- Page 1 Installation Guide Single-Control Bidet Faucet K-19481 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page “Français-1” Español, página “Español-1” 1050856-2-A...
-
Page 2: Tools And Materials
Replace waste or supply tubing if necessary. For new installations, install the faucet to the bidet before completing the bidet installation. Kohler Co. reserves the right to make revisions in the design of faucets without notice, as specified within the Price Book. 1050856-2-A... -
Page 3: Install The Faucet
Refer to the putty manufacturer’s instructions for proper application. Feed the faucet supply inlets through the faucet hole of the bidet, then properly position the faucet. Slide the washer and bracket over the mounting studs, then securely tighten the nuts to the mounting studs. Kohler Co. 1050856-2-A... - Page 4 From the top of the fixture, securely hand tighten the flange onto the drain body. Make sure the drain body seal hole is facing the back of the fixture, and securely tighten the nut. Remove any excess putty or sealant. 1050856-2-A Kohler Co.
- Page 5 Insert the lift rod into the hole in the body and then into the hole in the link. Tighten the thumbscrew onto the link so the lift rod knob extends 1/2″ (1.3 cm) above the lift rod hole. Kohler Co. 1050856-2-A...
-
Page 6: Installation Checkout
Lift and rotate the faucet handle to the full hot position, then the full cold position. Run water through the spout for about one minute to remove any debris. Check for leaks and repair as needed. Turn off the water. Reinstall the faucet aerator. 1050856-2-A Kohler Co. - Page 7 Rotate the valve stem clockwise to increase temperature, or counterclockwise to decrease temperature. Reinstall the locking ring into the inner geared ring. Reinstall the bonnet and handle to the faucet body. Test the setting and make any adjustments as needed. Kohler Co. 1050856-2-A...
- Page 8 Optional Temperature Limiting Adjustment (cont.) After all adjustments have been made, use a hex wrench to tighten the setscrew. Press the plug button into place. 1050856-2-A Kohler Co.
