roblight FL 1500 B-2 User Manual

Advertisement

FL 1500 B-2
User manual
RobLight A/S, Nordhavnsvej 1A, DK-9900 Frederikshavn
T: +45 9244 4888, E: info@rob-light.com
www.rob-light.com
RobLight accepts no responsibility for possible errors in catalogues, brochures and other printed material.
RobLight reserves the right to alter or discontinue its products without notice. © 2019 RobLight A/S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FL 1500 B-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for roblight FL 1500 B-2

  • Page 1 RobLight A/S, Nordhavnsvej 1A, DK-9900 Frederikshavn T: +45 9244 4888, E: info@rob-light.com www.rob-light.com RobLight accepts no responsibility for possible errors in catalogues, brochures and other printed material. RobLight reserves the right to alter or discontinue its products without notice. © 2019 RobLight A/S...
  • Page 2: Troubleshooting

    Introduction Troubleshooting The RobLight FL 1500 B-2 light generator is designed for indoor use in dry locations Problem Problem Trace the problem Trace the problem Solution Solution with glass and PMMA fibre harness Ø28 mm. It can be used in all installations set-...
  • Page 3: Application Notes

    The extremely high intensity will increase the temperature in the material. Using non RobLight harnesses in this light generator is at its own risk. Ensure that the polyconnector is undamaged and clean before using the light gener-...
  • Page 4: Light Source

    The fan can be replaced using standard tools. A replacement kit with guide is avail- able. Typical Ra (CRI 92+ (min 90) If the product is not performing as specified, use the troubleshooting guide. If you need further assistance, please contact RobLight.
  • Page 5: Installing Accessories

    Installing accessories Installation instructions 1-10V dimmer potentiometer 0126 5101 a) Remove cap from the light port b) Check that the end face of the polyconnector is clean and undamaged c) Insert the poly connector fully in the light port d) Tighten the screw onto the light port with an Allen key e) Ensure all installation and ventilation requirements are met f) Connect the supply cord to the mains WARNING!
  • Page 6: Mounting Accessories

    Vertical mounting F models Closed compartments This light generator should not be mounted with light port upwards. At high ambi- MAX AMBIENT TEMPERATURE 45°C. ent temperature the operational lifetime of the internal components and harness will be reduced. Recommendations: (should always be tested in a mock up) Secure enough space to allow natural heat transmission through surfaces.
