Page 3: Table Of Contents
Loading paper into the Paper Feeder Unit PF-602m................5-5 5.1.3 Loading Paper in Post Inserter of Folding Unit FD-503..............5-6 Paper Setting........................... 5-7 5.2.1 Specifying paper information for a tray....................5-7 Printer Driver Setting ........................5-12 5.3.1 Printer driver functions........................5-12 bizhub PRESS C1070series (IC-415/IC-308) Contents-1...
Page 4 8.4.2 Feeding-related optional devices......................8-16 8.4.3 Output-related optional devices .......................8-22 8.4.4 Electronic optional devices .......................8-40 8.4.5 Original-related optional devices ......................8-41 Weight for each size and copying speed..................8-42 Maximum paper size and printing area ..................8-45 Contents-2 bizhub PRESS C1070series (IC-415/IC-308)
Page 5: Introduction
Introduction...
Page 7: Intended Use Of This Machine
The user's guides are intended for the following users of the system: Operator: Person who has been trained by Konica Minolta or authorized partner to operate the system for its intended use as well as manage consumables, and perform the maintenance and troubleshooting described in user's guides.
Page 8: Configuration And Usage Of This Guide
This guide describes basic operations of this machine, how to in- er] (This Guide) stall the printer driver and applications required to use the Image Controller IC-415 or Image Controller IC-308, and how to replace consumables. [Safety Information] This guide provides precautions and requests that should be fol- lowed to ensure safe usage of this machine.
Page 9: Html User's Guide Operating Environment
Note that some of the functions may not work normally depending on your system environment. Please be forewarned. Problems may be able to be solved by using the latest Web browser. Display resolution 1,024 e 768 pixels or more bizhub PRESS C1070series (IC-415/IC-308)
Page 10: Conventions Used In This Guide
Reverse Automatic Document Feed- er DF-626 Saddle Stitcher SD-506 Saddle Stitcher Saddle Stitcher SD-510 The convention above is also applied to other optional devices. NOTICE The Image Controller IC-308 is not compatible with the bizhub PRO C1060L. bizhub PRESS C1070series (IC-415/IC-308)
Page 11: Make A Note About This Machine Information
Electronic optional devices Image Controller IC-602 Authentication Unit AU-201 Image Controller IC-415 Authentication Unit AU-201S Image Controller IC-308 Original-related optional devices Reverse Automatic Document Feeder Original Cover OC-509 DF-626 The available optional devices vary depending on your model. bizhub PRESS C1070series (IC-415/IC-308)
Page 12: Checking Network Information
To check network information, the administrator privilege may be required. Contact your machine ad- ministrator. NOTICE Some notes may include confidential information. Handle this guide with great care. In particular, do not enter information such as the password. Item Entry field Example: JSP port number Example: 30081 bizhub PRESS C1070series (IC-415/IC-308)
Page 13: Before Getting Started
Before Getting Started...
Page 15: Turning The Power On/Off
When the main power switch is turned on, the Power LED on the control panel lights up in red. Turn on the sub power switch on the upper-right corner of the main body. When the sub power switch is turned on, the Power LED on the control panel lights up in green. bizhub PRESS C1070series (IC-415/IC-308)
Page 16 When [Ready to print] is displayed on the [MA- CHINE] screen, you can use this machine. Turn the image controller on. % For Image Controller IC-415, turn the power switch in the rear side on ( ), then press the button on the top of the...
Page 17 Turning the Power ON/OFF Turning the power off (Image Controller IC-415) On the [MACHINE] screen, press [Controller]. Press [Login]. Select [Administrator] or [Operator], enter the password, then press [Login]. The default password is "Fiery.1". If you select [Operator], you do not need to enter the password.
Page 18 If the main power switch is turned on again within 10 seconds, the machine may not function normally. Turn the power switch in the rear side off. NOTICE After this machine has exited completely, turn Image Control- ler IC-415 off. bizhub PRESS C1070series (IC-415/IC-308)
Page 19 4, then select [Shut Down System] ( NOTICE After this machine has exited completely, turn the Image Con- troller IC-308 system off. When the system has quit, turn the power switch in the rear side off ( bizhub PRESS C1070series (IC-415/IC-308)
Page 20: Power Saving Function
Monochrome Energy-save Mode For monochrome printing, you can carry out it in energy-save mode. Weekly Timer Automatically turns the power of this machine on or off based on the specified time or day of the week. bizhub PRESS C1070series (IC-415/IC-308)
Page 21 For details about how to configure and use the above functions, refer to the [HTML User's Guide]. NOTICE If this machine is turned off because the Weekly Timer has started, job data is not received even if it is sent. While this machine can be used normally, send job data again. bizhub PRESS C1070series (IC-415/IC-308)
Page 22: Available Operations In This Machine
You can specify conditions such as the original scan setting, paper size, or the finish setting to copy data. More originals can be scanned in a short time by mounting an optional ADF. Tips Copy functions are not available in the Printer model. 2-10 bizhub PRESS C1070series (IC-415/IC-308)
Page 23: Scan Functions
WebTools is a device control utility program provided by the HTTP server built in the image controller. You can access an Image Controller via the network using the Web browser of the computer to check the status of this machine or configure various settings from WebTools. bizhub PRESS C1070series (IC-415/IC-308) 2-11...
