RUNHOOD 2400-EU User Manual

Residential ess & portable power station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
English
RESIDENTIAL ESS
& PORTABLE POWER STATION
USER MANUAL
2400-EU
www.runhoodpower.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2400-EU and is the answer not in the manual?

Questions and answers

Related Manuals for RUNHOOD 2400-EU

Summary of Contents for RUNHOOD 2400-EU

  • Page 1 English RESIDENTIAL ESS & PORTABLE POWER STATION USER MANUAL 2400-EU www.runhoodpower.com...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION To ensure safe operation and service of the product, read and be sure to understand all instructions. Failure to follow all instructions may result in severe injury or property damage. Any loss caused by incorrect use of product is not covered by our Warranty. IMPORTANT SAFETY INSTRUCTIONS The connector plug shall incorporate a fuse or other protective device having a current rating not greater than 16 A.
  • Page 3 STORAGE If storing for more than one month, charge completely before storage and recharge approximately every 3 months to avoid full discharge and possible damage. Store indoors, in cool temperatures, low humidity, and away from direct sunlight. Leaving in a vehicle or other confined spaces in extremely hot temperatures can lead to decreased service life, overheating, and fire.

  • Page 4: Table Of Contents

    Contents 1.PRODUCT DEFINITION 1.1 APPLICATION SCENARIOS 1.2 F2400 1.2.1 Product Appearance 1.2.2 Specification Parameters 1.2.3 Basic Function 1.2.4 LCD Function 1.3 B2400 1.3.1 Product Appearance 1.3.2 Specification Parameters 1.3.3 Basic Function 1.3.4 Power Indicator Function 2 USE AND INSTALLATION 2.1 GRID CONNECTION FUNCTION 2.1.1 grid-connection 1.Self-use Mode 2.Timer Mode...
  • Page 5 3 FAULT HANDLING 4 PARTS LIST...

  • Page 6: Product Definition

    1 PRODUCT DEFINITION 1.1 APPLICATION SCENARIOS Application Scenario One: Supports input methods such as AC charging, PV charging, and vehicle charging. Supports DC output such as USB, DC and AC output. Can be moved and stacked for use. Application Scenario Two: Used as a balcony photovoltaic, supporting grid connection function. Application Scenario Three: As a home energy storage battery pack, it can be matched with hybrid inverters for use.
  • Page 7 Key3 DC on/off Key4 Wi-Fi Reset PV Input Voltage 60Vdc Max. PV Input Current 25A Max. Input PV Input Power 1200W Max. ISC PV (Absolute maximum) 29A DC: OVC II OVC category Rated 12–60Vdc, Supports the Maximum Voltage Input of 150V, DC 15A, 1200W Max. USB-A(*2) 5V/2.4A 12W Max.

  • Page 8: Basic Function

    2. Main Power Switch ON/OFF To turn on the Runhood F2400 home/mobile energy storage power supply, press the main power button for 1.5 seconds until you hear a beep. To shutdown the device, long press the power button for three seconds, wait for the beep, and release the button. If device is unable to shutdown normally, press and hold the power button for ten seconds until you hear three beeps in succession.
  • Page 9 4. DC and USB Output Switch ON/OFF Press the DC&USB output switch button to turn on or off the DC output and USB output of Runhood F2400, and light up the button indicator light. This button controls the output of the USB output port and cigarette lighter port of the Runhood F2400 home/mobile energy storage power supply.
  • Page 10 DC parallel connection port (PORT-2), port (Black) containing wires and communication wires, connects to the upper connection port of F2400 or B2400. The schematic diagram and pins definitions are as follows: Figure 1-4 Schematic Diagram of DC Parallel Connection Port (PORT-2) DC Parallel Connection Port (PORT-2) Pins Description Number Identification...
  • Page 11 Hybrid inverter Communication or EMS Port (COM1) Pins Description Number Identification Description CT module RS485-B RS485_B_CT CT module RS485-A RS485_A_CT EMS module RS485-B RS485_B_EMS Hybrid inverter module CAN-H CAN1_H Hybrid inverter module CAN-L CAN1_L EMS module RS485-A RS485_A_EMS Hybrid inverter module RS485 A RS485_A Hybrid inverter module RS485 B RS485_B...
  • Page 12 12.Dry Junction Communication Port COM-3 The device has reserved a dry contact signal. Figure 1-7 Schematic Diagram of Dry Junction Communication Port COM-3 Dry Junction Communication Port Pins (COM3) Description Number Identification Description Output dry contact signal 1 (In) Output dry contact signal 1 (Out) COM1 Output dry contact signal 2 (In) Output dry contact signal 2 (Out)
  • Page 13 Figure 1-8 18. PV or DC Charging Input Port Specification XT60EW-M. The F2400 can be charged through the PV or DC charging input port using Runhood’ s built-in car charging port and a dedicated connection cable and through a solar panel.

