MultiSensor-LAN-RF (network radio repeater) – MANUAL | 1
Legacy product
This product is no longer available. The documentation is still available as an archive.
ORDER-CODES:
KMS-LAN-RF
DATA SHEET
MULTISENSOR-LAN-RF,
Quick Start Guide
Overview
The MultiSensor-LAN-RF offers the same functionality as the MultiSensor-LAN.
It also enables a remote radio network to be set up so that remote RF components (MultiSensor-RF / -
Door / KeyPads) can communicate with the manager via LAN/WAN. The configuration of the repeater
and the connected components is done via the web interface of the manager.
If the sensor is added as a LAN RF repeater, additional RF components can be added to it.
© Kentix GmbH. This file was automatically generated on 2024-12-24 10:52:27. Please visit
docs.kentix.com
for the
latest documentation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the KMS-LAN-RF and is the answer not in the manual?

Questions and answers

Summary of Contents for Kentix KMS-LAN-RF

  • Page 1 If the sensor is added as a LAN RF repeater, additional RF components can be added to it. © Kentix GmbH. This file was automatically generated on 2024-12-24 10:52:27. Please visit docs.kentix.com for the latest documentation.
  • Page 2 Kentix accepts no liability for damage to the equipment or components resulting from incorrect installation. No liability is accepted for incorrectly programmed units. Kentix shall not be liable in the event of malfunctions, damage to property or other damage. Use of the products, transport and storage Protect the device during transport, storage and operation from Protect moisture, dirt and damage.
  • Page 3 MultiSensor-LAN-RF (network radio repeater) – MANUAL | 3 MultiSensor LAN-RF Front view Status LED : GREEN: POWER OK, no alarms pending RED: POWER OK, alarms pending PIR sensor Back © Kentix GmbH. This file was automatically generated on 2024-12-24 10:52:27. Please visit docs.kentix.com for the latest documentation.
  • Page 4 MultiSensor-LAN-RF (network radio repeater) – MANUAL | 4 MultiSensor LAN-RF Rear view Reset button Mounting bracket Default settings information Connections © Kentix GmbH. This file was automatically generated on 2024-12-24 10:52:27. Please visit docs.kentix.com for the latest documentation.
  • Page 5 Additional system components such as leakage sensors, door contacts or external alarms from UPS or air conditioning units can be connected via the Kentix system port. The system port has 2 digital inputs and 2 digital outputs which are available via a RJ45 socket.
  • Page 6 The device loads the factory settings and performs a restart. After approx. 2 minutes, the device can be reached with the factory settings. © Kentix GmbH. This file was automatically generated on 2024-12-24 10:52:27. Please visit docs.kentix.com for the...
  • Page 7 Application example Assembly instructions Kentix MultiSensors are equipped with various individual sensors. To ensure optimum evaluation and functional cooperation of the sensors, please observe the following basic installation instructions: -Do not mount over radiators or air outlets or direct sources of heat/cold.
  • Page 8 More information about mounting MultiSensors here. Calibration of the room temperature measurement Kentix MultiSensors record all important environmental values of a room, including the room temperature. In order to achieve the most accurate temperature possible and to trigger an alarm if the room temperature exceeds the limit value, we recommend calibrating the temperature measurement at the final installation location.
  • Page 9 Before you start the configuration, make sure that the software is up to date on all network-enabled Kentix devices. The version status must be the same on all devices. You can download the latest software here: KentixONE © Kentix GmbH. This file was automatically generated on 2024-12-24 10:52:27. Please visit docs.kentix.com for the latest documentation.