Page 24: Application Functions
The [Device Center] tab provides the functions for the administrator. You can check or set the settings of the image controller, set up the color, adjust the tray, define the paper or view the job log. 2-12 bizhub PRESS C1070series (IC-415/IC-308)
Page 25: Printer Delete Utility
For details about how to use this application, refer to the User's Guide supplied with the Fiery Color Server. bizhub PRESS C1070series (IC-415/IC-308) 2-13...
Page 26 Available Operations in this Machine 2-14 bizhub PRESS C1070series (IC-415/IC-308)
Page 27: Let's Make Prints
Let's Make Prints...
Page 29: Printing Flow
To load paper into another optional device: Refer to page 5-6. 3.1.3 Step 3: Configure information of the paper loaded into a tray in this machine Specify the type, size, weight, and other values of paper. For details, refer to page 5-7. bizhub PRESS C1070series (IC-415/IC-308)
Page 30: Step 4: Use The Printer Driver To Print Data
Step 5: Check the finishing Check the image quality reproducibility, printing position misalignment, fold or staple position, and other items after printing data. For information about finishing checkpoints and adjustment proce- dures, refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308)
Page 31: Installing Software
Installing Software...
Page 33: Installing The Printer Driver
This driver is commonly used in applications where good color reproducibility is important. This driver provides various configurable functions com- pared with the PPD driver. The PostScript 3 driver is also compatible with Adobe PDF Print Engine (APPE) 2.5 and PCL interpreter. bizhub PRESS C1070series (IC-415/IC-308)
Page 34: In A Windows Environment
% When using your computer as a printer server, click [Share this printer so that others on your net- work can find and use it], then enter the share name. When printing a test page, click [Print a test page]. Check the test page printing result. Then, click [Close]. bizhub PRESS C1070series (IC-415/IC-308)
Page 35: Default Setting
Acquire optional information from the main body, then apply it to the setting of [Installed Options]. % If you have failed to acquire optional information, check the network setting. Click [OK]. The optional information setting of the machine is then completed. bizhub PRESS C1070series (IC-415/IC-308)
Page 36: In A Macintosh Environment
% In OS X 10.9/10.10/10.11, click the [Printer & Scanner]. Click [+]. % If the menu appears, select [Add Printer or Scanner]. Click [Default]. Connected printers are detected. If no printer is detected, restart this machine. bizhub PRESS C1070series (IC-415/IC-308)
Page 37 Select the name of the installed printer, then click [Options & Supplies] - [Driver]. % In OS X 10.9/10.10/10.11, click the [Options]. Configure optional information of this machine. Click [OK]. The optional information setting of the machine is then completed. bizhub PRESS C1070series (IC-415/IC-308)
Page 38: Installing Applications
Because the print attributes frequently used are stored in a folder in advance, you do not need to specify attributes for each printing, enabling to work in an efficient manner. Reference For details, refer to the User's Guide supplied with the Fiery Color Server. bizhub PRESS C1070series (IC-415/IC-308)
Page 39: In A Windows Environment
Check the total size of the software to install, then click [Next]. % If the [Windows Security] window is displayed, click [Install]. Click [Yes. Now, restart the computer.], then click [Finish]. When the computer restarts, installation is completed. bizhub PRESS C1070series (IC-415/IC-308)
Page 40: In A Macintosh Environment
Click [Install]. % The screen for entering [Name] and [Password] is displayed during processing. Enter the computer administrator's name and password into the respective fields. When the installation has been completed, click [Close]. Installation is completed. 4-10 bizhub PRESS C1070series (IC-415/IC-308)
Page 41: Starting Applications
% You can also specify any subnetwork or the IP address range to search for the desired Fiery Color Server. For details, refer to the User's Guide supplied with the Fiery Color Server. Click [Connect]. Fiery Remote Scan starts, and you can import a scan file. bizhub PRESS C1070series (IC-415/IC-308) 4-11...
Page 42: Starting Fiery Hot Folders
% In Windows 8.1/Server 2012 R2, on the Start window, click , then click [All Apps] - [Fiery Hot Folders]. % In Macintosh, select [Go] menu - [Applications] - [Fiery] - [Hot Folders], then double-click [Fiery Hot Folders Console]. 4-12 bizhub PRESS C1070series (IC-415/IC-308)
Page 43: Basic Operations
Basic Operations...
