Page 2
Please read and save these instructions before installation...
Page 3
FAN SUPPORT For all questions about your ceiling fan please read all included instructions, installation procedures, trouble- shooting guidelines and warranty information before starting installation For fast service have the following information below when you call: • Model Name and Number •...
Page 4
SAFETY RULES For operation, maintenance, and troubleshooting information, visit http://waclighting.com/fan-support/ Never place objects in the path of the fan blades. the circuit breaker before beginning. To avoid personal injury or damage to the fan and other items, please be cautious when working around All wiring must be in accordance with the National Electrical Code “ANSI/ or cleaning the fan.
Page 5
Substitution of parts or accessories not designated for use with this product by WAC could result in personal injury or property damage and will void the outlet box is to be sealed such that no water enters the outlet box.
Page 6
This WAC Fan is: Damp Location-listed to the strictest UL/cUL safety regulations. Finished and rated for interior and exterior use.
Page 7
TABLE OF CONTENTS Package Contents Mounting Options Installing the Mounting Bracket Attaching the Fan Blades Pull Chain Assembly/Luminaire Hanging the Fan Making the Electrical Connections Finishing the Installation Installing the GLASS Glass Controlling the Fan Accessories Troubleshooting...
Page 8
TOOLS & MATERIALS REQUIRED Electrical tape Wire cutters Phillips screwdriver Step ladder Hanging Weight: 6.8 kg/15 lbs. NOTE: Before discarding packaging materials, be certain all parts have been removed. NOTE: Place the parts from the hardware bag into a small container to keep them from being lost. F-1 0 6 L...
Page 9
PACKAGE CONTENTS Fan Blade (Set of ) Coupling Cover RPL-F106-52-BD-** RPL-F106-COUCVR-** Downrod Assembly RPL-HGR-ASM-F106** Motor Housing Mounting Canopy Ring Bracket RPL-CAN-CYL-** RPL-HGR-ASM-F106** Hardware Bag RPL-F106-PARTS Canopy CCT Luminaire Module RPL-CAN-CYL-** Outlet Box Safety Cable 6F4IN-120V-R1-CS-H #10x38mm Pan Head Phillip Screws x2 Φ6.5x19x2mm Flat Washer x1 Ø5*14*1mm Flat Washer x2 3/16”(Φ5.2x8.4x1.0mm)Spring Washer x1...
Page 10
MOUNTING OPTIONS INSTALLING THE MOUNTING BRACKET Standard Ceiling Slope Ceiling Caution: Remember to disconnect the power at the circuit breaker. CAUTION: To prevent electrical shock, ensure electricity has been Remove 1 set screw from mounting bracket and set aside for use in Finishing the Installation.
Page 11
ATTACHING THE FAN BLADES 4CCT switch before the fan is mounted. Do not adjust the switch when the fan is powered ON. NOTE: Your Fan comes standard as 3000K (neutral white color). You can preset your Fan to 2700K, 4000K, or 5000K (pure white - daylight color).
Page 12
HANGING THE FAN PULL CHAIN ASSEMBLY/LUMINAIRE 1. Remove screw from hanger ball. Remove hanger ball and Remove one of the three mounting plate screws from the mount- cross pin. Set them aside. ing ring and loosen the other two screws (do not remove). 2.
Page 13
HANGING THE FAN 1. Slip up canopy and canopy screw cover. Re-install hanger ball with cross pin in the correct position. 1. Seat all into the mounting bracket. Rotate until ball drops and locks into hanger bracket screw. 2. Secure the safety cable into the structure beams using the wood screw, washers, and spring washers provided.
Page 14
MAKING THE ELECTRICAL CONNECTIONS 2. Connect the ground conductor of the 120v supply to the green groundlead(s) of the fan. Connect the white (neutral) wire from the ceiling to the white wire (light) from fan. Connect the black (hot) wire from the ceiling to the black wire (fan motor) and blue wire (light) from the fan.
Page 15
FINISHING THE INSTALLATION 1. Secure wire connectors with supplied wire ties. 1. Tighten canopy screw ring as shown. 2. Install canopy to mounting bracket with the screw removed in section 2. F- 1 0 6L...
Page 17
CONTROLLING THE FAN PULL CHAIN OPERATING INSTRUCTIONS REVERSE SWITCH OPERATING INSTRUCTIONS The pull chain controls the fan speed as follows: The reverse switch is located on the surface of the switch housing. Slide the switch to the left for warm weather operation. Slide the NOTE: Speed settings for warm or cool weather depend on switch to the right for cool weather operation.
Page 18
CONTROLLING THE FAN Product Model Description Downrod DR12-** 12” in downrod DR18-** 18” in downrod DR24-** 24” in downrod All our downrods are 1” O.D. and are threaded on the motor DR36-** 36” in downrod end to create an extra layer of security to allow for adjustments DR48-** 48”...
Page 19
TROUBLESHOOTING My Fan Will Not Start Check main and branch circuit fuses or circuit breakers. Check line wire connections to fan and switch wire connections in the switch housings. WARNING My Fan is Noisy Allow for 24-hour break-in period. Most noises associated with a new fan will go away during this time period. Check to make sure the screws which attached to the blades (and blade arms when applicable) are tight.
Page 20
TROUBLESHOOTING My Fan is not producing Enough Air Movement If possible, please consider using a longer than included downrod. For all other questions, please contact our dedicated Fan Support specialists. Contact information can be found at the front of the instructions.
Page 21
(or according period of time as outlined by material). defecto por escrito debe ser recibida por WAC dentro de los cinco (5) años a partir de Excluded from warranty are any 3rd party component which carries its own la fecha de compra (o según el período de tiempo indicado en el material).
Page 22
WAC après autorisation écrite préalable du retour. L’obligation de WAC au titre de cette garantie ne s’étendra pas au-delà du prix d’achat initial du produit par le distributeur. En conséquence, tout dommage indirect ou tout coût de main-d’œuvre résultant d’un défaut est expressément exclu. Cette de manière inappropriée.
