Kathy Ireland CALLITO COVE CF135DBZ01 Owner's Manual

52” wet location ceiling fan
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
READ AND SAVE THESE INSTRUCTIONS
Ceiling Fan Owner's Manual
CF135DBZ01 -
Questions, problems, missing parts: Before returning to the store, Call Customer Service
BP7518-1 CF135 Callito Cove.indd 1
BP7518-1 CF135 Callito Cove.indd 1
CALLITO COVE
52" Wet Location
Model Number
Distressed Bronze
1-888-757-7697
MED
LOW
H
I
OFF
U.L. Model No.: CF135-1
2/2/21 4:25 PM
2/2/21 4:25 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CALLITO COVE CF135DBZ01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kathy Ireland CALLITO COVE CF135DBZ01

Summary of Contents for Kathy Ireland CALLITO COVE CF135DBZ01

  • Page 1 READ AND SAVE THESE INSTRUCTIONS CALLITO COVE 52” Wet Location Ceiling Fan Owner’s Manual Model Number CF135DBZ01 - Distressed Bronze Questions, problems, missing parts: Before returning to the store, Call Customer Service 1-888-757-7697 U.L. Model No.: CF135-1 BP7518-1 CF135 Callito Cove.indd 1 BP7518-1 CF135 Callito Cove.indd 1 2/2/21 4:25 PM 2/2/21 4:25 PM...

  • Page 2: Table Of Contents

    Table of Contents Section Section 10. Transmitter Battery Installation Safety Instructions and Code Setting 1. Unpacking Instructions 11. Receiver Code Learning 2. Electrical Requirements 12. Using Your Ceiling Fan 3. Ceiling Fan Assembly 13. Maintenance 4. Switch Cover Assembly Only 14.

  • Page 3: Unpacking Instructions

    1. Unpacking Instructions PACKAGE CONTENTS WARNING Do not install or use fan if any part is damaged or Part Description Quantity missing. Call Toll-Free: Fan Motor Assembly 1-888-757-7697 Ceiling Cover Motor Coupler Cover Glass Shade Light Kit Assembly 9-Watt Medium Base LED Bulbs Hanger Bracket Hanger Ball/4.5”...

  • Page 4: Electrical Requirements

    1. Unpacking Instructions (Continued) This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan THIS FAN IS SUITABLE FOR WET LOCATIONS SUCH AS PORCHES, PATIOS, AND DECKS. USE ONLY WITH LIGHT KITS MARKED SUITABLE FOR USE IN WET LOCATIONS. Tools Needed for Assembly WARNING Phillips head screwdriver...

  • Page 5: Ceiling Fan Assembly

    3. Ceiling Fan Assembly GREEN GROUND WIRE Remove the hanger ball by loosening the Phillips head setscrew in the hanger ball until the ball falls freely down the 4.5” downrod (Figure 1). 4.5" DOWNROD Remove the pin from the 4.5” downrod, then remove the hanger ball (Figure 1).
  • Page 6 3. Ceiling Fan Assembly (Continued) Align the clevis pin holes in the downrod with the holes in the motor coupler. Install the clevis pin and secure with the hairpin clip (Figure 4). The clevis pin must go through the holes in the motor coupler. HAIRPIN It is critical that the clevis pin in the motor coupler is properly CLIP...
  • Page 7 3. Ceiling Fan Assembly (Continued) Route the three 80” motor wires through the hanger ball RETAINER PIN DOWNROD (Figure 7). Locate the previously removed retainer pin from the downrod and insert it into the holes at the top of the downrod, as shown (Figure 7).
  • Page 8 3. Ceiling Fan Assembly (Continued) The fan comes with black, blue and white wires that are 80-inches long. Measure up approximately 6 to 9-inches above top of hanger ball/4.5” downrod assembly (Figure 9). Cut off excess wires and strip back insulation 1/2-inch from end of wires using wire strippers.
  • Page 9 3. Ceiling Fan Assembly (Continued) 3.11 PLAIN SIDE OF FAN BLADE BLADE/FLANGE INSTALLATION: Mount fan blade flange to the decorative bottom surface of the #10-24 x 0.4" FLANGE fan blade (as shown) using three #10-24 x .0.4” flange head HEAD SCREW (3 per flange/blade) blade screws using a Phillips head screwdriver (Figure 11).