Page 45: Loading Paper
To fix the side guide plates at the correct locations, load an appropriate amount of paper into the tray while aligning it to the right-hand side of the tray. NOTICE Load paper with the print side facing down. bizhub PRESS C1070series (IC-415/IC-308)
Page 46 [MA- CHINE] or [COPY] screen. NOTICE Carefully close the tray. Otherwise, the machine may be subjected to an unexpected impact due to the tray or paper weight, which may lead to a machine error. bizhub PRESS C1070series (IC-415/IC-308)
Page 47: Loading Paper Into The Paper Feeder Unit Pf-602M
NOTICE Load paper with the print side facing up. Press the side guide plates against paper, then turn the side guide lock knobs (4 pieces) clockwise to fix them. bizhub PRESS C1070series (IC-415/IC-308)
Page 48: Loading Paper In Post Inserter Of Folding Unit Fd-503
NOTICE Do not load more than 500 sheets (80 g/m / 21 lb Bond) for each of the upper and lower trays. Also, do not load above the limit line indicated on the tray guide plates. bizhub PRESS C1070series (IC-415/IC-308)
Page 49: Paper Setting
Press [Paper Setting] on the [MACHINE] screen. % You can also press [Paper Setting] on the [COPY] screen to specify the required size. Select the tray with paper loaded, then press [Change Set]. Press [Paper Type] to select the desired paper type. bizhub PRESS C1070series (IC-415/IC-308)
Page 50 To identify these sizes as one size so that they can be judged by the machine, you can select the size to be detected in [Detect Size Setting]. bizhub PRESS C1070series (IC-415/IC-308)
Page 51 % You can name and register the size specified in [Size Registration]. % To recall the registered size, select [Size Recall]. % Item (3) is not displayed depending on the mounted optional device. % [Tab Paper]: Specify the paper size and the number of tabs. bizhub PRESS C1070series (IC-415/IC-308)
Page 52 % This step is not required if you select [Cus- tom] or [Tab Paper]. Press [OK]. This returns to the [Change Individual Set] screen. Specify other items, if necessary. Press [OK]. This returns to the [Paper Setting] screen. 5-10 bizhub PRESS C1070series (IC-415/IC-308)
Page 53 For details about setting items, refer to the [HTML User's Guide]. Tips To register paper conditions in a paper profile, press [Register]. For details about how to register a paper profile, refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308) 5-11...
Page 54: Printer Driver Setting
Before selecting the color mode, execute calibration. For details, refer to page 6-37. The color mode can also be specified in [Color Setup] of Fiery Command WorkStation. For details, refer to the User's Guide supplied with the Fiery Color Server. 5-12 bizhub PRESS C1070series (IC-415/IC-308)
Page 55 [Basic Settings]. You can also change the setting for each print job. Reference You also select [Color Setup] of Fiery Command WorkStation to configure [Basic Settings] in the color mode. For details, refer to the User's Guide supplied with the Fiery Color Server. bizhub PRESS C1070series (IC-415/IC-308) 5-13...
Page 56 You can also change the setting for each print job. Reference You can also select [Color Setup] of Fiery Command WorkStation to configure [Expert Settings] in the color mode. For details, refer to the User's Guide supplied with the Fiery Color Server. 5-14 bizhub PRESS C1070series (IC-415/IC-308)
Page 57: Maintaining The Finishing Quality
Maintaining the Finishing Quality...
Page 59: Both Sides Adjustment
Two methods are available to carry out the Both Sides Adjustment: entering from [Paper Setting] and from [Both Sides] on the [MACHINE] screen. This guide describes how to enter from [Paper Setting] for adjustment. Reference For information about how to enter from [Both Sides], refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308)
Page 60: Adjustment Flow
You can change the default screen of the [Both Sides Adjust] screen. For more information, contact your ser- vice representative. (In bizhub PRESS C1070P/bizhub PRESS C71hc, you cannot set the [Scan Meas.] ad- justment screen to the default.) bizhub PRESS C1070series (IC-415/IC-308)
Page 61: Making The Both Sides Adjustment For Each Tray
The [Scan Meas.] adjustment is a simple method to adjust only the magnification ratio and image position of the back side. To adjust both front and back sides, perform the "Chart Adjustment" (page 6-16) or "Zoom and Image Shift Adjustment" (page 6-22). Press [Paper Setting] on the [MACHINE] screen. bizhub PRESS C1070series (IC-415/IC-308)
Page 62 Select a tray loaded with A3 or larger, or 11 e 17 or larger paper. You can also change the print count, but only one sheet is needed. If the background sheet size is smaller than A3 or 11 e 17, the scan measurement may not be performed. bizhub PRESS C1070series (IC-415/IC-308)
Page 63 20 adjustment charts can be scan-measured continuously. Press Start on the control panel. Adjustment charts are printed on both sides of the paper in the tray you selected in Step 2. bizhub PRESS C1070series (IC-415/IC-308)
Page 64 2 inches (approximately 5 cm) away from the vertical size guide and horizontal size guide respectively on the Original Glass making sure that the left and top sides are parallel to the vertical size guide and horizontal size guide respectively. front front bizhub PRESS C1070series (IC-415/IC-308)
Page 65 % If you press [Return] on the Scan Adjustment Chart screen during scan measurement, a message is displayed to confirm whether to interrupt the scan measurement. To discard the previous meas- urement result, press [Yes]. Retry the scanning process from the first scan measurement. When continuing scan measurement, press [No]. bizhub PRESS C1070series (IC-415/IC-308)
Page 66 (turned away from the original glass), with its bottom edge posi- tioned to the back side. When four times of scanning are completed, a dialog is displayed to calculate the adjustment value. 6-10 bizhub PRESS C1070series (IC-415/IC-308)
Page 67 Press [Close] to exit the adjustment. Scan Measurement Adjustment is then com- pleted. % To register adjustment values in a paper profile, press [Register]. % For details about how to register a paper profile, refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308) 6-11...
