CMT ORANGE TOOLS DHG-001 Manual

Digital height gauge (mm/inch/fraction)
Hide thumbs Also See for DHG-001:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual
DHG-001
EN
Digital height gauge (mm/inch/fraction)
ES
Medidor de altura digital (mm/pulgadas/fracciones)
FR
Jauge de hauteur numérique (mm/pouces/fractions)
IT
Calibro digitale per utensili (mm/pollici/frazioni)
Battery NOT INCLUDED (CR2032-3V) / Batería NO INCLUIDA (CR2032-3V)
Batterie NON INCLUSE (CR2032-3V) / Batteria NON INCLUSA (CR2032-3V)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DHG-001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CMT ORANGE TOOLS DHG-001

Summary of Contents for CMT ORANGE TOOLS DHG-001

  • Page 1 DHG-001 Digital height gauge (mm/inch/fraction) Medidor de altura digital (mm/pulgadas/fracciones) Jauge de hauteur numérique (mm/pouces/fractions) Calibro digitale per utensili (mm/pollici/frazioni) Battery NOT INCLUDED (CR2032-3V) / Batería NO INCLUIDA (CR2032-3V) Batterie NON INCLUSE (CR2032-3V) / Batteria NON INCLUSA (CR2032-3V)

  • Page 2: Part Description

    DHG-001 1. PART DESCRIPTION Graduated ruler Battery Slot Locking Knob LCD Display INC ABS in mm mm/inch/fraction Button INC/ABS Button mm/inch/fraction ON/OFF INC/ABS Gauge Base ON/OFF Button Display Unit Depth Pin Magnets 2. SPECIFICATIONS DATA & LED SCREEN ICONS Measuring Range 0~80mm (0~3-1/8”)

  • Page 3: Battery Installation And Replacement

    DHG-001 4. BATTERY INSTALLATION AND REPLACEMENT (1) To install or replace battery, push up the tabs on top of the Display Unit with two fingers (Fig.1). (2) Pull out battery holder (Fig.2) (3) Insert the new battery type CR2032-3V; Check out battery polarity (Fig.3).
  • Page 4 DHG-001 1. PARTES DEL MEDIDOR Regla Escalada Compartimento de la batería Tornillo de bloqueo Pantalla LCD Bóton de medición Botón milímetros/ INC ABS in mm incremental pulgadas/fracciones y absoluta mm/inch/fraction Cuerpo ON/OFF INC/ABS del medidor Botón ON/OFF Unidad de visualización...

  • Page 5: Operación

    DHG-001 4. INSTALACIÓN Y CAMBIO DE LA BATERÍA (1) Para instalar o reemplazar la batería levante la lengüeta sobre la pantalla. Vea imagen 1. (2) Levante el soporte para la batería. Vea imagen 2. (3) Quiete la batería y inserte un nuevo tipo CR2032-3V; Controle la polaridad. Vea imagen 3.

  • Page 6: Présentation De L'outil

    DHG-001 1.PRÉSENTATION DE L’OUTIL Rrègle graduée Logement de la batterie Vis de blocage Écran LCD Bouton Bouton de sélection de mesure millimètres/pouces/ INC ABS in mm incrémentale fractions et absolue mm/inch/fraction ON/OFF INC/ABS Bouton Marche/Arrêt Base de la jauge Unité...

  • Page 7: Opération

    DHG-001 4. INSTALLATION / REMPLACEMENT DE LA PILE (1) Pour installer ou remplacer la pile, poussez vers le haut les languettes situées sur le dessus de l’unité d’affichage à l’aide de deux doigts (voir Fig. 1). (2) Retirez complètement le support de pile (voir Fig. 2).

  • Page 8: Funzioni Dei Pulsanti

    DHG-001 1. PARTI DEL CALIBRO Riga graduata Vano batteria Vite di bloccaggio Display LCD Pulsante per misurazione Pulsante INC ABS in mm incrementale/ millimetri/pollici/frazione assoluta mm/inch/fraction Pulsante accensione/ ON/OFF INC/ABS Base del calibro spegnimento Corpo Display 25.50 Perno di profondità...

  • Page 9: Risoluzione Dei Problemi

    DHG-001 4. INSTALLAZIONE E SOSTITUZIONE DELLA BATTERIA (1) Per installare o sostituire la batteria, tirare verso l’alto le due linguette sulla parte superiore del corpo display utilizzando due dita (Fig. 1). (2) Estrarre il portabatteria (Fig. 2). (3) Inserire la nuova batteria tipo CR2032-3V; verificare la polarità della batteria (Fig. 3).
  • Page 10 © C.M.T UTENSILI S.P.A. TM: CMT, the CMT logos, CMT ORANGE TOOLS and the orange color applied to the tool surfaces are trademarks of C.M.T. Utensili SpA. This document has been Este documento Document envoyé Questo documento sent for your personal...
