- Page 1 FREON REFRIGERANT GAS LEAK DETECTOR Model: FD-92 Manual Print Version: 1.0 User Manual FORENSICS DETECTORS www.forensicsdetectors.com...
-
Page 2: Specifications
SPECIFICATIONS FD-92 Model: 1-year limited warranty Warranty: Semiconductor Heated Diode Sensor Sensors: 5 years Sensor Life: 0 – 10,000 ppm Detection Range: < 5 seconds Response Time: HFC: R134a, R410A, R407C, R417A, etc. Refrigerant Gas Detection: HCFC: R22, R123, R141b, R402a, etc. - Page 3 10 feet of work so quick access can occur if feeling unwell. What type of refrigerant leaks can these detectors find? The FD-92 can detect common refrigerants like R-134a, R-410A, R-22, and other halogenated refrigerants used in AC and refrigeration systems.
- Page 4 3. DESIGN The FD-92 Freon Gas Leak Detector has five buttons: FORENSICS DETECTORS www.forensicsdetectors.com...
-
Page 5: Quick Start
GREEN LED When the alarm has triggered, will flash rapidly. RED LED 5. By pressing the left or right button you can toggle between instantaneous levels (left image) and time series bar graph (right image). FORENSICS DETECTORS www.forensicsdetectors.com... -
Page 6: Display Icons
5. DISPLAY ICONS On the top of the FD-92 display is a row for notification icons. 6. MENU FUNCTIONS When in the main screen, press OK to enter the main menu. FORENSICS DETECTORS www.forensicsdetectors.com... - Page 7 Adjust the date and time to your local settings. Date and Time: Change screen brightness and auto sleep settings. Display: Toggle options for light, vibrator, and buzzer operation. Notifications: Chinese or English options. Language: ONLY do this if confirmed by our technical team. Factory Reset: FORENSICS DETECTORS www.forensicsdetectors.com...
-
Page 8: Advanced Menu
See chart below: This menu provides the user with the ability to select the sensitivity of the gas sensor. FORENSICS DETECTORS www.forensicsdetectors.com... -
Page 9: Battery Charging
8. BATTERY CHARGING The FD-92 has a built-in lithium battery and can be charged via Type C USB cable. USB Charger should be rated >1.0A for fast charging. Before charging, TURN OFF the analyzer to avoid any potential damage. Charging takes about 4 hours. -
Page 10: Warranty Disclaimers
ORIGINAL SUPPLIER WITH YOUR PROOF OF PURCHASE. Copyright © 2025, FORENSICS LLC, all rights reserved. FORENSICS, FORENSICS DETECTORS are registered trademarks of FORENSICS LLC. All other trademarks, trade names, service marks and logos referenced herein belong to their respective companies. - Page 11 Support & Sales Web: www.forensicsdetectors.com Email: sarah@forensicsdetectors.com FORENSICS DETECTORS www.forensicsdetectors.com...