Page 68: Gap Adjustment
"Chart Adjustment" (page 6-16) or "Zoom and Image Shift Adjust- ment" (page 6-22). Press [Paper Setting] on the [MACHINE] screen. Select the tray with the target paper loaded, then press [Change Set]. Press [Both Sides Adj]. 6-12 bizhub PRESS C1070series (IC-415/IC-308)
Page 69 - [5] - [+/-] to enter "-1.5" as the adjustment value. Then, the blue line on the back side will be moved 1.5 mm toward the minus side. % Write down the measured values so that you do not forget them. bizhub PRESS C1070series (IC-415/IC-308) 6-13...
Page 70 A test chart is printed out. Check a gap of the printing position refering the printed out chart. % Repeat steps 7 to 10 until all gaps between the front and back sides are cleared. 6-14 bizhub PRESS C1070series (IC-415/IC-308)
Page 71 Press [Close] to exit the adjustment. Gap Adjustment is then completed. % To register adjustment values in a paper profile, press [Register]. % For details about how to register a paper profile, refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308) 6-15...
Page 72: Chart Adjustment
Press [Paper Setting] on the [MACHINE] screen. Select the tray with the target paper loaded, then press [Change Set]. Press [Both Sides Adj]. 6-16 bizhub PRESS C1070series (IC-415/IC-308)
Page 73 Both Sides Adjustment Select [Front], then press [Chart Adjustment]. Press [Print Mode]. When the [PRINT MODE] screen is displayed, press Start on the control panel. A test chart is printed out. Press [Exit Print Mode]. bizhub PRESS C1070series (IC-415/IC-308) 6-17...
Page 74 [ 6 ] [ 8 ] [ 3 ] [ 4 ] Press each point number, then enter the measured length using the keypad, [,], or [+] on the screen. % To reset a value, press [Clear]. 6-18 bizhub PRESS C1070series (IC-415/IC-308)
Page 75 % In the next step, adjust the back side. Select [Back], then press [Chart Adjustment]. Press [Print Mode]. When the [PRINT MODE] screen is displayed, press Start on the control panel. A test chart is printed out. bizhub PRESS C1070series (IC-415/IC-308) 6-19...
Page 76 2.0 mm toward the minus side of the X direction and 1.5 mm toward the plus side of the Y direction. % Write down the measured values so that you do not forget them. 6-20 bizhub PRESS C1070series (IC-415/IC-308)
Page 77 When entry processing is completed, press [Adjustment Start]. After the adjustment is completed, press [OK]. % To finely adjust the adjustment value, con- tinuously proceed to step 4 in "Zoom and Image Shift Adjustment" (page 6-22). bizhub PRESS C1070series (IC-415/IC-308) 6-21...
Page 78: Zoom And Image Shift Adjustment
Press [Paper Setting] on the [MACHINE] screen. Select the tray with the target paper loaded, then press [Change Set]. 6-22 bizhub PRESS C1070series (IC-415/IC-308)
Page 79 The adjustment value changes 0.1 mm on a 1-step basis. Adjustment range: [Up/Down] -10.0 to +10.0, [Right/Left] -3.0 to +3.0 % To switch the positive mark (+) and negative mark (-), press [+/-]. % To reset a value, press [Clear]. bizhub PRESS C1070series (IC-415/IC-308) 6-23...
Page 80 [+0.5 mm]. % Next, press [Right/Left], then press [3] and [+/-] in sequence to set the adjustment value to [-0.3 mm]. The image on the back side shifts 0.5 mm up- ward and 0.3 mm leftward. 6-24 bizhub PRESS C1070series (IC-415/IC-308)
Page 81 If printing positions are misaligned between the front and back sides even after the Both Sides Adjust- ment has been carried out several times, readjust the reference position on the print side. For details about the adjustment procedure, refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308) 6-25...
Page 82: Image Quality Adjustment
Execute this method at the time of installation or when changing conditions such as the screen. If you use this application when you cannot obtain the stable image quality after calibration, the image quality may be enhanced. For details, refer to page 6-38. 6-26 bizhub PRESS C1070series (IC-415/IC-308)
Page 83: Daily Image Quality Management (Calibration)
(page 6-38). When print density is high When print density is low Current measurement value Reference value of target Input (%) Input (%) Adjust the printing density to the reference value Input (%) Consistent printing result bizhub PRESS C1070series (IC-415/IC-308) 6-27...
Page 84: Calibration Timing
(page 6-37) trol] (page 6-32) Calibrates the color reproducibility that fluctu- ates from day to day. [Color Density Control]: Select [Basic Setting], then set [Periodical Adj. Execution] to [ON]. If necessary, execute [Color Density Manual Control]. 6-28 bizhub PRESS C1070series (IC-415/IC-308)
Page 85 To use [Each Paper Type Color Adj.] in [Color Density Control] while the Relay Unit RU-509 is installed, ex- ecute [Each Paper Type Color Adj.] to configure tray settings before this procedure. For details, refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308) 6-29...
