MODEL 20631, 20631BT
20V MAX BRUSHLESS
RECIPROCATING SAW
Instruction Manual
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
1-847-429-9263 (M-F 8AM-5PM CST)
TECHSUPPORT@WENPRODUCTS.COM
IMPORTANT: Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
WENPRODUCTS.COM
For replacement parts and the most up-to-date instruction manuals, visit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 20631 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wen 20631

Summary of Contents for Wen 20631

  • Page 1 1-847-429-9263 (M-F 8AM-5PM CST) TECHSUPPORT@WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.

  • Page 2: Table Of Contents

    20V 5A Quick Charger (Model 20201Q) Replacement Blades (Part 20631-038) WEN plans to continue to add more items to our 20V line. For an up-to-date list of the 20V cordless tools compat- ible with the included battery and charger, visit wenproducts.com.

  • Page 3: Introduction

    **NOTE: Some tools may not be compatible with WEN 20V MAX 1.5Ah Batteries, model 49120B. Contact WEN customer service at 1-847-429-9263, M-F with questions. WEN plans to continue to add more items to our 20V line. For an up-to-date list of the 20V cordless tools compat- ible with the included battery and charger, visit wenproducts.com.

  • Page 4: Safety

    GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 5 GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

  • Page 6: Reciprocating Saw Safety Warnings

    RECIPROCATING SAW SAFETY WARNINGS WARNING! Do not operate the power tool until you have read and understood the following instructions and the warning labels. RECIPROCATING SAW SAFETY 9. Never cut pressurized tanks or any containers con- taining hazardous or flammable materials. 1.

  • Page 7: Electrical Information

    ELECTRICAL INFORMATION (CHARGER) DOUBLE-INSULATED CHARGER The charger’s electrical system is double-insulated where two systems of insulation are provided. This eliminates the need for the usual three-wire grounded power cord. Double-insulated tools do not need to be grounded, nor should a means for grounding be added to the product. All exposed metal parts are isolated from the internal metal components with protecting insulation.

  • Page 8: Battery & Charger Safety Warnings

    Never carry the charger by its cord or yank it by the cord battery chemicals. If the battery or charger are damaged, to disconnect it from the receptacle. Keep the cord away call WEN customer service at 1-847-429-9263 for as- from heat, oil and sharp edges. Make sure the cord will sistance.
  • Page 9 BATTERY & CHARGER SAFETY WARNINGS ABOUT THE BATTERY 1. The battery pack has to be charged completely before you use the tool for the first time. 2. For optimum battery performance, avoid low discharge cycles by charging the battery pack frequently. 3.

  • Page 10: Unpacking & Packing List

    If any part is missing or broken, please contact cus- tomer service at 1-847-429-9263 (M-F 8-5 CST), or email techsupport@wenproducts.com. Components Accessories *20V Battery (1) *20V Charger (1) Reciprocating Saw Wood Blade (1) *Only included with model number 20631.

  • Page 11: Know Your Reciprocating Saw

    TOOL PURPOSE Cut through almost anything with your WEN Reciprocating Saw. Refer to the following diagrams to become familiar- ized with all the parts and controls of your reciprocating saw. The components will be referred to later in the manual for assembly and operation instructions.

  • Page 12: Assembly & Adjustment

    ASSEMBLY & ADJUSTMENTS WARNING! Never make any adjustments or blade installations while the battery is installed. Make sure that saw blades are free of fine material, such as small slivers of metal or wood. Use protective gloves during operation and assembly. REPLACING / INSTALLING SAW BLADES Fig.

  • Page 13: Operation

    OPERATION WARNING! Dusts from certain materials can be harmful to your respiratory health. Always use this tool in an area with good ventilation. Wear a dust mask during operation to prevent inhalation of unwanted particulates. Prevent dust accumulation, as piles of dust and debris can easily ignite and cause a fire. STARTING &...

  • Page 14: Maintenance

    WARNING! Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the tool must be performed by a qualified technician. When servicing, use only identical WEN replacement parts. Use of other parts may be hazardous or induce product failure.

  • Page 15: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST...
  • Page 16 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. 20631-001 Left Housing Torx Oval-Head Screw, 20631-027 M4x8 20631-002 LED Light Reciprocating Rod 20631-003 LED Light Cover 20631-028 and Chuck Assembly 20631-004 Battery Terminal 20631-029 Rod Baseplate...

  • Page 17: Warranty Statement

    WARRANTY STATEMENT WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship during personal use for a period of two (2) years used for professional or commercial use.
  • Page 18 NOTES...
  • Page 19 NOTES...
  • Page 20 THANKS FOR REMEMBERING V. 2024.12.03...

This manual is also suitable for:

20631bt

Table of Contents
