Package List Package List Touchscreen Moun�ng Bracket Accelera�on Sensor Kits DC Power Cable A Micro-USB DC Power Cable B USB Flash Drive M3X12*2 M4X8*2 M4 nut*2...
Page 3
Touchscreen Pins Defini�on DC12~24V USB2.0 USB3.0 Type-C Accelerometer Power USB2.0 Accelerometer pin definition: DO 3-A7 3V3 GND Power: Press the Power button for more than 5s at power on satus, the klipper system will closed. Press the Power button for 1s at power off status, it will power on.
Page 4
Assembly Remove the screen Remove the display from the bracket on the right side of the base. Press diagonally upward to get it out of the holder. Please unplug the power cable Remove screen cable Remove screen...
Page 5
Assembly Install the Touchscreen Rotate the nut by 90° and Fixing the mounting bracket to snap it into the profile, then the profile with two M4X8 use a screwdriver to fasten screws and M4 nuts the screw. The ports are on the bottom Install the touchscreen on Slide the touchscreen downwards the bracket.
Page 6
Assembly Assembly Installing the screen power cord Unscrew the M4X20 screws Be careful to hold the power supply from the gantry profile with your hand to prevent it from falling down Note!!!! Connect the red and black wires to Remove the 4 screws from the corresponding locations on the the power supply case power supply...
Page 7
Assembly Connec�on harnesses Connecting the Micro USB cable Connecting the Display Power Cord Connect the micro usb cable and display power cable to the corresponding ports on the display Micro USB cable Screen power cable...
Page 8
Assembly Firmware update SV06 firmware.bin Copying files “ ”from USB flash drive to TF card Turn on the power Wait about 1 minute to refresh the firmware Enter the main interface and refresh successfully...
Page 9
Assembly Install Accelerometer X Part The accelerometer is an optional module, you can choose whether to install it according to your needs. To measure the X-axis acceleration, the following is the installation position of the accelerometer. Remove the M3 screw on the left side of the mounting plate Mount the accelerometer using a M3X12 screws as shown.
Page 10
Assembly Install Accelerometer Y Part The accelerometer is an optional module, you can choose whether to install it according to your needs. To measure the Y-axis acceleration, the following is the installation position of the accelerometer. Y Acceleration bracket downloads and SV06 prints from a USB flash drive Mount the acceleration sensor on the...
Bed Leveling Bed Leveling-1 1.After finish adjustment, Click *Machine leveling* on the home page. 2.Click * Z calibrate*. Please do not move a large distance at one time to avoid the nozzle hitting the hotbed. Click *start*, the printer will auto home first.
Page 12
Bed Leveling Bed Leveling-2 2.Click * Z Tilt*. 1.After finish adjustment, Click *Machine leveling* on the home page. The machine will auto-home first, then the entire X-axis will rise to the top for calibration, then descend to auto-home.
Page 13
Touchscreen Bed Leveling-3 1.Click * Machine Leveling * 2.Click *Bed Mesh*, then click *Calibrate* after the detection is complete, restart the system Leveling complete. If you want to view the bed mesh data later, please return to this interface and click the current configuration name "default“...
Page 14
Touchscreen Bed Leveling-4 1.The data of the bed reflects whether the bed is leveled. The detection data divides the hotbed into 25 small areas to detect the unevenness. When 0 means flat, the positive value means relatively high, and the negative value means relatively low.
Page 15
Slicer Preparing to prin�ng Double-click to install Sovol-Cura in the TF card file Sovol3D_Cura-5.0.0-win64 Select to add SV06(Klipper)or SV06PLUS(Klipper) Slice and save the file to USB flash drive...
Page 16