  • Page 10: Switch Cover Assembly Only

    4. Switch Cover Assembly Only This Ceiling Fan can be Installed Without the Light Kit. If you would like to Install your Fan Without a Light Kit, Please Follow the Below Instructions of Section 4. Skip to Section 5 if you Wish to Install the Light Kit Assembly on Your Ceiling Fan. If the Light Kit Assembly is Already Assembled to the Fan, and You Want to Remove it, Reverse Section 5 Assembly Instructions to Uninstall the Light Kit Assembly and Then Follow Section 4 Instructions to Disassemble the Light Kit Fitter from the Switch Cover.
  • Page 11 4. Switch Cover Assembly Only (Continued) 14 mm WRENCH On the center threaded nipple of the switch cover, you will find a hex nut and lockwasher. HEX NUT Loosen and remove the hex nut with a 14 mm wrench, and the lockwasher (Figure 16).
  • Page 12 4. Switch Cover Assembly Only (Continued) Straighten the frayed strands of the switch cover blue and WIRE CONNECTOR WIRE CONNECTOR white wires in preparation to re-install the wire connectors. Using the two saved wire connectors, attach one connector to the bare blue wire and one connector to the bare white wire SWITCH of the switch cover by twisting the connector in a clockwise COVER...
  • Page 13 4. Switch Cover Assembly Only (Continued) RUBBER PLUG Locate the rubber plug from the hardware pack and install it BLADE into the blade installation slot of the switch housing plate by INSTALLATION firmly pushing it into the slot (Figure 21). SLOT NOTE: The rubber plug must be installed to prevent water penetration of the switch housing assembly.

  • Page 14: Light Kit Assembly

    4. Switch Cup Assembly Only (Continued) 4.11 S e c u r e l y r e i n s t a l l t h e t h r e e p r e v i o u s l y r e m o v e d #8-32 x 0.3”...
  • Page 15 5. Light Kit Assembly (Continued) LIGHT KIT ASSEMBLY Light Kit Fitter Has to be Attached to the Switch Cover to Proceed. Position the light kit assembly near the switch housing plate. Align and engage the large white light kit electrical connector with the large white motor electrical connector.

  • Page 16: How To Hang Your Ceiling Fan

    6. How to Hang Your Ceiling Fan CAUTION CEILING To reduce the risk of injury, install the fan so that the blades are at least 7 ft. (2.1m) above the floor (Figure 30). WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring.
  • Page 17 6. How to Hang Your Ceiling Fan (Continued) NOTE: CEILING COVER, SUPPL Y WIRES AND FAN WIRES Carefully lift the partially assembled ceiling fan and seat the OMITTED FOR CLARITY. hanger ball/downrod assembly on the hanger bracket that was just attached to the outlet box (Figure 32). Be sure the groove in the ball is engaged with the anti-rotation OUTLET tab on the hanger bracket (Figure 32).

  • Page 18: How To Wire Your Ceiling Fan

    7. How to Wire Your Ceiling Fan If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a Disconnect electrical power to the branch circuit at the circuit licensed electrician. breaker or fuse box before attempting to wire the ceiling fan. WARNING CAUTION To avoid possible electrical shock, be sure electricity...
  • Page 19 7. How to Wire Your Ceiling Fan (Continued) NOTE: Make all wiring connections using the wire connectors supplied in the hardware kit and remote control kit. Make sure that all connections are tight, including ground, and that no bare wire is visible at the wire connectors, except for the supply circuit ground wire.
  • Page 20 7. How to Wire Your Ceiling Fan (Continued) Securely connect the receiver black wire (AC in L) to the supply black wire (hot) using the wire connector (supplied in parts bag) (Figure 36). WIRE CONNECTOR SUPPLY AND RECEIVER BLACK WIRES Figure 36 Securely connect the receiver white wire (TO MOTOR N) to the fan motor white wire using the wire connector (supplied in...
  • Page 21 7. How to Wire Your Ceiling Fan (Continued) Securely connect the receiver black wire (TO MOTOR L) to the fan motor black wire using the wire connector (supplied in parts bag) (Figure 38). SUPPLY AND RECEIVER BLACK WIRES WIRE CONNECTOR Figure 38 NOTE: Failure to properly connect the receiver wires will damage the device and render it non-operable.
  • Page 22 7. How to Wire Your Ceiling Fan (Continued) While inserting the receiver fully into the hanger bracket, turn WIRE CONNECTORS wires upward and carefully push wires into the outlet box, (Tucked Inside with the white and green wires on one side of the outlet box Outlet Box) and position the black wire on the other side of the outlet box (Figure 40).

