Page 1: Table Of Contents
Connecting the Watchdog Reset Cable page 6 Connecting Digital I/O page 7 Modifying Video Input Termination page 8 Connecting On-board Audio page 9 Connecting Audio and Video Sources page 10 Installing the Videum Software page 10 ©2011 Winnov, LP. All Rights Reserved. P/N 004-620102... -
Page 2: Product Description
PRODUCT DESCRIPTION The Videum 4400 AV Xpress is a 4-channel audio/video PCI Express capture card and the Videum 4400 VO Xpress is a 4-channel video-only PCI Express capture card. Both capture 4 simultaneous video streams from 4 independent video sources. The Videum 4100 AV Xpress is a 1-channel audio and video PCI Express capture card that enables fast switching between 4 video sources. -
Page 3: System Requirements
SYSTEM REQUIREMENTS • CPU: AMD or Intel > 1 GHz • Slot: x1, x4, x8 or x16 PCI Express, PCI-E 1.1 compliant • Memory: > 256 MB • OS: Windows 2000 SP4, XP SP2, Vista & SP1 x86, Server 2003 SP2, Server 2008 x86 (DirectX9 or higher required) VIDEUM 4400 AV XPRESS BOARD DRAWING This drawing illustrates the Videum 4400 AV Xpress board. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Power off the computer when installing and removing PC cards. When the computer is turned off by using the power switch, there still might be power supplied to the motherboard. To ensure that your computer is completely shut down, unplug the computer’s power cord from its power source. -
Page 5: Getting Setup
• Connect your source(s). • Install the software from the Videum CD. INSTALLING VIDEUM This section describes how to install the Videum board, connect Winnov’s Watchdog, connect Digital I/O, and modify Video Input Termination. Installing the Videum Board To install the Videum board, do the following: 1. -
Page 6: Installing Multiple Boards
Installing Multiple Boards Winnov Videum enables you to install several Videum capture cards into your system. If you have installed multiple boards in one system, Videum software recognizes the num- ber of capture cards that you have. Each board is one PCI Express device and requires only one driver installation. -
Page 7: Connecting Digital I/O
Your Videum board provides 8 digital I/O which can be used as trigger input or as event signaling output. Each input and output is used individually as input or output. The Digi- tal I/O interface on the board is controlled through Winnov’s ActiveX software and the Videum SDK (Software Development Kit). -
Page 8: Modifying Video Input Termination
Modifying Video Input Termination Each video input (Video Source 1-4) is terminated with 75 Ohm. For proper video recep- tion this termination is required. In some cases, termination is not desired, for example: • The card is inserted into an existing video link via a T-piece. •... -
Page 9: Connecting On-Board Audio
Connecting On-board Audio Connectors The Videum board provides on board headers for all 4 audio inputs (which are the same as the 8pin Mini DIN on the bracket) and for the audio output. The audio out amplifier is able to drive a 32 Ohm headphone or speaker. The on board headers have the following pinout. -
Page 10: Connecting Audio And Video Sources
CONNECTING VIDEO AND AUDIO SOURCES To connect your video sources, do the following: • Connect your video source (camera, DVD player, VCR, etc) to any of the four BNC video inputs (Video Source 1 through 4). To connect your audio sources (Videum 4400 AV Xpress and 4100 AV Xpress), do the following: •... - Page 11 Winnov’s support website at www.support.winnov.com. To obtain help or information associated with your Videum board or Videum applications, use the Videum SDK’s help menus, supplied documentation (on the CD), or contact Winnov support via e-mail at support@winnov.com. 2011 copyright Winnov. All Rights Reserved.
