- Page 1 Vario Vesa Adapter kit INSTRUCTION MANUAL SLA078 SLA079 SLA080 SKU: https://sim-lab.eu/shop/product/vario-vesa-adapter-kit-3-pieces-1143 info@sim-lab.eu Copyright© 2021 - Sim-Lab Products | Revision 0.9...
- Page 2 Required tools: 2/4/5/6 mm Assembly of the Vesa adapter *Base value of the set screws...
- Page 3 Assembly of the Vesa holder *Base value of the set screws 24.00 Attaching the Vesa adapter to the monitor...
- Page 4 Attaching the Vesa holder to the crossbar/sidearm Attaching the monitor assembly to the Vesa holder...
- Page 5 Adding the set-screws to fixate the monitor and to fine tune if needed DETAIL A SCALE 2:1...
- Page 6 Fine tune positioning of the monitors...
- Page 7 VESA 200 mounting BenQ adapter mounting...
- Page 8 Parts list Hardware kit Part name Note VESA Vario pin holder Units VESA Vario guide block 1.95 Units VESA Vario pin 8 mm (Stainless Steel) Units Bolt – DIN 912 (Black steel, 16mm, M8) Units Mounts whole plate to monitor crossbar/sidearm Bolt - DIN 7991 (Black steel, 12mm, M6) Units Connect VESA 200 to VESA plate...
