SimLab P1X PRO COCKPIT Instruction Manual page 23

BOX A - PROF 56A
PROFILE KIT
# Part
A1 160X40 UL Length=1350mm
A2 160X40 UL Length=500mm
A3 160X40 UL Length=490mm
A4 120X40 Length=850mm
A5 40X40 Length=500mm
BOX B - BASE PACK 56
PROFILE KIT
# Part
B1 80X40 Length=650mm
B2 80X40 Length=320mm
HARDWARE KIT
B3 Corner bracket 160x40
B4 Profile 160x40 end-cap
B5 Profile 120x40 end-cap angled
B6 Profile 80x40 end-cap angled
B7 Profile 80x40 end-cap
B8 Profile 40x40 end-cap
B9 Upright sandwich plate LEFT
B10 Upright sandwich plate RIGHT
B11 Side mount sandwich plate
B12 Side mount bracket
B13 Bolt M8 X 40 DIN 912
B14 Bolt M8 X 25 DIN 912
B15 Bolt M8 X 20 DIN 912
B16 Bolt M8 X 20 DIN 7991
QTY Note
2 Machined.
1 Crossbeam.
1 Rear.
2 Uprights, angled.
2 Machined.
QTY Note
1 Side mount.
1 Angled.
2
2
4
1
1
4
1
1
1
2
8
18
8
10 Countersunk.
B17 Cap-Washer M8
B18 Washer M8 DIN 988
B19 Washer M8 DIN 125-A
B20 Slot-Nut M8
HARDWARE KIT - ADJUSTABLE FEET
B21 Foot support plate
B22 Foot
B23 Bolt M8 X 25 DIN 912
B24 Washer M16 DIN 125-A
B25 Nut M16
B26 Slot-Nut M8
BOX C - Pedal Deck
PROFILE KIT
# Part
C1 160X40 Length=450mm
C2 80X40 Length=450mm
HARDWARE KIT
C3 Pedal deck bracket
C4 Bolt M8 X 40 DIN 912
C5 Bolt M8 X 30 DIN 912
C6 Bolt M6 X 16 DIN 912
C7 Bolt M5 X 16 DIN 912
C8 Cap-Washer M8
C9 Washer M8 DIN 988
C10 Slot-Nut M8
C11 Slot-Nut M6
C12 Slot-Nut M5
Disclaimer: for some entries on this page, we supply more than required as spare
materials. Don't worry if you have some leftovers, this is intentional.
10
18 Small.
8
28
4
4 Threaded ball-joint rod fitted.
8
8 Pre-installed.
8 Pre-installed.
8
QTY Note
1
1
2
6
8
12 Extra.
12 Extra.
14
14 Small.
6
12 Extra.
12 Extra.
23
23 27 |
