Page 1: Table Of Contents
Connector Descriptions page 4 Safety Instructions page 5 Getting Set Up page 5 Installing Videum page 5 Connecting Video Sources page 6 Installing the Videum Software page 8 Connector Specifications page 8 ©2009 Winnov, LP. All Rights Reserved. PN 004-620076... -
Page 2: Product Description
PRODUCT DESCRIPTION • The Videum 1000 Plus is an audio/video capture card and 1000 VO Plus is a video-only capture card that supports square pixel resolution. • The Videum 1010 Plus is an audio/video capture card that is designed for a low profile PCI slot. SCOPE OF DELIVERY QuickStart Guide CD with software driver and documentation... -
Page 3: System Requirements
SYSTEM REQUIREMENTS • 200 Mhz Pentium® or faster • One open PCI slot • 16 MB RAM minimum (32 or 64 MB recommended), 2 GB RAM max • Windows 2000, 2003, XP, or Vista (for all OS, x86 only - 32 bit) •... -
Page 4: Connector Descriptions
Audio must be connected to the Line/Mic Audio IN input. 8-pin mini-DIN Winnov composite video camera (comes with the Videum Camera IN Conference Pro XP kit) or other cameras via a special interface cable. This input combines audio, video, and power for the camera. -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS Power off your computer when installing and removing PC cards. To ensure that your computer is completely shut down, unplug the computer’s power cord from its power source. Static electricity can damage your client adapter. Before removing the adapter from the antistatic packaging, discharge static by touching a metal part of a grounded PC. -
Page 6: Connecting Video Sources
• S-Video IN is used for S-VHS or Hi-8 camcorders. • Composite Video IN is used for normal cameras and camcorders. • MXC Video IN is used for the Winnov video camera or other cameras via a special interface adaptor cable. See the Hardwaresection for a description. - Page 7 Videum Conference Pro XP Kit Camera If you purchased the Winnov’s Videum Conference Pro XP kit, the Winnov video camera is shipped with the following settings: Switch Settings Description ON (default) Sets backlight compensation to prevent underexposed or overexposed images.
-
Page 8: Installing The Videum Software
INSTALLING VIDEUM SOFTWARE The Videum Software CD contains the Drivers required for using the Videum board, applications, and documentation. Note: If the “Found New Hardware Wizard” popup appears after you start up your sys- tem, be sure to cancel out of it. It may take up to four cancellations (depending on the capture card that you installed) to dismiss the popup. - Page 9 MXC Connector Pinout Assignment PC SCL (control/data bus) PC SDA (control/data bus) Ground +5V DC at 500mA (unregulated from PC motherboard) Ground Line level audio (from camera microphone) +5V DC at 500mA (regulated from Videum card) Composite video (from camera) Audio Connector Connector Characteristics...
- Page 10 Winnov’s website at www.winnov.com. To obtain help or information associated with your Videum board or Videum applications, use the Videum SDK’s help menus, supplied documentation (on the CD), or contact Winnov support via e-mail at support@winnov.com. ©2009 Winnov, LP. All Rights Reserved.