  • Page 23: Ceiling Cover Installation

    8. Ceiling Cover Installation Screw the studs into the threaded holes on the bottom of the hanger bracket with your fingers (Figure 42). HANGER BRACKET THREADED STUDS (2) Figure 42 Lift the ceiling cover up to the threaded studs and turn until studs protrude through the holes in the ceiling cover (Figure 43).

  • Page 24: Glass Shade Installation

    8. Ceiling Cover Installation (Continued) Secure the ceiling cover in place by sliding a lockwasher and knurled knob onto the threaded stud and loosely tighten to keep the cover in place. Install the other lockwasher and knurled knob onto the second threaded stud (Figure 44).
  • Page 25 9. Glass Shade Installation (Continued) The finial nut, hex nut, and rubber washer are preassembled to the bottom of the light kit. Unscrew the finial nut and remove the hex nut and rubber washer (Figure 46). Keep these items on top of the ladder for reassembly after the glass shade is installed.

  • Page 26: Transmitter Battery Installation And Code Setting

    9. Glass Shade Installation (Continued) Securely fasten the finial nut onto the light kit threaded nipple by screwing it on with your fingers until it is tight against the glass shade (Figure 48). NOTE: Periodically check that the glass bowl is seated correctly onto the light kit upper cover plate and the hex nut and finial nut are tightly fastened.
  • Page 27 10. Transmitter Battery Installation and Code Setting (Continued) 10.2 REMOTE CONTROL TRANSMITTER PRESET MEMORY FEATURE Your receiver is equipped with a preset memory feature. If the AC supply to the receiver is powered through a wall switch, when the switch is turned OFF, the control will remember the light intensity and fan speed.

  • Page 28: Operation Of Remote Control

    11. Receiver Code Learning - Programming the Operating Frequency of the Receiver 11.1 The receiver must be programmed within 2 minutes of restoring electricity to the fan. Program the receiver code by pushing and holding down the remote control OFF button REMOTE CONTROL for 5-10 seconds.

  • Page 29: Receiver Code Learning

    11. Receiver Code Learning - Programming the Operating Frequency of the Receiver (Continued) 11.3 INSTALLATION OF THE STORAGE BRACKET A storage bracket is provided for holding your remote control when not in use. If you desire to use the bracket, install it on a STORAGE wall that is away from excess heat or humidity (Figure 54).

  • Page 30: Using Your Ceiling Fan

    12. Using Your Ceiling Fan 12.1 All fans are shipped from the factory with the reverse switch positioned to circulate air downward. The reverse switch is located on the side of the switch cover. The switch is covered with a soft rubber seal that protects it from water.

  • Page 31: Repair Parts

    14. Repair Parts PARTS BAG BP7518-1 CF135 Callito Cove.indd 32 BP7518-1 CF135 Callito Cove.indd 32 2/2/21 4:25 PM 2/2/21 4:25 PM...

  • Page 32: Troubleshootin

    15. Troubleshootin WARNING FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLESHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Loose electrical connections in the 1. Check the electrical connections at the ceiling ceiling cover.
  • Page 33 SERIAL NUMBER: DATE CODE: The serial number of this fan can be found on the nameplate on top of the fan housing. The date code can be found on the carton and on top of the fan housing, stamped in ink on a white label. You should record this data above and keep it in a safe place for future use.
