DIVERSITECH ASURITY CONNECTED Wet Switch Installation Instructions

The Asurity Connected Wet Switch helps prevent flooding and property damage by detecting water
®
caused by accumulation of air-conditioning condensate, drain leaks, etc. The device notifies the user by
either Email or SMS Text. When water is detected, contacts controlling the system are disconnected and
a notification is sent. Multiple Wet Switches may be connected in series (within the electrical limits of
the power supply) to expand coverage area. The Connected Wet Switch incorporates isolated relay
contacts (both normally open and closed) for added flexibility in installations with electronic control
boards where breaking one lead from the transformer is not possible.
Installation
1. Turn off power to the HVAC system.
2. Place Connected Wet Switch, padded side down, on the surface to be monitored.
3. Connect wiring as shown in the diagrams below. Wires may be extended, but avoid excess run lengths.
4. Restore power to the HVAC system.
5. Press "PUSH TO TEST" to assure proper function.
6. See back for setting up notifications.
Controlling Selected Components
System components such as compressors, electric valves, condenser
pumps, chill water pumps, or other controls may be connected
selectively and independently to Connected Wet Switch.
The Connected Wet Switch can be powered from either VAC and VDC
sources.
CONNECTED WET SWITCH SPECIFICATIONS
®
LED INDICATORS: POWER REQUIREMENTS:
12 to 30 VAC, 50/60 Hz, 2.0 Watts max
Green: Power On, Normal State
Red: Moisture Detected 12 VDC
Blue: Wi-Fi Connection Status RELAY: Isolated Contacts: 3 Amps (max) @ 240V, SPDT
VAC Typical Wet Switch Connection:
RED
GREEN ORANGE
(Common) (Normally
closed)
RED
POWER IN
24VAC
ALARM
BLACK WHITE
(optional)
(Normally
WS-1C
open)
BLACK
CONNECTED WET SWITCH NOTIFICATIONS
®
This device uses Email or SMS Text for notifications, by using nearby Wi-Fi to connect to a cloud server on the Internet. A report of the event is digitally signed by the device and sent to the server. The server verifies user data and sends a notification via Email
or SMS Text. To ensure the device is operating correctly, it periodically reports operating status with the secure server, and if not functioning, a "device off-line" notification is sent.
NOTE: Your Wet Switch will operate and help protect against flooding even if notification feature is not setup or used.
CONDENSATE MANAGEMENT
Warning: It is recommended to verify operation of Wet Switch using the "TEST" and
"RESET" buttons at time of installation and at least annually thereafter.
Operation of the contacts varies depending on
type of power provided.
12 to 30 VAC
No Power ORG-GRN WHT
Dry & Power ORG-GRN WHT
Wet & Power ORG GRN-WHT
, 1.5 Watts max
VDC Typical Wet Switch Connection:
RED RED
+
EQUIPMENT
RED
POWER IN
(Thermostat,
12VDC
Control
BLACK
Board, etc.)
-
BLACK BLACK
Status Indications & Operation
Normal State: When power is applied and no moisture is detected, the POWER LED will
be lit green, and the MOISTURE LED will be OFF. See back for WI-FI Connection LED
information.
Pressing the red PUSH TO TEST button simulates moisture
SCAN
for detection and confirms proper function of Connected Wet
Quick Start Guide
Switch. MOISTURE LED will be lit red, and POWER LED will
and Video
be OFF.
Instructions
Press the green PUSH TO RESET button to return
Connected Wet Switch to normal state.
When water is detected, the control circuit is opened, and the MOISTURE LED is lit red.
Connected Wet Switch will remain in this state until the issue is corrected and the
PUSH TO RESET button is pressed, or power is disconnected. Upon correcting the
moisture issue, dry felt pad using an absorbent cloth. May use hair dryer on low for
faster drying. Reset once dry.
12 VDC
ORG-GRN WHT
ORG GRN-WHT
ORG-GRN WHT
This product is intended to be installed and connected to a suitable power source,
which employs appropriately rated current limiter, by qualified personnel.
In a wet location, circuit rated above 16 VAC or 35 VDC can cause electric shock.
Unit is not to be placed or kept under water.
Two or More Wet Switches in Series: (
RED
GREEN
(Common) Sensor +
ORANGE
EQUIPMENT
POWER IN
(Normally
closed)
(to all WS)
(Home Monitor,
WHITE
Alarm, etc)
(Normally
WS-1C
open)
BLACK
Sensor -
*Dashed lines indicate field wiring
CONNECTED Wet Switch
Installation Instructions
LED Indicators
WI-FI CONNECTION
POWER
MOISTURE
TEST & RESET
Buttons
Moisture detection by either switch interrupts the circuit)
RED GREEN
GREEN INPUT
(Common)
ORANGE
RED
(Normally
WS-1C
closed)
GREEN
RED
BLACK WHITE INPUT
(Normally
WS-1C open)
WS-1C
www.diversitech.com
®
WS-1C
CONNECTED
Wet Switch Flood Detector
®
PUSH DUAL VOLTAGE
TO
TEST
POWER
WI-FI
MOISTURE
PUSH
TO
MODEL NO. WS-1C
RESET
SEE USER GUIDE
FOR WARNINGS
3190890
CONFORMS TO UL STD
ANSI/UL 508, UL STD 61010-1
Wet Switch ® is a registered trademark
of DiversiTech Corp.
ORANGE
ORANGE GREEN
VAC
example
WS-1C
OR
RED
VDC
example
WS-1C
800.995.2222
