Monitor User Manual
Updated 4.16.2025
XMP Series
This manual is based on firmware version 3.1.07. If you have an
older or newer firmware version installed instructions may vary.
Flanders Scientific, Inc.
6215 Shiloh Crossing
Suite G
Alpharetta, GA. 30005
Phone: +1.678.835.4934
Fax: +1.678.804.1882
E-Mail:
Support@FlandersScientific.com
www.FlandersScientific.com
Advertisement
Table of Contents
Related Manuals for Flanders Scientific Inc. XMP Series
Summary of Contents for Flanders Scientific Inc. XMP Series
- Page 1 Monitor User Manual Updated 4.16.2025 XMP Series This manual is based on firmware version 3.1.07. If you have an older or newer firmware version installed instructions may vary. Flanders Scientific, Inc. 6215 Shiloh Crossing Suite G Alpharetta, GA. 30005 Phone: +1.678.835.4934 Fax: +1.678.804.1882...
-
Page 2: Table Of Contents
Contents TOPIC PAGE Safety Precautions Parts & Their Functions Menu Overview Menu - Function Menu Menu - Scopes Menu - Video Menu - Video - Pixel Mapping Menu - Color Menu - System Menu - OSD Dimensions Removable Feet and Mounting Info Appendix A - AutoCal Appendix B - IP Remote Control Appendix C - FAQ... -
Page 3: Safety Precautions
100nits or lower is ideal whenever possible. For cameras that do not support camera surround or frame line intensity customization you can use the XMP series Custom Marker capabilities to generate a translucent overlay to mute these elements to more reasonable levels. See the Custom Marker section of this manual for more details. - Page 4 Safety Precautions Connecting and Disconnecting SDI BNC Cables To prevent damage to components from electrical discharge follow these steps: • Connect power first on all devices. • Power on all devices. • Connect BNC cables. To disconnect: • Disconnect BNC cables. •...
- Page 5 Safety Precautions • If the product requires replacement parts, make sure that the service person uses replacement parts specified by the manufacturer, or those equivalent parts having the same characteristics and performance specifications as the original parts. Use of unauthorized parts can result in fire, electric shock, and/or other damage.
-
Page 6: Parts & Their Functions
Parts & Their Functions Keyboard • SDI 1: Used to select SDI Input 1 as the active Input. • SDI 2: Used to select SDI Input 2 as the active Input. • SDI 3: Used to select SDI Input 3 as the active Input. •... - Page 7 Parts & Their Functions Back Panel • SDI In: 4 Multi-Format 12G/6G/3G/HD-SDI Inputs. • SDI Out: 4 Looped 12G/6G/3G/HD-SDI Outputs. • MON Out: 4 processed MON outputs. If UHD Downscaling is enabled on the Vid- eo menu each output will provide a quarter sample resolution downscaled output of any 4K / UHD input.
-
Page 8: Menu Overview
Menu Navigating the Menu Pressing the MENU button on the monitor’s keypad will call up the on screen menu. To navigate use the UP and DOWN buttons and press the ENTER button to select the highlighted sub menu. Navigate the sub menu in the same way by using the UP and DOWN buttons to highlight a particular function and press ENTER to change that function’s setting. -
Page 9: Menu - Function Menu
Menu - Function Menu Area Marker Use the Area Marker function to toggle the configured Area Marker feature on or off. See the OSD section of this manual for details on setting up the preferred Area Marker. Safety Marker Use the Safety Marker function to toggle the configured Safety Marker feature on or off. See the OSD section of this manual for details on setting up the preferred Safety Marker. - Page 10 MON output will mirror that corresponding input’s assigned Look DIT LUT if enabled, effectively turning your XMP series monitor into a 4 channel LUT box not just for your onscreen image, but for your downstream MON outputs as well.
- Page 11 Menu - Function Menu Please note: loading profile configurations does NOT change function button assignments. The function buttons are independent of the profile configurations. See Save Profile and Load Profile sections in the System Menu portion of this manual for more details. Lum Coloring (Customizable Exposure Check) Enabling this function generates an artificial luminance map of the incoming source that can be particularly useful in identifying overexposed areas in any given shot.
