pakoworld 330-000014 Assembly Instruction

ASSEMBLY INSTRUCTION
Before you begin, please follow Assembly Instruction carefully.
Follow them step by step.
STEP 1
(A) M6 X 50MM JCBC
SCREW - 2 PCS
1
A
(D) M4 ALLEN KEY
( BALL TYPE ) - 1 PC
STEP 3
ASSEMBLY INSTRUCTION
Before you begin, please follow Assembly Instruction carefully.
Follow them step by step.
2
5
4
5
6
6
FULL SETUP
330-000014
STEP 2
D
A
(B) M4 X 16MM C/B
SCREW - 4 PCS
1
STEP 4
(C) M4 X 16MM C/B
SCREW - 2 PCS
1) TABLE LEGS X 2 SETS
2) PART A X 1 PC
3) TABLE WITH DRAWER X 1 PC
(A) M6 X 50MM JCBC SCREW - 2 PCS
(B) M4 X 32 MM C/B SCREW - 4 PCS
3
B
B
B
B
REMARK : ATTACH PART 3 USING (B) SCREW
AND POZI SCREWDRIVER AS SHOWN.
REQUIRED ASSEMBLY TOOLS :
POZI SCREWDRIVER - 1PC
C
REMARK : ATTACH PART 4 USING (C) SCREW
AND POZI SCREWDRIVER AS SHOWN.
REQUIRED ASSEMBLY TOOLS :
POZI SCREWDRIVER - 1PC
PART LIST
4) MIRROR X 1 SET
5) CHROME CAP X 2 PCS
6) METAL JOIN X 2 PCS
HARDWARE LIST
(C) M4 X 16 MM C/B SCREW - 2 PCS
(D) M4 ALLEN KEY ( BALL TYPE ) X 1 PC
Page 1
B
C
C
Page 2
