Summary of Contents for Pyle PHSP4
- Page 1 Visit Our Website SCAN ME PyleUSA.com PHSP4 - PHSP5 Indoor/Outdoor PA Horn Speaker USER GUIDE...
-
Page 2: What's In The Box
PA Horn Speaker Technical Specs: • Construction Material: Engineered ABS • Nominal Impedance: 8 Ohms • Frequency Range: 500Hz - 5kHz MODEL PHSP4 PHSP5 Power/Load Rating 50 Watt 65 Watt SPL (1W/1m) 100dB 101dB Product Dimensions 6'' x 4'' x 8'' -in. -
Page 3: California Prop 65 Warning
How to Use Polarity Caution Pay close attention to the polarity when more than two speakers are in operation at the same location. Incorrect polarity can lead to poor sound quality and/or low sound pressure levels. Connections should be made like those of a battery: the same polarity for parallel connections and opposite polarity for series connections. - Page 4 Speaker Bracket www.PyleUSA.com...
- Page 5 Planar Graph PSHP4: 203mm PHSP5: 232mm PSHP4: 117mm PHSP5: 100mm PSHP4: 200mm PHSP5: 150mm www.PyleUSA.com...
- Page 6 Assembly Instructions 1. Unpack the Speaker: Carefully take the speaker and all parts out of the box. Make sure everything is included and in good condition. 2. Install the Mounting Bracket: Find the right spot where you want to mount the speaker (e.g., wall, pole, or stand). Attach the mounting bracket securely using the proper screws and tools.
-
Page 7: Maintenance
Complete the form to access expert support and to keep your PyleUSA purchase Model Number: in perfect condition. PHSP4 PyleUSA.com/pages/register www.PyleUSA.com... - Page 8 Questions or Comments? We are here to help! Phone: 1.718.535.1800 PyleUSA.com/ContactUs...
