U-Line H-11198 Manual

H-11198
EXTENDED HANDLE
STEEL WHEEL CHOCK
TOOLS NEEDED
10 mm Wrench Allen Wrench x 1
(included)
Handle x 1
(Two Pieces)
1. Fit handle pieces together and align holes.
Use long bolt and nut to secure. (See Figure 1)
Figure 1
2. Determine if handle will be mounted on left or
right side of chock.
PAGE 1 OF 3
1-800-295-5510
uline.com
PARTS
Wheel Chock x 1
Short Bolt x 4
ASSEMBLY
3. Align handle and mounting plate around bar on
back of wheel chock. Secure using short bolts and
nuts. (See Figure 2)
4. Tighten all bolts using Allen and 10 mm wrenches.
Pour le français, consulter la page 3.
Nut x 5 Mounting Plate x 1
Long Bolt x 1
Figure 2
Mounting
Plate
Handle
Para Español, vea página 2.
0224 IH-11198
