Technical Support and E-Warranty Certificate
www.vevor.com/support
GARAGE WALL CABINET
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands
.
Advertisement
Table of Contents
Related Manuals for VEVOR FWC26
Summary of Contents for VEVOR FWC26
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support GARAGE WALL CABINET USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Warning - To reduce the risk of injury, user must read instructions manual carefully. 1. Do not allow children to climb on the unit. -Serious or fatal crushing injuries can occur from furniture tip-over. To prevent this, furniture must be permanently fixed to the wall. -
Page 4: Product Parameters
PRODUCT PARAMETERS 1) Name: Garage wall cabinet 2) Model: FWC26 3) G.W.: 15.5kg 4) Package Size: 740x730x120mm 5) Product Size: 26x12x26inch / 660x305x660mm 6) Total Load Limit: 240lbs 7) Load Limit for Each Shelf:120lbs PART LIST Name Parts Name Parts... -
Page 5: Assembly Step
Overcoil Attention: For additional information regarding the parts listed above, please refer to the Assembly Diagram of this manual. Unwrap and separate all parts in a clear work area. ASSEMBLY STEP 1. Take the product out of the packaging and open it. 2. - Page 6 3. Open the middle shelf and bottom shelf as shown in the following picture. The overcoil(Part E) was installed before leaving the factory, and there is no need for you to install it. 4. Install the magnet (part C) Install EVA(part J) stickers next to the magnet. The EVA of the upper and lower ends of the door frame are attached to the magnet, as shown in the figure.
- Page 7 6. Install the top shelf( part B). Please note that the top shelf should be hooked onto the side of the cabinet door first before being covered. 7. Install the garage wall cabinet onto the wall. Please note that the holes should be drilled accurately.
- Page 8 Technical Support and E-Warranty Certificate www.vevor.com/support...
