10 Stage Charging, Boost & Support CHARGING: All Types of 12V Lead-acid & 12V Lithium Ion battery type: Batteries(4-cell LiFePO4) and 24V Lead-acid Batteries Charging Input -...
  • Page 12: Getting To Know Your Starter Charger

    GETTING TO KNOW YOUR STARTER / CHARGER CONTROL PANEL Item Description Item Description Item Description Engine Start Button GEL Battery LED Function Selector Engine Start Indicator AGM Battery LED Alternator % LED Digital Display 12V Lithium Battery LED Battery % LED Charged LED Battery Type Selector Voltage LED...
  • Page 13 GETTING TO KNOW YOUR STARTER CHARGER Cont... SOCKETS & FUSE ASSEMBLY Item Description Red Positive Socket 24v Red Positive Socket 6/12v Black Negative Socket Fuse Cover Fuse Link...
  • Page 14 ASSEMBLY 03584 CONTENTS:- 1 x 03584 Starter Charger: 2 x Cable Tidy Brackets: 4 x Screws: 2 x Bracket Stand-Offs: 1 x Negative Cable: 1 x Positive Cable • Fit cable tidy brackets to each side of the Starter Charger using one bracket, 2 spaces &...
  • Page 15 ASSEMBLY Cont... 03585 03586 03587 2 x Wheels: 1 x Axle: 1 x Handle: 1 x Foot: 4 x Long Screws: 2 x Short Screws: 2 x E - clips: 2 x Fuses **The 2 fuses are spare and not required for assembly.
  • Page 16: Operating Instructions

    OPERATING INSTRUCTIONS Charging a Battery Step No. Selection Result Make Battery Connect 6/12v battery to 6*/12v Termi- nal / Connect 24v battery to 24v Termi- Connections nal: Display shows battery voltage Corresponding LED will light. Select Battery Type Corresponding LED will light. Select Charging Mode NORMAL - “CHARGING”...
  • Page 17: Battery Types

    OPERATING INSTRUCTIONS Cont... ASSEMBLY Cont... CAUTION: Do not leave the battery connected to the charger once the charging has finished, this may cause excessive heating of the cells and the electrolyte to “boil”. If this happens during charging select a lower setting or stop the charge. Danger / Caution: Do not touch the positive clamp (Red) with the negative clamp (Black) together to check the starter / charger output –...
  • Page 18 OPERATING INSTRUCTIONS Cont... Step Mode Description Display Read-Out LED Status Charging State Analysing-1 Charging Checks that the battery is con- Analysing 1 BATT12/24 nected Charging Charging Pulsing charge to remove sul- De-sulphation BATT 12/24 phate Charging Charging Gradually increases charging De-sulphation 2 BATT 12/24 rate...
  • Page 19 OPERATING INSTRUCTIONS Cont... ASSEMBLY Cont... Engine Start Function Important: Check with the manufacturer of the vehicle to be started that it is safe to use a starter / charger without causing damage to the electrical system. Follow all safety instructions & precautions for charging a battery. Wear eye / face protection and protective clothing.
  • Page 20 OPERATING INSTRUCTIONS Cont... After the cool down cycle is complete the display will return to “START-READY”. If the vehicle did not start then charge the battery again on BOOST. Then perform steps 9 -11 again. If the engine turns over but does not start then the problem lies elsewhere - do not continue to attempt to crank using the starter / charger until the problem has been resolved.
  • Page 21 OPERATING INSTRUCTIONS Cont... ASSEMBLY Cont... Alternator Tester With the charger switched off, connect the battery as in the charging & starting sec-tions. Switch on the starter / charger. Press the test button until the “Alternator %” LED illuminates. Start the vehicle and turn on the vehicles headlights. If you get a reading of 0 - 100%, then the alternator is working ok.
  • Page 22: Troubleshooting

    <1 volt. Clean battery terminals Red & black clamps are Replace battery touching. Prevent clamps touching BATT - Charging in 12v mode Connect correctly. on 24v battery. ** MISMATCH ** NOTE: SIP Model 03584 "Charging in 6v mode on 12/24v battery"...
  • Page 23: Exploded Drawing 03584

    EXPLODED DRAWING 03584...
  • Page 24: Parts List 03584

    PARTS LIST Ref. No Description Ref. No Description Handle On / Off Switch Top Cover Cable Strain Relief Bottom Case Foot Cable Tidy Front Panel Bracket Stand-Offs Fuse Rectifier Bridge Fuse Cover Rectifier Bridge Bracket Panel PCB Transformer Quick Socket Main PCB Control Panel Relay...
  • Page 25: Exploded Drawing 03585 03508 03587

    EXPLODED DRAWING 03585 03586 03587...
  • Page 26 PARTS LIST Ref. No Description Ref. No Description Top Panel Bottom Plate Front Cover Transformer Base Pate Front Storage Cover Transformer Foot Rectifier Bridge Handle Rectifier Bridge Bracket Lower Handle Fuse Cover Control Panel Control PCB Battery Clamps 12/24v Terminal Wheels Circuit Board Heat Sink Top Panel...
  • Page 27 NOTES...
  • Page 28 NOTES...
  • Page 29 NOTES...
  • Page 30: Uk Declaration Of Conformity

    LE12 9NH England As the manufacturer within England, Scotland and Wales, we declare that the SIP Startmaster DSC200B Digital Starter Charger Item No.03584 SIP Startmaster DSC250B Digital Starter Charger Item No. 03585 SIP Startmaster DSC350B Digital Starter Charger Item No. 03586 SIP Startmaster DSC600B Digital Starter Charger Item No.
  • Page 31: Eu Declaration Of Conformity

    County Louth As the manufacturer within England, Scotland and Wales, we declare that the SIP Startmaster DSC200B Digital Starter Charger Item No. 03584 SIP Startmaster DSC250B Digital Starter Charger Item No. 03585 SIP Startmaster DSC350B Digital Starter Charger Item No. 03586 SIP Startmaster DSC600B Digital Starter Charger Item No.
  • Page 32 If your supplier offers a disposal facility please use it or alternatively use a recognised recycling agent. This will allow the recycling of raw materials and help protect the environment. For help or advice please contact you distributor, or sip directly on: Tel.: 01509 500400 Email: sales@sip-group.com customerservice@sip-group.com Ref: 07July2023 Revision 4 www.sip-group.com...
