- Page 1 Type-C Casting Dongle eShare D20 User Manual...
-
Page 2: Table Of Contents
Table of Contents Introduction ....................2 Overview ..........................2 Features ..........................2 Package Contents......................2 Panel ............................ 3 Application ....................5 Specifications ....................7 Warranty ...................... 8 www.avaccess.com info@avaccess.com... -
Page 3: Introduction
Introduction Introduction Overview This product is a USB type-C based wireless screen sharing dongle. It supports sharing contents from sources (e.g., laptop) to a display device wirelessly through our AV equipment (such as eShare W80, hereinafter referred to as receiver). It supports transmitting up to 4K@30fps video signal with audio, USB camera signal return and USB speakerphone signal return. -
Page 4: Panel
Introduction Panel LED Indicator Wireless Conference Button Casting Button USB-C Port Name Description a. Marquee (Blue, counterclockwise): The dongle is starting / The dongle is pairing up with the receiver (connected with a receiver) / WiFi is disconnected. b. Solid on Blue: The dongle is paired up with the receiver successfully / The dongle is preparing for casting screen (connected... - Page 5 Introduction Name Description support video transmission; Solid on dark blue + solid on green (LED indicator below the wireless conference button): Press the wireless conference button in the status of casting screen. e. Blinking 2 times/s (blue): The dongle is in the process of upgrading.
-
Page 6: Application
Application Name Description support video and audio transmission, such as laptop) for casting screen. Application 1. Pair the USB dongle with the receiver (take eShare W80 as an example). Note: More detail operations about the receiver, please refer to its own user manual. Connect the USB dongle to the “Pairing”... - Page 7 Application 3. Casting screen. Press the button of the dongle once, the laptop’s screen will be cast to the display the receiver connected. The LED will light blue. Displa y USB Camera USB Speakerphone Dongle Receiver Laptop Enter full screen mode When there are multiple screens (including screen projected through the dongle) shown on the sink display, hold press the dongle’s button for about 3 seconds, you can have your...
-
Page 8: Specifications
Specifications Wirelessly connected with camera speakerphone When plug the dongle, the wireless conference feature is disabled, when press the wireless conference button, and a USB camera and a speakerphone are connected to the receiver, the signals from these USB devices will return to the source device through the dongle. -
Page 9: Warranty
Warranty Products are backed by a limited 1-year parts and labor warranty. For the following cases AV Access shall charge for the service(s) claimed for the product if the product is still remediable and the warranty card becomes unenforceable or inapplicable. - Page 10 Warranty...
