MG MOTOR MG HS Quick Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Quick Guide
MG HS / MG EHS PHEV

Advertisement

loading
Need help?

Need help?

Do you have a question about the MG HS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MG MOTOR MG HS

Summary of Contents for MG MOTOR MG HS

  • Page 1 Quick Guide MG HS / MG EHS PHEV...
  • Page 3 Before starting the journey, it is recommended to read the Owner's Manual in the vehicle's infotainment system, MG iSMART App or on the MG Motor website to understand all the information required for the use of the vehicle. Always remember that if you have any queries concerning the operation or specification of your car, your MG Authorised Repairer will be glad to advise you.
  • Page 4 If you require MG Assistance please provide the following information when you call: • Your name • A contact telephone number (if available) • Registration, make, model and colour • Address • Nature of breakdown • Exact location...

  • Page 5: Interior Layout

    Interior Layout...
  • Page 6 Interior Layout 9. Glovebox 1. Wiper Stalk Switch 10. Gear Lever 2. Horn 11. START/STOP Switch 3. Driver Airbag 12. Clutch Pedal * 4. Instrument Pack 13. Brake Pedal 5. Indicator/Main Beam Stalk Switch 14. Accelerator Pedal 6. Intelligent Display 15.
  • Page 7 Instrument Pack - Gasoline Model 1. Left Information Card 6. Time 2. Warning Lamps and Indicators 7. Driving Mode 3. Vehicle Speed 8. Gear Display 4. Right Information Card 9. Engine speed in RPM 5. Engine Coolant Temperature 10. Fuel Gauge and Fuel Driving Range The instrument pack has multiple display modes, which can be set in the entertainment display.
  • Page 8 Instrument Pack – PHEV Model 1. Left Information Card 9. Driving Mode 2. Warning Lamps and Indicators 10. Engine Speed in RPM 3. Vehicle Speed 11. Power Meter 4. Right Information Card 12. Power System Status 5. Engine Coolant Temperature 13.
  • Page 9 Underbonnet Locations Gasoline model 1. Engine Intercooler Coolant Expansion Tank 2. Engine Coolant Expansion Tank 3. Washer Fluid Reservoir 4. Brake Fluid Reservoir 5. Oil Dipstick 6. Oil Filler Cap PHEV model 1. Water-Cooled Intercooler and Drive Motor 1 2 3 4 5 Control Module Coolant Expansion Tank 2.
  • Page 10 Recommended Fluids, Capacities and Pressures 1.5T - DCT280 1.5T - SCM280 1.5T - EDU Engine Oil C5 & SP 0W-20 4 Litres 4 Litres 4 Litres Engine Coolant Glycol (OAT ) 7.3 Litres 6.6 Litres 7.6 Litres Water-cooled Intercooler Glycol (OAT ) 3 Litres 3 Litres 7.2 Litres...
  • Page 11 Keyless Start Indicator OFF • Engine and Power system OFF • Power seats and mirrors remain operational Indicator light is YELLOW • Pressing START/STOP switch without footbrake applied enters ACC mode • Limited electrical equipment operation & power windows Indicator light is GREEN •...
  • Page 12 Locking and Unlocking - Keyless 1. Lock button 2. Tailgate release button 3. Unlock button 4. Smart Key 5. Mechanical Key Keyless Locking Upon exiting the vehicle, press the button on the front door handle once (no need to press the lock button on the key) to lock all doors before walking away from the car.
  • Page 13 Locking and Unlocking - Key 1. Lock button 2. Tailgate release button 3. Unlock button 4. Remote Key 5. Mechanical Key Key Locking • Using the remote key to lock: press the Lock button (1) on the smart key to lock the vehicle after closing the doors, bonnet and tailgate.
  • Page 14 Accessing Owners Literature Select ‘User Manual’ in the Main Interface Page, scan the QR code to select your region and download the iSMART APP. Register and view the user manual. The full Owners Manual is also available in the Owners Section of www.mg.co.uk...

  • Page 15: Emergency Starting

    Emergency Starting NEVER attempt to power the vehicle by pushing or towing. Make sure that both batteries are of the same rated voltage (12 volts), and that the booster cables are approved for use with 12 volt car batteries. Ensure sparks and naked flames are kept well away from the front compartment. Ensure that each booster cable connection is securely made.
  • Page 16 Emergency Starting NOTE: Where it is possible to open the tailgate of the disabled vehicle (B), please always give priority to the positive battery terminal as the positive connecting point. If the tailgate cannot be opened, please open the front compartment fuse-box. The terminal shown in figure(1) can be used as the positive connecting point.

  • Page 17: Towing For Recovery

    Towing for Recovery Vehicle Recovery Towing for Recovery Towing Hook When pushing or towing the vehicle from a dangerous situation or onto the transporter, the speed must remain below 3mph and be completed within 3 minutes. When pushing or towing the vehicle for temporary situation, the locking tab of the driver seat belt should be inserted into the buckle and maintained in the inserted state, then turn the shift knob to N and release the EPB, otherwise the vehicle maybe damaged.
  • Page 18 Towing for Recovery Towing points are intended for use by qualified recovery specialists to assist in the recovery of your car when a breakdown or accident occurs. They are not designed for towing other vehicles. The vehicle can be towed using a tow rope but a towing bar is recommended. NEVER use a twisted tow rope, may cause the towing eye to unscrew.
  • Page 19 Towing for Recovery Towing for Recovery When towing, DO NOT suddenly accelerate or brake suddenly, this can cause accidents. Suspended Towing Suspended towing is the best method for recovering a vehicle that needs to be towed. The drive wheels MUST be suspended above the ground. Ensure the EPB is released when the rear wheels are in contact with the road surface.
  • Page 20 Emergency Tyre Inflation Tyre Repair * Tool Identification Type A* Type B* 1. Towing hook 1. Electric air pump 2. Repair Fluid 2. Repair fluid 3. Wheel bolt cap removal 3. Wheel bolt cap removal tool tool 4. Warning triangle 4.
  • Page 21 Emergency Tyre Inflation 3. Switch on the power switch of the electric compressor (i.e., press ‘-‘), to start pumping sealant into the tyre. The tyre sealant bottle will become empty after approximately 30 seconds. The tyre should reach the specified pressure within 5 or 10 minutes.
  • Page 22 Emergency Tyre Inflation Please follow different guidelines based on the tyre pressure measured: • If the tyre pressure has dropped to less than 0.8 bar (11.6 psi), do not continue driving, seek assistance instead. • If the tyre pressure is between 0.8 bar (11.6 psi) and specified pressure, use the electric air pump to inflate the tyre until it reaches the specified pressure.

This manual is also suitable for:

Mg ehs phev
