Moveis Primavera VISAGE VS9124A Assembly Instructions

MANUFACTURER'S TIPS
NECESSARY TOOLS:
ELECTRIC SCREWDRIVER MANUAL SCREWDRIVER
ASSEMBLY TIME:
ASSEMBLY TIPS:
A - SEPARATE AND IDENTIFY THE PARTS AS PER THE ASSEMBLY INSTRUCTIONS.
B - IF THE UNIT IS TO BE ASSEMBLED LYING DOWN, DO SO WITH IT FACING UPWARDS, RESTING ON
THE CARDBOARD. TURN THE UNIT AROUND TO INSTALL THE BACK BOARD.
C -
REMEMBER, IF THE BACK BOARD IS NOT INSTALLED CORRECTLY, THE UNIT WILL NOT ALIGN
PROPERLY.
D -
FOR A BETTER FINISH, DON'T FORGET TO PUT THE LIDS ON THE SCREWS
PRODUCT CARE:
A -
USE A SLIGHTLY DAMPENED CLOTH TO CLEAN THE UNIT.
B -
AVOID LEAVING THE UNIT IN THE SUN, AS THIS WILL WEAR OUT THE PAINTWORK.
C -
DON'T LET THE UNIT COME INTO CONTACT WITH WATER.
ATTENTION: FOLLOW THESE ASSEMBLY INSTRUCTIONS CAREFULLY
HAMMER
45 MINUTES
.
.
Assembly instructions
DUO BED VISAGE - VS9124A - ONIX/TERRACOTA
Dimensions: Height: 1.06 - Width: 1,702 - Depth: 2,15
Fitting Qty Code
A 04 1688
SCREW
1/4 X 130
B
04 256
FLAT HEAD
SCREW 4.5 X 50
C
FLAT HEAD 12 255
SCREW 4 X 40
D
FLAT SCREW 06 254
4x25
E 24
FLAT SCREW 252
3,5x14
F
04 17520
PEG
12X50
G
14 266
PEG
8X30
H
BEAM 10 2969
SUPPORT
I
NAIL 59 264
13x15
J 04
HOLE COVER 16325
STICKER ONIX
K
04 1689
HALF MOON
NUT
L
04
25X30 2223
SOCKET
M MINIFIX
10
17573
PIN
MINIFIX
N
10
2774
CAM
O 02
ANGLE BRACKET 4007
30X40
P
PLASTIC 06 8816
ANGLE BRACKET
Part Code Description
Bed Beam onix
37550
01
Front Footboard terracota
37551
02
Large foot bed onix
03 37552
Large rear panel terracota
37554
04
37556 Headboard frame onix
05
Small foot bed onix
37553
06
37555 Footboard frame onix
07
10948 Beam
08
37560 Fifth foot
09
7631 Cross support
10
Fittings kit
11 37559
ATTENTION: FOLLOW THESE ASSEMBLY INSTRUCTIONS CAREFULLY
Qty Part dimensons :
02 2000X220X25 mm
01 1650X220X25 mm
02 1060X100X25 mm
01 1600X677X15 mm
01 1652X100X25 mm
02 395X100X25 mm
01 1702X100X25 mm
11 1950X60X12 mm
03 340X65X22 mm
05 1595X70X22 mm
