Summary of Contents for CS Instruments FA 515
- Page 1 Operating Instructions Dew point sensor FA 515 with 2-wire technology 4…20 mA or RS 485 Modbus output FA 515 Version 1.20 Seite 1 von 20...
- Page 2 Fax: +49 (0) 461 807 150 15 Mail: info@cs-instruments.com Web: http://www.cs-instruments.com Impressum © CS Instruments GmbH & Co.KG | 78052 VS-Tannheim| Zindelsteiner Strasse 15 | GERMANY. Translation of the original German instructions. FA 515 | DE | V1.20 FA515 V1.20 Seite 2 von 20...
- Page 3 Table of contents II. Table of contents Foreword ............................2 Table of contents ..........................3 Scope of delivery ..........................4 Type plate ............................4 Device overview ..........................5 Pictograms and Symbols ........................6 Warning Symbols ........................6 Electrical symbols ........................6 Signalwords according ISO 3864 and ANSI Z 535 ................6 Intended use ............................7 Use contrary to the intended purpose ....................7 Safety provisions ..........................8...
- Page 4 Scope of delivery Scope of delivery ● Dew point sensor FA 515 ● Optional measuring chamber ● M12 connector socket, 5-pin, A-coded ● Calibration certificate ● These operating instructions Type plate 10…36V 1 – Manufacturer info 2 – Sensor name 3 –...
- Page 5 Device overview 3 Device overview 1. Sensor case 2. M12 Input/Output Connector 3. glass feed-through with G1/2‘ or NPT ½’ screw-in thread 4. humidity sensor element protected by sintered cap- FA 515 Version 1.20 Seite 5 von 20...
- Page 6 Note! Possible harzard As a consequence of incorrect handling: possible personal injury or damage Important! Additional notes, information, tips As a consequence of incorrect handling: Disadvantages in operation and maintenance, no danger FA 515 Version 1.20 Seite 6 von 20...
- Page 7 6. Intended use Intended use Dew point sensor FA 515 is a measuring probe used to measure the dew point of gaseous fluids (compressed air, nitrogen) in pipes under pressure. The dew point sensor is also used for long-term stable dew point monitoring of corresponding compressed air preparation systems.
- Page 8 Obligations of the installer of the system: The installer of the system is responsible for the safety of the system in which the FA 515 is installed. Pay particular attention to the technical data and ambient conditions (chapter 7) and the information on the electrical connection and prescribed connection cables (chapter 9).
- Page 9 Alternatively, use a quick coupling for FA 515 with measuring chamber. For FA 515 without measuring chamber, install a shut-off valve or ball valve in the compressed air line before and after the dew point sensor so that the dew point sensor can be removed quickly and easily for maintenance and calibration purposes.
- Page 10 8. Safety provisions Danger if the applicable regulations for electrical installations are not observed. For electrical installation, observe the applicable regulations, e.g. DIN EN 50110-1. In Germany observe in particular VDE 0100 in the relevant parts. Observe local regulations. Before working on the electrical installation, switch off all supply circuits, switch off the mains fuse and secure against being switched on again.
- Page 11 9. Product informationen Product informationen Sensor types ● FA 515 for pressure ranges up to 50 bar/725 psig and for dew point measuring ranges of -20...+50 °Ctd/-4...122 °Ftd.. Recommendation: after refrigeration dryers, for example. ● FA 515 for pressure ranges up to 50 bar/725 psig and for dew point measuring ranges of -80…+20 °Ctd/-112…68 °Ftd.
- Page 12 IP 66 * of f.s. = of full scale Remark: The FA 515 comes standard with a 4...20mA output in 2-wire technique and an RS 485 Modbus output. But it can only be used either the analogue output 4...20 mA or RS 485 Modbus output. Both outputs cannot be used at the same time due to the 4...20 mA 2-wire technology (low power).
- Page 13 Dimension 11 Dimension Abmessungen Dimensions 30,2 FA515 V1.20 Seite 13 von 20...
- Page 14 Schwarz / Black Blau / Blue - VB Connector plug Modbus (B) Weiss / White Modbus (A) Remark: The sensor must be connected in strain less state only FA 515 Version 1.20 Seite 14 von 20...
- Page 15 Measurable gases In general, humidity can be measured in all non- FA 515 corrosive gases. In case of measurements in corrosive gases please consult CS Instruments GmbH. FA515 V1.20 Seite 15 von 20...
- Page 16 Modbus 14 Modbus The FA 515 comes standard with a 4...20mA output in 2-wire technique and an RS 485 Modbus output. But it can only be used either the analogue output 4...20 mA or RS 485 Modbus output. Both outputs can not be used at the same time due to the 4...20 mA 2-wire technology (low power).
- Page 17 Modbus 14.2 Register of device settings 14.2.1 Modbus Settings (2001…2006) Modbus Modbus No.of Default Data Type Description Read Write Unit /Commen Register Address Byte Setting 2001 2000 UInt16 Modbus ID Modbus ID 1…247 2002 2001 UInt16 Baudrate 0 = 1200 1 = 2400 2 = 4800 3 = 9600...
- Page 18 From the manufacturer According to DIN ISO certification of the measuring instruments we recommend regular calibration and, if necessary, adjustment of the instrument by the manufacturer. The calibration cycles should fit your internal scheme. FA 515 Version 1.20 Seite 18 von 20...
- Page 19 Control and calibration set 33 % RH 0554.0005 Control and calibration set 75.3 % RH 0553.0104 Connection cable for FA 515, length: 5 m 0553.0105 Connection cable for FA 515, length: 10 m 3200.0003 Precision calibration at 0 °Ctd and 10 °Ctd incl. ISO certificate FA 515 Version 1.20...
- Page 20 Declare under our sole responsibility that the product Feuchtesensoren FA 510 FA 515 Dew point sensors FA 510 / FA 515 den Anforderungen folgender Richtlinien entsprechen: We hereby declare that above mentioned components comply with requirements of the following EU directives: Elektromagnetische Verträglichkeit...