-
Page 12: Menu - Scopes
Menu - Scope Menu Scope Menu Function Lum Style Scope Lum Position Bottom Right Video Luminance Color Vec Position Bottom Right System Vector Lum Position & Vec Position Use Lum & Vec Position to select in what area of the screen you would like your Scopes to be displayed. Lum Style Select IRE or HDR. -
Page 13: Menu - Video
Menu - Video Menu Video Menu Function Input SDI 1 Scope UHD Downscaling Video SDI Format AUTO Color Pixel Mapping System Deinterlace Mode INTERFIELD Color Mode Normal Input Inputs can be directly selected using the dedicated input buttons on the monitor’s keypad, but the active input can also be selected through the Video Menu. - Page 14 Menu - Video Menu Video Menu Function Input SDI 1 Scope UHD Downscaling Video SDI Format AUTO Color Pixel Mapping System Deinterlace Mode INTERFIELD Color Mode Normal Color Mode The Color Mode selection allows you to enable optional viewing modes that may be useful for various exposure, QC, and engineering tasks.
-
Page 15: Menu - Video - Pixel Mapping
Menu - Video Menu - Pixel Mapping Note: Using pixel mapping with a 4K source on a native 3840x2160 screen will cause a portion of video to not be displayed, but these modes can be used to display 4K signals 1:1 and view the Left, Right, or Center of the video signal. -
Page 16: Menu - Color
Menu - Color Menu Color Menu Function ColorSystem GaiaColor Scope Range Video 64-940 Video Gamut Color EOTF Gamma 2.4 System Temperature 6500K Luminance Mode 1000 Luminance Custom 3rdParty LUTMemory User1 ColorSystem The monitor features 2 Color System selections: GaiaColor and 3rd Party. GaiaColor is the default selection and what you should use unless you are specifically utilizing 3rd Party calibration software to build 3rd Party calibration LUTs. - Page 17 Menu - Color Menu For typical video range SDR workflows we suggest setting the monitor to Extended Video Range 64- 1019 whether your signal is configured to pass super-white levels (64-1019) or not (64-940). XMP monitors are optimized to offer the best SDR video range performance in Extended Video Range 64- 1019 mode and this one setting is compatible with both signals that contain super-white levels and those that do not.
- Page 18 Menu - Color Menu Temperature (GaiaColor Color System Only) Sets the white balance of the display. Select from 3200K, 5000K, 6000K (P3-D60), 6300K (P3-DCI), 6500K, or 9300K. 6500K is the default. GaiaColor AutoCal Select Start to begin a new Direct Connect Volumetric AutoCal. See AutoCal instructions for details. 3rd Party LUT Memory Does not apply to GaiaColor Color System.
- Page 19 Menu - Color Menu Display warm up recommendation If starting from a cold boot it is a best practice to allow the display to warmup before performing calibration or making color-critical decisions. If using GaiaColor AutoCal the warm up and stabilization routine will automatically be performed before any measurements are taken.
- Page 20 Menu - Color Menu When using the monitor as a GUI display via the DP In Port in combination with a system that reads EDID the monitor should be configured as follows: Color System: GaiaColor Gamut: P3 EOTF: 2.2 Temperature: 6500K Using this configuration allows the monitor to be configured to match what its EDID will report back to the connected computer.
- Page 21 Menu - Color Menu Color Menu Function ColorSystem GaiaColor Scope Range Video 64-940 Video Gamut Color EOTF Gamma 2.4 System Temperature 6500K Luminance Mode 1000 Luminance Custom 3rdParty LUTMemory User1 Note on Hue Preservation When set to a color space selection larger than the monitor can achieve the display will preserve proper hue tracking towards the selected gamut to the extent possible and will not shift hue at gamut clip.
-
Page 22: Menu - System
Menu - System Menu System Menu Function Update Firmware Allow Scope Current IP 192.168.1.5 Video Version 2.4.3 Color Serial Number P550A00001 System Payload ID 0.0.0.0 Profile Load Profile Save Set Static IP 192.168.1.5 192.168.1.5 IP Reset DHCP 255.255.255.0 Clear Panel Noise 192.168.1.1 Panel Dimming Apply Settings... - Page 23 Menu - System Menu System Menu Function Update Firmware Allow Scope Current IP 192.168.1.5 Video Version 2.4.3 Color Serial Number P550A00001 System Payload ID 0.0.0.0 Profile Load Profile Save Set Static IP 192.168.1.5 192.168.1.5 IP Reset DHCP 255.255.255.0 Clear Panel Noise 192.168.1.1 Panel Dimming Apply Settings...
