CMT ORANGE TOOLS DMM-001 Manual

Digital moisture meter
Hide thumbs Also See for DMM-001:
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual

Tools components

A
B
C
D
E
F
G
H
I
J
A
B
C
WOOD
www.cmtorangetools.com
DMM-001
K
D
HOLD
BLDG
E
Digital Moisture Meter
ENGLISH
TOOLS COMPONENTS
A - Protection cover
B - Pins
C - LCD screen
D - Mid moisture LED indicator
E - Low moisture LED indicator
F - Measuring mode button
G - Power button
H - High moisture LED indicator
I - Data hold button, hold button
to turn off the buzzer sound
J - Battery slot on the back
K - Protection caps for pins
TOOLS COMPONENTS
A - Low battery Indicator
B - Moist %
C - Wood mode selected
D - Data hold selected
E - Building material mode selected
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMM-001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CMT ORANGE TOOLS DMM-001

Summary of Contents for CMT ORANGE TOOLS DMM-001

  • Page 1 DMM-001 Digital Moisture Meter ENGLISH Tools components TOOLS COMPONENTS A - Protection cover B - Pins C - LCD screen D - Mid moisture LED indicator E - Low moisture LED indicator F - Measuring mode button G - Power button...

  • Page 2: Safety Instructions

    Digital Moisture Meter Introduction DMM-001 measures moisture content by detecting a material’s electrical resistivity using two pins. Measurement output is displayed on a practical LCD screen. Tool is easy to operate and carry and features a low consumption single chip smart design.

  • Page 3: Led Indicators

    • Red LED——>20%-33%, high moisture. Accuracy checking DMM-001 also features an accuracy checking function. Remove cover and protection caps, switch on tool and place the two pins into the two holes on the back of the cover. LCD will now display a value within 18.3%±1%. Value should not exceed that percentage. Should this happen, please have tool repaired.

  • Page 4: Specifications

    DMM-001 Digital Moisture Meter Specifications Product name Digital Moisture Meter Model DMM-001 Measuring range Wood 5~50% Measuring range 1.5~33% Building Material Measuring accuracy ±2% Backlight shut off In about 15 seconds Auto power off 3 minutes idle Low battery indicator <7V...