  • Page 14: Lcd Function

    Method 2: Add automatic/manual switch mode: Usually, you can obtain power from the mains. When no mains is detected, you can obtain power from the battery. The backup switch time is related to the corresponding time of the automatic switch. The automatic switch or manual switch is purchased by the customer.

  • Page 15: B2400

    Display Information： 1.Status Prompt Identification. 2.F2400 Parallel Status Identification and F2400 Code. 3.Charging Power. 4.Discharging Power. 5.Percentage of Remaining Battery Capacity. 6.AC Output Voltage and Frequency. 7.Abnormal State Identification. 8.Charge/Discharge Remaining Time. 9.Parallel Connection Quantity: The maximum quantity is 8 units. 10.Parallel Available Quantity: The maximum quantity is 8 units.

  • Page 16: Basic Function

    If F2400 is idle (All output switches are turned off and the device is not charging) for more than 5 minutes, F2400 will automatically shut down. The period of time until device shuts down in power save mode can be adjusted using the Runhood Power App.

  • Page 17: Power Indicator Function

    1.3.4 POWER INDICATOR FUNCTION 1. Power Indicator Function: The B2400 has a total of five indicator lights, LED1-LED5. Each light indicates 20% power. When all indicators are lit, capacity is at 100%. The following table shows the indicator status during charging and discharging: State of Charge State: LED1 LED2...

  • Page 18: Use And Installation

    AFE communication abnormality 1,3,4 Flash Discharge fault 1,3,4,5 Flash Charging fault 1,2,5 Flash Encoding fault 1,2,4 Flash Battery short circuit fault 1,2,4,5 Flash Voltage sampling disconnection 1,2,3 Flash Abnormal temperature sampling 1,2,3,5 Flash Abnormal pre discharge 1,2,3,4 Flash Fault that locks device 1,2,3,4,5 Flash 2 USE AND INSTALLATION 2.1 GRID CONNECTION FUNCTION...
  • Page 19 B. Solar energy provides power to the loads as first priority. If solar energy is not sufficient to power all connected loads, battery energy will supply power to the loads at the same time. GRID PLUG LOAD F2400 INVERTER OTHER LOAD Figure 2-2 F2400 BAT C.

  • Page 20: Timer Mode

    2.Timer Charge/Discharge Mode 1.On Charge Time A. When 2400 is nearly fully charged, Solar energy will charge battery as first priority. The excess energy will supply power to the loads. Power generation to the grid is not supported in this mode. The load on the smart plug draws power directly from the grid. GRID PLUG LOAD F2400 INVERTER...

  • Page 21: Battery Priority Mode

    3. In the Period of No Charge or Discharge The load on the smart plug draws power directly from the grid. GRID PLUG LOAD F2400 INVERTER OTHER LOAD Figure 2-7 F2400 BAT B. Solar energy provides power to the loads as first priority. If solar energy is not sufficient to power all connected loads, battery energy will supply power to the loads at the same time.

