H-11622
EXTENDED HANDLE
LAMINATED WHEEL CHOCK
TOOLS NEEDED
11 mm Wrench
13 mm Wrench
14 mm Wrench
Wheel Chock x 1
Small Bolt x 1
1.
Fit handle pieces together and align holes. Use
small bolt and locknut to secure. Tighten with
11 mm wrench. (See Figure 1)
Figure 1
Small
PAGE 1 OF 6
Bracket x 1
Small Locknut x 1
Large Flat Washer x 2
Small
Locknut
Bolt
1-800-295-5510
uline.com
PARTS
Handle x 1
Large Locknut x 2
ASSEMBLY
NOTE: Determine if chock will be configured
left- or right-handed before completing step 2.
Instructions show right-handed setup.
2. Attach handle to bracket using two short bolts and
two small flat washers. Tighten with 13 mm wrench.
(See Figure 2)
Figure 2
Bracket
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Small Flat Washer x 2
Short Bolt x 2
Large Bolt x 2
Small
Short
Washer
Bolt
Handle
1124 IH-11622