- Page 24 Menu - System Menu System Menu Function Update Firmware Allow Scope Current IP 192.168.1.5 Video Version 2.4.3 Color Serial Number P550A00001 System Payload ID 0.0.0.0 Profile Load Profile Save Set Static IP 192.168.1.5 192.168.1.5 IP Reset DHCP 255.255.255.0 Clear Panel Noise 192.168.1.1 Panel Dimming Apply Settings...
-
Page 25: Menu - Osd
Menu - OSD Menu OSD Menu Function Status Position Top Left Scope Status Set Video Menu Position Top Left Color Menu Set System Menu Brightness Area Marker Safety Marker Center Marker Custom Marker Menu & Status Position Changes position of on-screen menu and signal status display. Menu Set Set menu to automatically disappear after 5s, 10s, or to stay On until manually cleared. - Page 26 Menu - OSD Menu OSD Menu Function Status Position Top Left Scope Status Set Video Menu Position Top Left Color Menu Set System Menu Brightness Area Marker Safety Marker Center Marker Custom Marker Menu Brightness Allows you to specify how bright the on screen menu will be displayed. Select any value between 5 and 100 to set the menu to your prefered selection.
- Page 27 Menu - OSD Menu Custom Marker File requirements: PNG Format 1920x1080 resolution Custom markers can be any 1920x1080 resolution PNG. Make sure to set any areas you wish to be visible as transparent in your PNG file. You may also define marker areas with different opacity levels by simply setting their opacity level within your PNG.
-
Page 28: Dimensions
XMP Dimensional Drawings All dimensions in mm. XMP310 weight approximately 17.8 lbs (8.0 Kg) All dimensions in mm. XMP550 weight approximately 43lbs (19.5Kg) All dimensions in mm. XMP650 weight approximately 56lbs (25.5kg) Return to Table of Contents © 2025 Flanders Scientific, Inc. -
Page 29: Removable Feet And Mounting Info
XMP Removable Feet and Mounting Info XMP series monitors have pedestal style feet that can be removed when monitor is wall mounted. The feet are held on by six screws per foot on the bottom. The XMP550 and XMP650 can be mounted with M6 screws using the 300mm x 200mm VESA mounting points. - Page 30 GaiaColor Direct Connect Volumetric AutoCal provides a simple and accurate way to calibrate your FSI monitor. On XMP series monitors this automatic calibration routine is currently compatible with the Colorimetry Research CR100, Klein K10A / K80, Minolta CA210* / CA310* / CA410, and the xRite i1D3DS OEM.
-
Page 31: Appendix A - Direct Connect Autocal
Appendix A - Direct Connect AutoCal The principle behind AutoCal is that the native, uncalibrated state of your display is profiled and saved to the monitor’s non-volatile memory. Then as any color management selections on the monitor are made calibrated states are calculated from that native profile and instantly applied on demand. Be- cause all selections are calculated from this one primary profile capture you can make any selection without having to rerun AutoCal. - Page 32 Appendix A - Direct Connect AutoCal Tips and Troubleshooting Issue / Topic Solution / Tip Monitor displays error This error can occur if the probe you are connecting does not match the message advising you to probe model you selected from the monitor’s menu when starting Auto- check probe connection matic Calibration.
- Page 33 Appendix A - Direct Connect AutoCal Tips and Troubleshooting Issue / Topic Solution / Tip Poor results or calibration When using the CR100 please ensure that Exposure Multiplier is set to failure when using CR100 1, Sync is set to Auto, Max Exposure is set to 500ms, and Max Flicker Frequency Search is set to 150Hz.
- Page 34 Appendix A - Direct Connect AutoCal Tips and Troubleshooting Question Answer Do customizable manual No, customized settings do not necessarily need to be reset before calibration settings need starting AutoCal, but importantly any custom settings will contin- to be reset before starting ue to impact your post calibration result if not returned to neutral.
-
Page 35: Appendix B - Ip Remote Control
Appendix B - IP Remote Control The monitor can be controlled over an ethernet connection using FSI’s IP Remote Utility (IPRU) application. The IPRU will allow you to control menu navigation, input selection, function button selection, and rotary knob control. The IPRU is also what you will use to load firmware updates. The IPRU can optionally be paired with a Stream Deck and sample Stream Deck profiles and instructions, as well as download links for the IPRU, can all be found at: https://flandersscientific.com/ip-remote/... -
Page 36: Appendix C - Faq
Appendix C - FAQ Question Answer Is a 13 second boot time normal? XMP series monitors take approximately 13 seconds to boot. This is normal and part of a multi- stage boot up process that helps preserve the life of components.
