- Page 1 FL 1500 F User manual...
-
Page 2: Installation Instructions
Introduction The RobLight FL1500 F light generator is designed for indoor use in dry locations with glass and PMMA fibre harness Ø28 mm. It can be used in all installations set- ups, including closed compartments if limits for max ambient temperature are followed. -
Page 3: Warranty Label
The extremely high intensity will increase the temperature in the material. Using non RobLight harnesses in this light generator is at its own risk. Ensure that the polyconnector is undamaged and clean before using the light gener- ator in retrofit RobLight installations. -
Page 4: Light Source
Technical data General Light port Ø28 mm Fibre type PMMA or glass Material Aluminium, POM and other Dimensions (L x H x W) 375 x 150 x 300 mm Weight (total) 7600 g Safety Environmental Protection rating IP 20 Thermal protection Integrated auto Cooling Axial fan x 2... - Page 5 Installation instructions a) Remove cap from the light port b) Check that the end face of the polyconnector is clean and undamaged c) Insert the poly connector fully in the light port d) Tighten the screw onto the light port with an Allen key e) Ensure all installation and ventilation requirements are met f) Connect the supply cord to the mains WARNING!
-
Page 6: Mounting Accessories
Vertical mounting F models This light generator should not be mounted with light port upwards. At high ambi- ent temperature the operational lifetime of the internal components and harness will be reduced. Mounting (Accessories) Attach to surface using three screws in the baseplate holes. Be aware that the total weight of this system is more than 7.6 kg + the downforce from the fibre harness. - Page 7 Closed compartments MAX AMBIENT TEMPERATURE 45°C. Recommendations: (should always be tested in a mock up) Secure enough space to allow natural heat transmission through surfaces. Surfaces should not be insulated. Cooling air for the polyconnector can not be obstructed in any way, as it is essential to avoid damage to the harness.
- Page 8 Accessories / Spare part Part name Description Item no. To change the light Adapter Ø28/Ø9 port from Ø28 to 7800 0130 Ø9 mm Repair kit with parts Fan replacement kit 0130 8000 to install new fan Mounting plate for C Mounting kit 0136 9001 and F models...
-
Page 9: Installing Accessories
Installing accessories Remove the connector (3 screws) Mount the filtre in the bracket place the filter bracket on the back side of the connector Replace the connector in the light generator... -
Page 10: Application Notes
Application notes The light generator is an electronic device and must be handled accordingly. The different components will have different factors influencing the practical lifetime. The most important factor for this system is the condition of the surrounding air (temperature and cleanliness). The data we have stated about or and the expected lifetime of the key components, are at the temperatures that the suppliers have performed during their standardized tests in clean environments. -
Page 11: Troubleshooting
This light source is not supposed to be otherwise serviced, if used as recommended. The fan can be replaced using standard tools. A replacement kit with guide is avail- able. If the product is not performing as specified, use the troubleshooting guide. If you need further assistance, please contact RobLight. Troubleshooting Problem Problem... - Page 12 RobLight A/S, Gl. Skagensvej 105 H, DK-9900 Frederikshavn T: +45 9244 4888, E: info@rob-light.com www.rob-light.com RobLight accepts no responsibility for possible errors in catalogues, brochures and other printed material. RobLight reserves the right to alter or discontinue its products without notice. © 2019 RobLight A/S...
