Summary of Contents for AV Access eShare D30
- Page 1 Type-C Casting Dongle eShare D30 User Manual...
-
Page 2: Table Of Contents
Table of Contents Introduction ....................2 Overview ..........................2 Features ..........................2 Package Contents ......................2 Panel ............................ 3 Application ....................4 Specifications ................... 13 Warranty ....................14 www.avaccess.com info@avaccess.com... -
Page 3: Introduction
Introduction Introduction Overview This product is a USB type-C based wireless screen sharing dongle. It supports sharing contents from sources (e.g., laptop) to a display device wirelessly through our AV equipment (such as eShare W90, hereinafter referred to as receiver). It supports transmitting up to 4K@30fps video signal with audio, and also features USB camera signal return and USB speakerphone signal return with a desktop application. -
Page 4: Panel
Introduction Panel LED Indicator Wireless Conference Button Casting Button USB-C Port Name Description a. Running lights (Blue, counterclockwise): The dongle is starting / The dongle is pairing up with the receiver (connected with a receiver) / WiFi is disconnected. b. Solid on Blue: The dongle is paired up with the receiver successfully / The dongle is preparing for casting screen (connected... -
Page 5: Application
Application Name Description b. Disconnecting the screen casting: Press the button once. c. Frozen the screen: Press the button twice in 1s in projecting process. d. Unfrozen the screen: Press the button once in frozen status to exit and back to sharing status. e. - Page 6 Application Receiver Dongle Once pairing is done, “Pairing Successful” will appear on the display screen. The dongle’s LED will be solid on blue. 2. Connect the dongle to a laptop. After the pairing is successful, unplug the dongle from the receiver and connect it to the USB Type-C port of a laptop, it will start running and connecting to the receiver.
- Page 7 Application on the laptop, navigate to the section of “My Computer” or “This PC”, and double click “CD Drive (G:) eShare” to install the application automatically. The installation process will perform background and the application will run automatically after the installation is successful.
- Page 8 Application Click “Continue” to install the application. Before starting installation process, users need to use the correct touch ID, face ID or password to enable the installation to process. For example: Note: Some relevant permissions requirements may www.avaccess.com info@avaccess.com...
- Page 9 Application pop up in the installation process, users need to allow the permissions. For example: Click “Open System Settings” to enter the following setting page: Click the button after “eShare”, and input correct touch ID, face ID or password to allow the permission, and click “Done”...
- Page 10 Application receiver connected can’t be used. Click “Allow” to enable the application to find devices on local network and back the installer interface. Upon successful installation, the installer will display the following interface. Click "Close" button to exit the installer. The application window appears in the lower right corner of the desktop when the installation is successful and after about 5s the window will minimize to menu...
- Page 11 Application using M series chips need to have system version 12.3 or higher. The Instruction of “eShare” Application: • The main interface introduces the button operation of the dongle. • : Click the icon to check the application version, export log file and contact support.
- Page 12 Application • When the application installed on the laptop is not the latest version, it will prompt to update the latest version when users plug in the dongle. Click “Update” to update the application to the latest version. • Whether the application is installed or not does not affect the operation of the big button of the dongle.
- Page 13 Application laptop’s screen (cast through the dongle) displayed in full screen. Freeze/unfreeze the screen In the process of casting screen, press the button twice in 1s, the cast screen will be frozen, and the audio cast through the dongle is also paused. A transparent pause icon will appear on the center of the cast screen.
-
Page 14: Specifications
Specifications connected to the source through the dongle, they can be detected by the system and specific application in the name of the following: USB Camera: Room Camera USB Speakerphone: Room Audio Specifications Technical Max Resolution 4K @ 30fps Terminal Type 1 x USB Type-C Frequency 5GHz (default) and 2.4GHz... -
Page 15: Warranty
Warranty Products are backed by a limited 1-year parts and labor warranty. For the following cases AV Access shall charge for the service(s) claimed for the product if the product is still remediable and the warranty card becomes unenforceable or inapplicable.
