- Page 1 MIX / Instruction Manual: 1900105 POUR’D Machine P/N: 1000943 , 1000879#, 1000879FB, 1000941 & 1000942, 1000876...
-
Page 2: Table Of Contents
Contents 1. Font Box Contents....................2 2. Counter Cut-Out....................3 3. Installation......................4 No Drip Tray....................4 Drip Tray....................5 Connecting Hoses with MIX................6 Connecting Hoses with POUR’D..............7 4. Operating Font....................12 5. Cleaning & Maintenance..................13 Font Box Contents 3 & 1 Button Models 3B Concentrate 1000942 •... -
Page 3: Counter Cut-Out
Counter Cut Out 32mm Scale 1:1 / 1 ¼” 100mm / 4” For drip tray only... -
Page 4: Installation
Installation 1. No Drip Tray 32mm / 1 ¼” Hosing should be trimmed to ensure continuous drop from font to boiler 50mm... -
Page 5: Drip Tray
Installation 2. Drip Tray (sold seperately p/n. 2300268) 32mm/ 1 ¼” 100mm/ 4” The drain outlet on the drip tray should be plumbed to waste Hosing should be trimmed to ensure continuous drop from font to boiler 50mm... -
Page 6: Connecting Hoses With Mix
Installation Connecting Hoses with MIX Cold Water Power Hot Water Vent MIX Programmable Buttons 1 Button Font 2 Button Font 3 Button Font... -
Page 7: Connecting Hoses With Pour'd
Installation Connecting Hoses with POUR’D Control Box POUR’D 3 Button Font with Boiler Diluted concentrate with hot or ambient water & concentrate shot 3 button connections (1000942 3b concentrate) For use with Boiler never place beverage source above control box to avoid concentrate spilling on machine (Plumbed to mains) Cold water hard 1/4”... -
Page 8: Boiler Setup
Installation Control Box Setup 3 finger press short hold MODE COLD % CONCENTRATE (0% = just 020% 000% water, 20%=4:1) P&H 200ml 30ml DISPENSE VOLUME (P&H = push and hold) Next MODE DESCRIPTION Hot Water (set ratio to 0% ) COLD Cold / ambient water mixed with concentrate (set ratio to 0% for just cold water) - Page 9 Installation POUR’D 3 Button Font with Chiller Diluted concentrate with cold, sparkling or ambient water & a concentrate shot 3 button connections (1000942 3b concentrate) Connecting Hoses For use with chiller Cold/Sparkling water (1800372) Din connector to font Power Cable Beverage tube control box to font (1800372)
- Page 10 Installation Control Box Setup Calibrate conc pump Calibrate Hot water Calibrate Cold water RTD speed Calibrate Hot water Chiller present RTD speed Next Next 3 finger press long hold 3 finger press short hold MODE COLD % CONCENTRATE (0% = just 000% 020% water, 20%=4:1)
-
Page 11: User Setup
User Setup Programmable Buttons - Program and change buttons accordingly Calibrate conc pump Calibrate Cold water Calibrate Hot water RTD speed Next 3 finger press long hold OPTION DESCRIPTION Calibrate conc pump Will pump concentrate using FAST speed for 10 seconds and ask for weight to be entered –... -
Page 12: Operating Font
Operating Font 1. Push & Hold 2. Push & Release... -
Page 13: Cleaning & Maintenance
Cleaning & Maintenance RISK OF SCALDING Turn off the boiler before cleaning to prevent accidental triggering of a dispense. Beware of accidentally operating the font – especially when cleaning around the push buttons. The appliance may not be immersed in water or cleaning solution . The exterior of this font may be cleaned with a damp cloth and a light detergent. - Page 14 Marco Beverage Systems Limited. 63d Heather Road, Sandyford Industrial Estate, Dublin 18 t: +353 (0)1 295 2674 f: +353 (0)1 295 3715 e: sales@marco.ie www.marcobeveragesystems.com NSF/ANSI E337347...