Page 86: Maximum Density Auto Adjustment (Ru)
After image stabilization control is completed, you must carry out calibration us- ing the image controller. Then, carry out Color Density Manual Control (page 6-35). Press [Adjustment] on the [MACHINE] screen. Press [Max.Density Auto Adj. (RU)]. Press [Print Mode]. 6-30 bizhub PRESS C1070series (IC-415/IC-308)
Page 87 For more information, contact your service representative. Then, carry out Color Density Manual Control (page 6-35). bizhub PRESS C1070series (IC-415/IC-308) 6-31...
Page 88: Auto Setting Of Color Density Control
Calibration is executed every arbitrarily specified number of sheets, and you can keep printing using the ap- propriate density. Tips The printed chart is included in the print count. Auto setting of Color Density Control Press [Adjustment] on the [MACHINE] screen. Press [Color Density Control]. Press [Basic Setting]. 6-32 bizhub PRESS C1070series (IC-415/IC-308)
Page 89 Specify each item as follows: % [Switch Color (1st or 2nd)] ... [Precise] NOTICE Select [Precise] or [Normal] depending on the situation. To ensure quality, [Precise] is appro- priate. For details, refer to the [HTML User's Guide]. Press [OK]. bizhub PRESS C1070series (IC-415/IC-308) 6-33...
Page 90 Image Quality Adjustment Press [Close]. Press [Exit [ADJUSTMENT]]. Automatic Adjustment is set. A chart is printed out periodically, and calibra- tion is carried out automatically. Tips Selecting [Color Density Manual Control] can carry out the manual adjustment. 6-34 bizhub PRESS C1070series (IC-415/IC-308)
Page 91: Manual Setting Of Color Density Manual Control
Press [Adjustment] on the [MACHINE] screen. Press [Color Density Control]. Press [Color Density Manual Control]. This function is available only when [Use Color Density Control] is set to [ON] in [Color Density Control] - [Basic Setting]. Press [Print Mode]. bizhub PRESS C1070series (IC-415/IC-308) 6-35...
Page 92 Image Quality Adjustment Press [Quality Adj.]. Press [)] of [Screen Pattern] to select a screen. Press [Close]. Press Start. A chart is printed out, and calibration is carried out. 6-36 bizhub PRESS C1070series (IC-415/IC-308)
Page 93: Executing Calibration Using The Image Controller
% When a strip is measured successfully, a check mark is displayed at the side of the color name, and is displayed for the color to be measured next. % Measure colors in the order displayed in the measurement screen. When all the patches have been read successfully, click [Continue]. bizhub PRESS C1070series (IC-415/IC-308) 6-37...
Page 94: Specifying The Reference Image Quality
"STEP2. Gamma Automatic Adj." when restarting the adjustment, then execute "STEP4. Color Density Control". If sufficient adjustment results are not obtained via daily maintenance, also carry out the adjustment in this order. For details about the setting procedure, refer to the [HTML User's Guide]. 6-38 bizhub PRESS C1070series (IC-415/IC-308)
Page 95: Adjusting The Finisher And Saddle Stitcher
When the finisher or saddle stitcher is mounted on this machine, you can finely adjust various functions such as fold positions or staple positions. Reference For details about how to adjust the finisher, refer to the [HTML User's Guide]. Press [Adjustment] on the [MACHINE] screen. Press [Finisher Adjustment]. bizhub PRESS C1070series (IC-415/IC-308) 6-39...
Page 96 Adjusting the Finisher and Saddle Stitcher Press the items to be adjusted. % The items displayed on this screen vary depending on the model of the mounted finisher. 6-40 bizhub PRESS C1070series (IC-415/IC-308)
Page 97: Adjustable Settings
Adjusts the tray size of the post inserter. [Output Quantity Limit] Sets the maximum number of pages to be printed. [Curl Adjustment] Adjusts paper curling for each folding type when the Relay Unit is not used. bizhub PRESS C1070series (IC-415/IC-308) 6-41...
Page 98 Adjusting the Finisher and Saddle Stitcher 6-42 bizhub PRESS C1070series (IC-415/IC-308)
Page 99: Troubleshooting
Troubleshooting...
