Moveis Primavera VISAGE VS908EA Assembly Instructions

MANUFACTURER'S TIPS
NECESSARY TOOLS:
ELECTRIC SCREWDRIVER MANUAL SCREWDRIVER
ASSEMBLY TIME:
ASSEMBLY TIPS:
A - SEPARATE AND IDENTIFY THE PARTS AS PER THE ASSEMBLY INSTRUCTIONS.
B - IF THE UNIT IS TO BE ASSEMBLED LYING DOWN, DO SO WITH IT FACING UPWARDS, RESTING ON
THE CARDBOARD. TURN THE UNIT AROUND TO INSTALL THE BACK BOARD.
C -
REMEMBER, IF THE BACK BOARD IS NOT INSTALLED CORRECTLY, THE UNIT WILL NOT ALIGN
PROPERLY.
D -
FOR A BETTER FINISH, DON'T FORGET TO PUT THE LIDS ON THE SCREWS
PRODUCT CARE:
A -
USE A SLIGHTLY DAMPENED CLOTH TO CLEAN THE UNIT.
B -
AVOID LEAVING THE UNIT IN THE SUN, AS THIS WILL WEAR OUT THE PAINTWORK.
C -
DON'T LET THE UNIT COME INTO CONTACT WITH WATER.
ATTENTION: FOLLOW THESE ASSEMBLY INSTRUCTIONS CAREFULLY
HAMMER
60 MINUTES
.
.
Assembly instructions
DRESSER VISAGE - 8 DRAWER - VS908EA - ONIX / TERRACOTA
Dimensions: Height: 1.86 - Width: 1.2 - Depth: 0.40
Fittings Qty
Code
A
25 255
FLAT HEAD SCREW 4 X 40
B 96 252
FLAT SCREW 3.5 X 14
C
TUBE 01 2783
OF GLUE
D
HOLE COVER 38 16325
STICKER onix
E PEG
12 266
8 X 30
F PEG 16 372
6 X 30
G MINIFIX 38 2773
PIN
H
MINIFIX 38 2774
CAM
I H PROFILE 16914
01
1200MM GREY
J NAIL
110 263
10 X 10
K 08 15438
STYLE CURVE
L
PLASTIC 06 37549
SOCKET
M NAIL
32 264
13 X 15
N METALIC
424
08
SLIDE 350MM
ATTENTION !!!
MIRROR: REMOVE THE PROTECTION
OFDOUBLE-SIDED TAPE. AFTER MAKING THE
APPLICATION, ALIGNING THE MIRROR THERE
ARE 20MM OF THE DRESSING TABLE TOP.
Description
Code
Part
Tophead onix
37530
01
Backboard onix
02 37512
Left sideboard onix
37513
03
Right sideboard onix
37514
04
Division onix
37515
05
Smaller frame onix
37518
06
Larger frame onix
37517
07
37516 Panel with mirror terracota
08
Draw terracota
37529
09
37520 onix draw sideboard
10
onix draw rearboard
37521
11
Draw bottom stylized Primavera
37522
12
Bottomboard chest
37523
13
37528 Set of fittings
14
ATTENTION: FOLLOW THESE ASSEMBLY INSTRUCTIONS CAREFULLY
Qty. Dimension parts :
01 1200X385X25 mm
01 1200X385X25 mm
01 720X385X25 mm
01 720X385X25 mm
01 720X385X15 mm
01 600X70X25 mm
02
1015X70X25 mm
01 1250X600X15 mm
08 560X175X15 mm
16 365X120X15 mm
08 511X97X15 mm
08 541X370X03 mm
02 1190X377X03 mm