  • Page 22: Installation Steps

    B. Solar energy will charge the battery as its first priority. If there is excess solar energy, the excellent power will supply the loads. If solar energy is not sufficient to charge battery and supply loads, grid will supply power to loads. The load on the smart plug draws power directly from the grid.
  • Page 23 Step 3: Press the main power switch button for 1.5s 1.5S Figure 2-14 Step 4: Connected photovoltaic panel Install the solar panel and connect it to the DC input port of F2400 using a Solar to XT60F charging cable. Note: The parameters of the photovoltaic plate need to meet the following range:Rated 12-60Vdc, Supports the Maximum Voltage of 150V, DC 25A, 1200W Max.
  • Page 24 Install the load on the smart plug. Press and hold the smart plug for 3 seconds until the indicator light keeps flashing and enters the distribution network state. Figure 2-21 RUNHOOD SMART PLUG Step 8: Now to configure the network, the following is the operation of the App.

  • Page 25: Dc Coupling

    2.2 DC Coupling Both the F2400 and B2400 can be connected to hybrid inverters and used as energy storage power sources in home energy storage systems. You can expand the energy storage capacity by "F2400+B2400" or "B2400+B2400" parallel mode. The communication mode between the battery BMS and the inverter is CAN communication, and the SOC notified by the BMS to the inverter is the average SOC.
  • Page 26 Figure 2-25 Runhood 2400 home/mobile energy storage power supply products support “F2400+B2400” and “B2400+B2400” parallel modes. The F2400 can be used as either a master or a slave device. The total power capacity of the F2400 or B2400 can be extended by parallel operation up to 8*2.4KWh.
  • Page 27 1.2.3-13 DIP Switch. Step 3: Connect the battery power port of the inverter using the Runhood dedicated hybrid inverter power cable. For hybrid inverter power of 5KW and below, use hybrid inverter power cable A (2AWG). For hybrid inverter power above 5Kkw, use hybrid inverter power cable B(1/0AWG).
  • Page 28 NOTE: The sixth steps and the fourth step must be the same device. Step 7: Turn on the Runhood 2400 home/mobile energy storage power supply and confirm that the inverter is successfully connected. At this time, the Runhood 2400 home/mobile energy storage power supply enters ESS mode and the F2400 LCD displays the PCS identifier indicating...

  • Page 29: Installation Steps

    Step 8: Shutdown: If you need to turn off the battery, stop the inverter first, and then disconnect the Cat.6 ethernet cable connection with the inverter. After the Runhood 2400 home/mobile energy storage power supply exits the Hybrid inverter mode, long press the power switch for 3s to shut down the Runhood home/mobile energy storage power supply.

  • Page 30: Smart Meter

    2. Based on the original solar inverter or micro-inverse scheme, F2400 and AC coupling are connected to the distribution box: Runhood smart meter is added to the household side and the F2400 works together through the wireless distribution network. GRID...

  • Page 31: Fault Handling

    3 FAULT HANDLING Can it be automatically Fault code Fault content Actions restored Stop charging, check if the device temperature is too high, and wait for Too high charging the device to cool down before use. If it cannot be restored or cannot process temperature be used normally after restoration, please contact a professional.
  • Page 32 Abnormal Check and restart the device for restoration. If it cannot be restored communication between the main or cannot be used normally after restoration, please contact a station BMS and the professional. DC main control AFE communication Restart the device to restore. If it cannot be restored or cannot be abnormality used normally after restoration, please contact a professional.
  • Page 33 Disconnect the electrical appliance, and click the USB output switch to restore. If it cannot be restored or cannot be used normally after USB-C1 port fault restoration, please contact a professional. Disconnect the electrical appliance, and click the USB output switch to USB-C2 port fault restore.

  • Page 34: Parts List

    Disconnect the electrical appliance and wait for the device to restore AC output overload or restart the device to restore. If it cannot be restored or cannot be used normally after restoration, please contact a professional. Disconnect the electrical appliance and wait for the device to restore Inverter malfunction or restart the device to restore.
  • Page 35 In the balcony photovoltaic application Smart Plug Optional scenario, it is used with the load. Residential ESS &portable B2400 B2400 power station extra batrrey Optional product Used for parallel 2 * 2AWG+8 * expansion of battery Extra 20AW/orange+black Included in packs battery plug/cable...
  • Page 36 Android service@runhoodpower.com www.runhoodpower.com Version: EU_2024_06...
