Sealey RE2500 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
1.1. GENERAL SAFETY
WARNING! It is compulsory to read this manual before using this equipment. The proper operation and full compliance of this
‰
product's performance is guaranteed only if all the instructions provided in this manual are closely adhered to.
The usage of this machine requires particular attention. Compressed springs can be potential dangers due to force collected
because of compression. This machine must be used always with its specific frontal protection mounted correctly on the
frame.
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this equipment.
‰
WARNING! Wear approved safety hand and eye protection (standard spectacles are not adequate).
‰
WARNING! TRAPPING DANGER – Keep hands and fingers away from the spring and compressing jaws in use.
‰
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9
Remove ill-fitting clothes. Remove ties, watches, rings, other loose jewellery. Contain and/or tie back long hair.
9
Wear appropriate protective clothing.
9
Familiarise yourself with the applications, limitations and potential hazards of the spring compressor.
9
The machine is equipped with pictograms that show remaining risks and individual protection measures to be used during working
9
operations. The pictograms are integral part of the product. In case of loss, deterioration or illegibility, require the pictograms to the
constructor in order to substitute them immediately. Replace the pictograms always in the same place where they were removed.
DO NOT use the spring compressor for a task it was not designed to perform.
8
DO NOT allow untrained persons to use the spring compressor.
8
1.2. PRE-OPERATIONAL SAFETY
DO NOT operate compressor if parts are damaged or missing as this may cause failure and/or personal injury.
8
Before commencing compression, make a visual inspection of machine to ensure pins are securely positioned and that there is no sign
9
of wear or fatigue – if found, DO NOT use and refer to your local Sealey stockist for advice and replacement parts.
Ensure that spring holding attachments are correctly attached and positioned before use.
9
Before commencing compression of spring, ensure coils of the spring are seated securely in the yokes of the compressor and cannot slide out
9
during compression.
ALWAYS ensure that the safety guard locks in place.
9
1.3. OPERATIONAL SAFETY
When applying compression to the spring, always stand to one side of the compressor.
9
▲ DANGER! Stop compressing the spring before the coils touch / bind.
DANGER! Before attempting to remove top cap nut, always use a tool or similar to test if the compression has been relieved, DO NOT
▲
use your hands / fingers.
We recommend the use of purpose made strut tools to remove the top-nut from the shock absorber piston.
9
Once compressed, and the strut removed, we recommend releasing the tension on the spring. DO NOT leave the spring under
9
compression in the machine unattended and DO NOT leave in compression for prolonged periods, i.e. overnight.
Before releasing the compression ensure that the top strut-nut is securely tightened to the manufacturer's tolerance.
9
Release the compression slowly keeping your hands and fingers away from the spring assembly.
9
Be sure that the tension on the spring is fully controlled by the strut assembly before removing it from the yokes of the compressor.
9
1.4. POST OPERATIONAL SAFETY
When not in use, clean and store the spring compressor in a safe, dry, childproof location.
9
Maintain the spring compressor in good condition. Replace or repair damaged parts. Use genuine parts only.
9
Unauthorised parts may be dangerous and will invalidate the warranty.
9
2. INTRODUCTION
Designed for fast and safe compression of suspension coil springs. Air powered system operated by foot pump for ease of use. High-capacity
unit featuring 2500kg maximum load. Features safety cage. Includes a suspension strut clamp. Fits a wide range of left and right-handed coil
spring configurations and diameters.
© Jack Sealey Limited
AIR OPERATED COIL SPRING COMPRESSOR
2500KG
RE2500
MODEL NO:
Wear protective
Beware
gloves coil binding
Original Language Version
Wear safety
Warning:
footwear
Keep bystanders
away
Warning: General
Crushing of Warning
hands
RE2500 Issue 2 18/12/24