Page 101: Replenish And Replace Consumables
[MACHINE] screen, and the color of the exhausted toner is displayed in red on the [Consumable and Scrap Indicators] display. Tips This machine contains a toner storage container that contains spare toner to prevent a print job from being interrupted during printing even if toner in the toner bottle becomes exhausted. bizhub PRESS C1070series (IC-415/IC-308)
Page 102 % The number on the right-hand side of the help message indicates a replacement procedure. To dis- play the next step, press [,]. % Attach the cap of a new toner bottle to the used toner bottle, then place it into the package. For the subsequent treatment, contact your service representative. bizhub PRESS C1070series (IC-415/IC-308)
Page 103: Replacing A Staple Cartridge
Help on the control panel to display the help message. % If you press the red row in the [Consumable and Scrap Indicators] display area of the touch panel, the window shown in step 3 is displayed directly. Press [Consumable/Scrap]. bizhub PRESS C1070series (IC-415/IC-308)
Page 104 To remove a staple cartridge, securely hold its right and left sides, and pull it out toward you. To install a staple cartridge, be careful not to mistake the top side for the bottom side. If the top side is facing down, the staple cartridge cannot be inserted. bizhub PRESS C1070series (IC-415/IC-308)
Page 105: Replacing A Waste Toner Box
Help on the control panel to display the help message. % If you press the red row in the [Consumable and Scrap Indicators] display area of the touch panel, the window shown in step 3 is displayed directly. Press [Consumable/Scrap]. bizhub PRESS C1070series (IC-415/IC-308)
Page 106 Press the [Waste Toner] tab, then follow the on-screen instructions to replace the waste toner box. % The number on the right-hand side of the help message indicates a replacement procedure. To dis- play the next step, press [,]. bizhub PRESS C1070series (IC-415/IC-308)
Page 107: Clearing Paper Jams
Tips Pressing [Close] changes to the [MACHINE] screen. Even while the [MACHINE] screen is being dis- played, a paper jam position is indicated by (red circle). Pressing [Confirm Details] changes to the [JAM Position] screen. bizhub PRESS C1070series (IC-415/IC-308)
Page 108: Illustration Screen For Jam Handling
Pressing [Next] can check the next step. Pressing [JAM Position] returns to the [JAM Po- sition] screen. Follow the guidance to remove jammed paper. Pressing [Next] can check the next step. Pressing [Previous] can check the previous step. 7-10 bizhub PRESS C1070series (IC-415/IC-308)
Page 109 - Open and close the door of the part indicated by the number on the touch panel again. This operation may clear the message. If the paper jam message still has not been cleared after checking the above, contact your service rep- resentative. bizhub PRESS C1070series (IC-415/IC-308) 7-11...
Page 110: If The Specified Paper Is Not Found
Select [Administrator] or [Operator], enter the password, then press [Login]. % If you select [Operator], you do not need to enter the password. Press [Force Print]. Press the tray in which print sheets are loaded. Printing starts using the selected tray. 7-12 bizhub PRESS C1070series (IC-415/IC-308)
Page 111: If An Error Has Been Displayed During Scanning
You can configure a setting to automatically delete data temporarily saved on the HDD at periodic in- tervals. To configure this setting, select [Administrator Setting] - [Security Setting] - [HDD Management Setting] - [Hold Job Auto Delete Period]. For details, refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308) 7-13...
Page 112: Hue Adjustment
Fusing Unit. In this case, adjust the image position (Both Sides Adjustment) again. Reference For details, refer to page 6-3. 7-14 bizhub PRESS C1070series (IC-415/IC-308)
Page 113: Appendix
Appendix...
Page 115: Good Use Of The [Html User's Guide]
These contents are included in each of the [Select from output results], [Adjust the output result], and [Utilize useful functions] on the top page (Home). They are always helpful for you. bizhub PRESS C1070series (IC-415/IC-308)
Page 116: Name Of Each Component
Tray 1, and up to 1,000 sheets (80 g/m / 21 lb Bond) into Tray 2. Waste toner box door Open when replacing a waste toner box. Front door Open when removing jammed paper or turning the main power switch on or off. bizhub PRESS C1070series (IC-415/IC-308)
Page 117 Power cord Supplies this machine with electricity. Image Controller IC-415 Required to use this machine as a printer or scanner with the Image Controller IC-415 mounted. Network port (1000Base- Connect the network cable to monitor this machine or re- T/100Base-T/10Base-T) motely operate the control panel using Web Utilities.
Page 118: Internal Components
Generates a print image. Conveyance fixing unit Pulled out to remove jammed paper. For information about how to handle levers and knobs of the conveyance fixing unit, refer to the screen displayed when a paper jam has occurred. bizhub PRESS C1070series (IC-415/IC-308)
Page 119 DO NOT pull out the toner bottle other than the time to exchange for running out of toner. If you pull out the toner bottle in which the toner remains, an area nearby may become dirty with toner. bizhub PRESS C1070series (IC-415/IC-308)
Page 120: Control Panel Layout
Proof Copy* Used to make a proof copy. Print data to check the adjusted image quality on the [Quality Adjustment] screen, or output a sample from the [Job Ticket Edit] screen. Start Starts each function operation. bizhub PRESS C1070series (IC-415/IC-308)
Page 121 *This function is not provided for the printer model. 7CAUTION Do not press hard or pointed objects against the touch panel. Otherwise, the glass may be scratched or break and you may be injured. Use fingers to operate the touch panel. bizhub PRESS C1070series (IC-415/IC-308)
Page 122 Otherwise, an unexpected trouble may be caused. Write down the report code as stated on the 2nd line of the message, turn off the sub power switch and main power switch in this order, then disconnect from the power socket. Contact your service representative and inform them of the report code. 8-10 bizhub PRESS C1070series (IC-415/IC-308)
Page 123: Convenient Use Of Scan Function (Scan To Smb)
Also, you can send data to your computer and the file server used for daily file transfer in order to share it. Tips Mac OS X 10.7 or later does not support the Scan to SMB function. Instead, use Scan to FTP. For de- tails, refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308) 8-11...
Page 124: Step 1: Prepare The Destination Computer
% The computer name is required to specify a destination. Write down the computer name so that you do not forget it. Check the user name. % For Image Controller IC-415 or Image Controller IC-308, "computer name (or domain name)\user name" is required. % In Windows Vista/7/Server 2008/Server 2008 R2, select [All Programs] - [Accessories] and open [Command Prompt].
