Summary of Contents for MG MOTOR MG3 Hybrid

  • Page 1 Quick Guide MG 3 Hybrid...
  • Page 3 Before starting the journey, it is recommended to read the Owner's Manual in the vehicle's infotainment system, MG iSMART App or on the MG Motor website to understand all the information required for the use of the vehicle. Always remember that if you have any queries concerning the operation or specification of your car, your MG Authorised Repairer will be glad to advise you.
  • Page 4 If you require MG Assistance please provide the following information when you call: • Your name • A contact telephone number (if available) • Registration, make, model and colour • Address • Nature of breakdown • Exact location...

  • Page 5: Interior Layout

    Interior Layout...
  • Page 6 Interior Layout 10. Glovebox 1. Power Window Switches 11. Air Conditioning Controls*/Shortcut Keys 2. Interior Locking Switches 12. Shift Control Knob 3. Wiper Stalk Switch 13. Stop/Start Switch* 4. Horn 14. Brake Pedal 5. Driver Airbag 15. Accelerator Pedal 6. Instrument Pack 16.

  • Page 7: Instrument Pack

    Instrument Pack 1. Active Safety Display 7. Power Meter 8. Driving Mode 2. Warning Lamp Display Areas (multiple warning lamps feature in these areas). 9. Fuel Gauge and Driving Range 10. Power System Status 3. Speedometer - Indicates road speed in miles or kilometres per hour 11.
  • Page 8 Underbonnet Locations 4. Engine oil filler 1. Washer fluid reservoir 2. Brake fluid reservoir 5. Engine coolant reservoir 3. Engine oil level dipstick 6. Hybrid/transmission coolant reservoir...
  • Page 9 3.4 Litres Hybrid Transmission Fluid Castrol BOT794 1.5 Litres Brake Fluid DOT 4 0.8 Litres Washer Fluid Original MG Motor Windscreen 2.5 Litres Washer Fluid Air Conditioning Refrigerant, g R1234yf 520 +/- 20g Air Conditioning Oil, ml SP-A2 150 +/- 10g...
  • Page 10 Keyless Start Indicator OFF • Engine and Power system OFF • Power seats and mirrors remain operational Indicator YELLOW • Pressing Start/Stop switch without footbrake applied enters ACC mode • Limited electrical equipment operation & power windows Indicator GREEN • Pressing Start/Stop switch without footbrake applied whilst in ACC mode - Enters ON Mode •...

  • Page 11: Key Start

    Key Start Position 0 ( LOCK/OFF ) • The key can be inserted or removed. • Steering lock activated – may require steering wheel turning slightly to engage/disengage. Position 1 ( ACC ) • The power system is not in a started state and the key cannot be removed. •...
  • Page 12 Locking and Unlocking - Keyless 1. Lock button 2. Tailgate release button 3. Unlock button 4. Smart Key 5. Mechanical Key Keyless Locking Upon exiting the vehicle, press the button on the front door handle once (no need to press the lock button on the key) to lock all doors before walking away from the car, the vehicle will enter the immobilised/alarm armed state.
  • Page 13 Locking and Unlocking - Key 1. Lock button 2. Tailgate release button 3. Unlock button 4. Smart Key 5. Mechanical Key Key Locking • Using the remote key to lock: press the Lock button (1) on the smart key to lock the vehicle after closing the doors, bonnet and tailgate.
  • Page 14 Accessing Owners Literature Home – Short press to return main interface Long press to restart system Volume Control – Volume Control + Audio Source Information Displays music/radio status information, including song name, play/pause, etc. Status Bar Displays Bluetooth, Time, etc. Menu Bar Displays shortcut function icons: such as HOME, Navigation*, Bluetooth Music Radio,...
  • Page 15 Accessing Owners Literature 1. A/C 7. Vehicle 2. Radio 8. Navigation 3. BT Music 9. User Manual 4. USB Music 10. Phone 5. USB Video 11. Settings 6. 360° Camera (if fitted) Power On/Off Power On Pressing the START/STOP Switch or rotating the ignition switch to select the ACC or ON/READY position will automatically set the system to power on.
  • Page 16 Accessing Owners Literature Select (My Car) in the Main Interface shortcut menu bar to enter the Vehicle Settings interface. Select ‘User Manual’ (9) in the vehicle settings interface to open the Owners Manual. The full Owners Manual is also available in the Owners Section of www.mg.co.uk...

  • Page 17: Emergency Starting

    Emergency Starting Emergency Starting NEVER attempt to power the vehicle by pushing or towing. Make sure that both batteries are of the same rated voltage (12 volts), and that the booster cables are approved for use with 12 volt car batteries. Ensure sparks and naked flames are kept well away from the front compartment.
  • Page 18 Emergency Starting Emergency Starting cont Start the donor vehicle and allow it to run for a few minutes. Start the disabled vehicle. If the disabled vehicle does not start after several attempts, it may need to be repaired. Please contact an MG Authorised Repairer. After both the vehicles have normally started/powered, turn off the donor vehicle power.

  • Page 19: Towing For Recovery

    Towing for Recovery Vehicle Recovery Towing for Recovery Towing Hook When pushing or towing the vehicle from a dangerous situation or onto the transporter, the speed must remain below 3mph and be completed within 3 minutes. When pushing or towing the vehicle onto the transporter, the driver's side seat belt should be inserted into the lock and maintained in the inserted state in order to release the EPB.
  • Page 20 Towing for Recovery Towing points are intended for use by qualified recovery specialists to assist in the recovery of your car when a breakdown or accident occurs. They are not designed for towing other vehicles. The vehicle can be towed using a tow rope but a towing bar is recommended. NEVER use a twisted tow rope, may cause the towing eye to unscrew.
  • Page 21 Towing for Recovery Towing for Recovery When towing, DO NOT suddenly accelerate or brake suddenly, this can cause accidents. Suspended Towing Suspended towing is the best method for recovering a vehicle that needs to be towed. The drive wheels MUST be suspended above the ground. Ensure the EPB is released when the rear wheels are in contact with the road surface.
  • Page 22 Emergency Tyre Inflation Tyre Repair Tool Identification Repair Fluid Electric Air Pump Wheel Bolt Cap Removal Tool Towing Hook Tyre Repair 1. Remove the label at the bottom of the repair fluid reservoir and attach it to the steering wheel to remind the driver not to exceed 50 mph. 2.
  • Page 23 Emergency Tyre Inflation 3. Switch on the power switch of the electric compressor (i.e., press “-”), to start pumping sealant into the tyre. The tyre sealant bottle will become empty after approximately 30 seconds. The tyre should reach the specified pressure within 5 or 10 minutes. Note: The pressure gauge may briefly reach 6 bar (87 psi), then the pressure begins to drop to normal.
  • Page 24 Emergency Tyre Inflation Please follow different guidelines based on the tyre pressure measured: • If the tyre pressure has dropped to less than 0.8 bar (11.6 psi), do not continue driving, seek assistance instead. • If the tyre pressure is between 0.8 bar (11.6 psi) and specified pressure, use the electric air pump to inflate the tyre until it reaches the specified pressure.
