MultiSensor-LAN (Ethernet) – MANUAL | 1
MultiSensor-LAN (Ethernet) – MANUAL
ORDER-CODES:
,
,
,
KMS-LAN-B
KMS-LAN-W
KMS-LAN-B-BLE
KMS-LAN-W-BLE
DATA SHEET MULTISENSOR-LAN
KentixONE Operating mode
SiteManager Operation
Stand-alone operation
Further information on the operating mode
© Kentix GmbH. This file was automatically generated on 2025-04-25 00:45:05. Please visit
docs.kentix.com
for the
latest documentation.
Advertisement
Related Manuals for Kentix MultiSensor-LAN
Summary of Contents for Kentix MultiSensor-LAN
- Page 1 MultiSensor-LAN (Ethernet) – MANUAL ORDER-CODES: KMS-LAN-B KMS-LAN-W KMS-LAN-B-BLE KMS-LAN-W-BLE DATA SHEET MULTISENSOR-LAN KentixONE Operating mode SiteManager Operation Stand-alone operation Further information on the operating mode © Kentix GmbH. This file was automatically generated on 2025-04-25 00:45:05. Please visit docs.kentix.com for the latest documentation.
- Page 2 GHz). Additional Kentix wireless sensors can be connected via these in the Satellite Device operating mode. The MultiSensor-LAN then also works as an Ethernet wireless gateway, making it very easy to set up stable sensor networks. The wireless sensors can be distributed within a radius of up to 20m, depending on the structure of the building.
- Page 3 Electrical appliances and batteries must be disposed of separately from household waste. Controls Front Status LED : GREEN: POWER OK, no alarms pending RED: POWER OK, alarms pending 360° PIR motion sensor © Kentix GmbH. This file was automatically generated on 2025-04-25 00:45:05. Please visit docs.kentix.com for the latest documentation.
- Page 4 MultiSensor-LAN (Ethernet) – MANUAL | 4 Back MultiSensor LAN Rear view Reset button Mounting bracket Default settings information Connections © Kentix GmbH. This file was automatically generated on 2025-04-25 00:45:05. Please visit docs.kentix.com for the latest documentation.
- Page 5 Additional system components such as leakage sensors, door contacts or external alarms from UPS or air conditioning units can be connected via the Kentix system port. The system port has 2 digital inputs and 2 digital outputs which are available via a RJ45 socket.
- Page 6 * These connections are for internal use only Kentix system port assignment Connection of a leakage sensor to the system port Leakage sensor MultiSensor © Kentix GmbH. This file was automatically generated on 2025-04-25 00:45:05. Please visit docs.kentix.com for the latest documentation.
- Page 7 MultiSensor via the RJ45 T adapter. Connection of a leakage sensor and an alarm siren to the system port © Kentix GmbH. This file was automatically generated on 2025-04-25 00:45:05. Please visit docs.kentix.com for the latest documentation.
- Page 8 For initial configuration, use the IP address printed on the device or the address assigned via DHCP in a web browser (HTTPS). Please note the network settings of your connected PC. The factory IP addresses at a glance: © Kentix GmbH. This file was automatically generated on 2025-04-25 00:45:05. Please visit docs.kentix.com for the...
- Page 9 We recommend regular backup of the system. Assembly instructions Kentix MultiSensors are equipped with various individual sensors. To ensure optimum evaluation and functional cooperation of the sensors, please observe the following basic installation instructions: -Do not mount over radiators or air outlets or direct sources of heat/cold.
- Page 10 More information about mounting MultiSensors here. Calibration of the room temperature measurement Kentix MultiSensors record all important environmental values of a room, including the room temperature. In order to achieve the most accurate temperature possible and to trigger an alarm if the room temperature exceeds the limit value, we recommend calibrating the temperature measurement at the final installation location.
- Page 11 Before you start the configuration, make sure that the software is up to date on all network-enabled Kentix devices. The version status must be the same on all devices. You can download the latest software here: KentixONE © Kentix GmbH. This file was automatically generated on 2025-04-25 00:45:05. Please visit docs.kentix.com for the latest documentation.
