- Page 1 Operations and Maintenance Manual HAPP 25 Four Post Single point safety release Hydraulic Lift...
-
Page 2: Table Of Contents
These tests should be repeated monthly..............8 Troubleshooting ......................11 Australian and CE Standards ................... 12 To Our Customers ..................... 12 Safe operating procedures and installation ............... 12 © 2013- 2018 HAPP Australia Pty Ltd Version 2 P a g e... -
Page 3: Introduction
These documents are important as a base for documenting the regular training and maintenance by workshop personnel. To use this hoist in a workplace contact HAPP for the WH&S registration kit, you will need your serial number of the hoist. Only hoist owners that have the official HAPP company signed and sealed approval are considered WH&S approved by HAPP. -
Page 4: Operation
Vehicle hoists installed in such environments are not covered by HAPP warranty. Only HAPP hoists that are registered with HAPP and Workplace Health and Safety are to be used in business premises. In these locations, the HAPP registration label will be affixed to the hoist and supporting documentation is to be held on the business premises. -
Page 5: Operation
Disengage safety latches on each column with safety release lever • Push hydraulic release lever to lower Before working at any position ensure the raise procedure is followed and safety latches are engaged on all columns. © 2013- 2018 HAPP Australia Pty Ltd Version 2 P a g e... -
Page 6: Example Hoist Operation
Authorized personnel only! Do not restart the lift before the error has been remedied. If the lift load lies fully on the safety plates, manual lowering is not possible. © 2013- 2018 HAPP Australia Pty Ltd Version 2 P a g e... -
Page 7: Maintenance
Monthly check cables for broken strands and pulleys for proper operation. Lubricate with high pressure dry lube. Adjust cables to maintain even raising and lowering of vehicles. © 2013- 2018 HAPP Australia Pty Ltd Version 2 P a g e... -
Page 8: These Tests Should Be Repeated Monthly
This is a rare problem and should not be adjusted immediately. © 2013- 2018 HAPP Australia Pty Ltd Version 2 P a g e... - Page 9 Read over the entire process until you understand how to adjust the balance cables for lifting and lowering evenly. Adjust one cable at a time and take your time, observing changes as cables are adjusted. © 2013- 2018 HAPP Australia Pty Ltd Version 2 P a g e...
- Page 10 Continue to recheck the bolts for sound fixing and tight location of nuts with vehicles loaded for the first week and at regular intervals during operation of hoist. © 2013- 2018 HAPP Australia Pty Ltd Version 2 10 | P a g e...
-
Page 11: Troubleshooting
Lift tilts vehicle to one Lift cables not tight enough Retention cables. side on lifting / lowering. for lifting / lowering If vehicle will not lower evenly. © 2013- 2018 HAPP Australia Pty Ltd Version 2 11 | P a g e... -
Page 12: Australian And Ce Standards
It is a business responsibility to fully research and understand the details of work cover compliance in their location. In order for HAPP approved hoists to be used in a business workshop the hoist must be registered with HAPP and formal documentation indicating the serial numbered hoist is certified and that the hoist has been registered as a certified hoist will be supplied.