Page 125: Step 2: Connect This Machine To The Network
You can also use the [Scan Address Register] on the [UTILITY] screen to register the setting. Reference For details about how to register destinations, refer to the [HTML User's Guide] or the user's guide supplied with Fiery Color Server. bizhub PRESS C1070series (IC-415/IC-308) 8-13...
Page 126: Step 5: Send Scan Data To A Public Folder
Start. Reference You can specify conditions such as the image quality and scanning size. For details about scan conditions, refer to the [HTML User's Guide] or the user's guide supplied with Fiery Color Server. 8-14 bizhub PRESS C1070series (IC-415/IC-308)
Page 127: Major Specifications
Up to 500 sheets (80 g/m / 21 lb Bond) can be loaded into Tray 1 (upper capacity tray), and up to 1,000 sheets (80 g/m / 21 lb Bond) into Tray 2 (lower tray). bizhub PRESS C1070series (IC-415/IC-308) 8-15...
Page 128: Feeding-Related Optional Devices
If the paper width is less than 139.7 mm / 5.5", use the small size guides. For details, refer to the [HTML User's Guide]. Storage capacity 3,000 sheets (80 g/m / 21 lb Bond) for each 8-16 bizhub PRESS C1070series (IC-415/IC-308)
Page 129 *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. Storage capacity Tray 3 (upper tray), Tray 4 (middle tray): 1,390 sheets (80 g/m / 21 lb Bond) Tray 5 (lower tray): 1,850 sheets (80 g/m / 21 lb Bond) bizhub PRESS C1070series (IC-415/IC-308) 8-17...
Page 130 You can change the detectable standard size. Also, you can select [ON] from [K Size] on the Utility/Counter screen to detect the K size. For details, refer to the [HTML User's Guide]. Storage capacity 2,500 sheets (80 g/m / 21 lb Bond) 8-18 bizhub PRESS C1070series (IC-415/IC-308)
Page 131 *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. Storage capacity 250 sheets (80 g/m / 21 lb Bond) (Load height: 27.5 mm / 1.08") Caution This option cannot be combined with Paper Feeder Unit. bizhub PRESS C1070series (IC-415/IC-308) 8-19...
Page 132: Post Inserter (Folding Unit Fd-503)
7.17" to 13.03", Length 5.47" to 19.02" *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. Storage capacity 500 sheets (80 g/m / 21 lb Bond) for each 8-20 bizhub PRESS C1070series (IC-415/IC-308)
Page 133 *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. Storage capacity 200 sheets (80 g/m / 21 lb Bond) or within 30 mm / 1.18" thick for the upper tray and lower tray each bizhub PRESS C1070series (IC-415/IC-308) 8-21...
Page 134: Output-Related Optional Devices
Custom: Width 100 mm to 330 mm, Length 140 mm to 487 mm / Width 3.94" to 12.99", Length 5.51" to 19.17" *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. 8-22 bizhub PRESS C1070series (IC-415/IC-308)
Page 135 *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. Relay Unit RU-516 Specifications Function Charge control Connection option Relay Unit RU-509, Finisher FS-531, Finisher FS-612 Relay Unit RU-517 Specifications Function Charge control Connection option Output Tray OT-502 bizhub PRESS C1070series (IC-415/IC-308) 8-23...
Page 136 Custom: Width 210 mm to 305 mm, Length 279 mm to 458 mm / Width 8.27" to 12.01", Length 10.98" to 18.03" Sheet volume Multi folder tray 30 copies or more (All fold types: 80 g/m / 21 lb Bond or less) 8-24 bizhub PRESS C1070series (IC-415/IC-308)
Page 137 Custom: Width 95 mm to 331 mm, Length 139 mm to 488 mm / Width 3.74" to 13.03", Length 5.47" to 19.21" *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. bizhub PRESS C1070series (IC-415/IC-308) 8-25...
Page 138 Custom: Width 95 mm to 331 mm, Length 139 mm to 488 mm / Width 3.74" to 13.03", Length 5.47" to 19.21" *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. 8-26 bizhub PRESS C1070series (IC-415/IC-308)
Page 139 / 36 lb Bond to 65 lb Bond: 2 sheets • Multi Tri-Fold 50 g/m to 81 g/m / 13 lb Bond to 22 lb Bond: 5 sheets 82 g/m to 91 g/m / 23 lb Bond to 24 lb Bond: 3 sheets bizhub PRESS C1070series (IC-415/IC-308) 8-27...
Page 140 Colored, Coated: max. 150 sheets, or within 15 mm / 0.59" thick Maximum number of Z-folded insertions: • 4 sheets or less for the duplex printing • 2 sheets or less for the simplex printing 8-28 bizhub PRESS C1070series (IC-415/IC-308)
Page 141 / 57 lb Bond to 80 lb Bond: 500 sheets Secondary (sub) tray 100 sheets (80 g/m / 21 lb Bond) *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. bizhub PRESS C1070series (IC-415/IC-308) 8-29...
