SimLab P1X PRO COCKPIT Instruction Manual page 24

BOX D - Wheel Deck
(optional purchase)
HARDWARE KIT
# Part
D1 Wheel deck
D2 Bolt M8 X 50 DIN 912
D3 Bolt M8 X 20 DIN 912
D4 Washer M8 DIN 125-A
D5 Slot-Nut M8
BOX E - Front Mount
(optional purchase)
PROFILE KIT
# Part
E1 120X40 UL Length=192mm
HARDWARE KIT
E2 Front mount
E3 Front mount bracket A
E4 Front mount bracket B
E5 Front mount spacer
E6 Bolt M8 X 40 DIN 912
E7 Bolt M8 X 25 DIN 912
E8 Cap-Washer M8
E9 Washer M8 DIN 988
E10 Washer M8 DIN 125-A
E11 Lock-Nut M8
E12 Slot-Nut M8
QTY Note
1
2
2
4
4
QTY Note
2
1
2
2
12
4 Extra.
16
4
4 Small.
4 Extra.
4 Extra.
4
BOX F - Fanatec DD Mount
PROFILE KIT
# Part
F1 120X40 UL Length=176mm
HARDWARE KIT
F2 Front mount bracket A
F3 Front mount bracket B
F4 Front mount spacer
F5 CSL spacer
F6 Bolt M8 X 25 DIN 912
F7 Bolt M6 X 20 DIN 7380-2
F8 Cap-Washer M8
F9 Washer M8 DIN 988
F10 Slot-Nut M8
Disclaimer: for some entries on this page, we supply more than required as spare
materials. Don't worry if you have some leftovers, this is intentional.
(optional purchase)
QTY Note
2
2
2
12
2 Only for CSL/GT DD.
12+4 Also used to mount DD1/DD2.
4
4
4 Small.
4
24
24 27 |