Page 142 11 e 17 w, 8.5 e 14 w, 8.5 e 11 w/v, 7.25 e 10.5 w/v, 5.5 e 8.5 w, 8K w, 16K w/v, Foolscap* *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. Punch Kit PK-513 is available only in Sweden. 8-30 bizhub PRESS C1070series (IC-415/IC-308)
Page 143 5.5 e 8.5 w/v, 7.25 e 10.5 v, 16K v Secondary (sub) tray 300 sheets (80 g/m / 21 lb Bond) *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. bizhub PRESS C1070series (IC-415/IC-308) 8-31...
Page 144 30 sets (21 to 30 sheets stapled) • 25 sets (31 to 40 sheets stapled) • 20 sets (41 to 50 sheets stapled) • 15 sets (51 to 60 sheets stapled) • 10 sets (61 to 100 sheets stapled) 8-32 bizhub PRESS C1070series (IC-415/IC-308)
Page 145 / 58 lb Bond to 81 lb Bond: 1 sheets • Multi Tri-Fold 50 g/m to 91 g/m / 13 lb Bond to 24 lb Bond: 3 sheets 92 g/m to 105 g/m / 25 lb Bond to 28 lb Bond: 1 sheet bizhub PRESS C1070series (IC-415/IC-308) 8-33...
Page 146 500 sheets (80 g/m Secondary (sub) tray 100 sheets (80 g/m / 21 lb Bond) *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. 8-34 bizhub PRESS C1070series (IC-415/IC-308)
Page 147 Number of loadable sheets in Fold & Staple • 5-sheet stapled: 20 sets or more (80 g/m / 21 lb Bond), 15 sets or more when the paper length is 299 mm / 12" or less (80 g/m / 21 lb Bond) bizhub PRESS C1070series (IC-415/IC-308) 8-35...
Page 148 * Up to 3 sheets can be changed. For more information, contact your service representative. Specifications: Punch (with Punch Kit PK-512 or PK-513 installed) For the punch function specifications, refer to the specifications of Finisher FS-531. 8-36 bizhub PRESS C1070series (IC-415/IC-308)
Page 149 3.74" to 12.99", Length 5.47" to 19.21" Punch mode A4 v, 8.5 e 11 v • *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. bizhub PRESS C1070series (IC-415/IC-308) 8-37...
Page 150 / 20 lb Bond) + 2 covers (216 g/m / 57 lb Bond)Largest: 100 body sheets (75 g/m / 20 lb Bond) + 2 covers (216 g/m / 57 lb Bond) Bypass sheet size/weight Same as main body 8-38 bizhub PRESS C1070series (IC-415/IC-308)
Page 151 Maximum 1,054 mm (W) e 346 mm (D) e 28.5 mm (H) / 41.5" (W) e 13.62" (D) e 1.12" (H) Weight Feeding ex- 0.9 kg / 1.98 lb tension tray Output exten- 1.8 kg / 3.97 lb sion tray bizhub PRESS C1070series (IC-415/IC-308) 8-39...
Page 152: Electronic Optional Devices
User Authentication Unit for Non-Contact IC Card Reading Applied cards FeliCa, TypeA, FCF, FCF campus, SSFC Authentication Unit AU-201S Specifications Function User Authentication Unit for Non-Contact IC Card Reading Applied cards FeliCa, TypeA, FCF, FCF campus, SSFC 8-40 bizhub PRESS C1070series (IC-415/IC-308)
Page 153: Original-Related Optional Devices
11 e 17 w, 8.5 e 14 w, 8.5 e 11 w/v, 5.5 e 8.5 w/v, 8K w, 16K w/v, Fools- cap* *Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w. Storage capacity Max. 100 sheets (80 g/m / 21 lb Bond) bizhub PRESS C1070series (IC-415/IC-308) 8-41...
Page 154: Weight For Each Size And Copying Speed
93.5 86.5 104.0 177 to 216 / 48 to 57 − 111.0 − 125.0 217 to 256 / 58 to 68 − 139.0 − 153.0 257 to 300 / 69 to 81 − 167.0 − 8-42 bizhub PRESS C1070series (IC-415/IC-308)
Page 155: Copying Speed
106 to 135 / 29 to 36 51 pages 35 pages 136 to 176 / 37 to 47 177 to 216 / 48 to 57 217 to 256 / 58 to 68 35 pages 257 to 300/69 to 81 bizhub PRESS C1070series (IC-415/IC-308) 8-43...
Page 156 106 to 135 / 29 to 36 45 pages 30 pages 136 to 176 / 37 to 47 177 to 216 / 48 to 57 217 to 256 / 58 to 68 30 pages 257 to 300 / 69 to 81 8-44 bizhub PRESS C1070series (IC-415/IC-308)
Page 157: Maximum Paper Size And Printing Area
When this machine is equipped with the Banner Tray Unit MK-740: 1,200.0 mm / 47.24" Maximum printing area Crosswise direction: 323 mm / 12.72" Paper feed direction: 1,195 mm / 47.05" Tips For information about other paper trays, refer to the [HTML User's Guide]. bizhub PRESS C1070series (IC-415/IC-308) 8-45...
Page 158 Maximum paper size and printing area 8-46 bizhub PRESS C1070series (IC-415/IC-308)

This manual is also suitable for:

Ic-308

Konica Minolta IC-415 Quick Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Konica Minolta IC-415

Summary of Contents for Konica Minolta IC-415

This manual is also suitable for:

Table of Contents
